| Ref | Part Number | Description |
|---|
| 1 |
108-9083 |
PLATE-SIDE, RH Price: $328.36 |
| 1 |
532071673 |
Cap, Plunger (AYP part number) Price: $3.99 |
| 2 |
108-9082 |
PLATE-SIDE, LH Price: $328.36 |
| 2 |
532123436 |
Rod, Parking Brake (AYP part number) Price: $4.99 |
| 3 |
104-3396 |
SCREW-HH Price: $0.75 |
| 3 |
532123437 |
Bracket, Parking Brake (AYP part number) Price: $4.46 |
| 4 |
532008883 |
PEDAL COVER This part replaces 532124872. Price: $3.99 |
| 4 |
99-8662 |
TUBE-SPRING Price: $21.55 |
| 5 |
3218-5 |
NUT-JAM Price: $0.27 |
| 5 |
532122504 |
Bracket, Clutch/Brake Pedal, L.H. (AYP part number) Price: $3.08 |
| 6 |
87-7270 |
WASHER-THRUST Price: $0.89 |
| 6 |
876020308 |
Pin, Cotter 3/32 x 1/2 (AYP part number) This part replaces 876020312. Price: $1.99 |
| 7 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 7 |
819131016 |
Washer 13/32 x 5/8 x 16 Ga. (AYP part number) Price: $3.99 |
| 8 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 8 |
817490508 |
Screw, Hex, Thd. Roll. 5/16-18 x 1/2 (AYP part number) Price: $3.99 |
| 9 |
119-4285 |
SPRING-COMPRESSION Price: $53.23 |
| 9 |
876020412 |
Pin, Cotter 1/8 x 3/4 (AYP part number) Price: $3.99 |
| 10 |
819131316 |
Washer 13/32 x 13/16 x 16 Ga. (AYP part number) Price: $2.99 |
| 11 |
532123543 |
Rod, Brake Front (AYP part number) Price: $8.38 |
| 12 |
110-4069 |
BRACKET Price: $5.57 |
| 12 |
532139933 |
Assembly, Clutch/Brake Pedal (AYP part number) This part replaces 532129567. Price: $21.38 |
| 13 |
115-2007 |
ROD-SPRING Price: $34.97 |
| 13 |
532123394 |
Rod, Clutch (AYP part number) Price: $7.99 |
| 14 |
532121978 |
Bracket, Lift, Shaft (AYP part number) Price: $2.38 |
| 14 |
92-2762 |
PIN-HAIR Price: $1.09 |
| 15 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 15 |
532123641 |
Assembly, Brake, Pivot, Arm (AYP part number) Price: $12.18 |
| 16 |
819251816 |
Washer 25/32 x 1-1/8 x 16 Ga. (AYP part number) Price: $3.99 |
| 17 |
107-7400 |
PIN-LYNCH Price: $9.56 |
| 17 |
812000034 |
Ring, Klip 3/8-16 UNC (AYP part number) Price: $2.99 |
| 18 |
110-4058 |
BRACKET-CHAIN Price: $32.43 |
| 18 |
532151332 |
SPRING, BRAKE ROD This part replaces 532106888. Price: $2.99 |
| 19 |
112-8978 |
FRAME-CENTER Price: $494.59 |
| 19 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 20 |
107-2979 |
BOLT-SHOULDER Price: $3.94 |
| 20 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $3.99 |
| 21 |
3234-19 |
SCREW-HHF Price: $1.73 |
| 21 |
532131461 |
CLUTCH KIT This part replaces 532131460. Price: $13.99 |
| 22 |
532144585 |
Trunnion, Lift (AYP part number) This part replaces 532127378. Price: $7.99 |
| 22 |
67-9410 |
WASHER Price: $2.04 |
| 23 |
108-4279 |
SPACER-FRAME Price: $8.34 |
| 23 |
873680600 |
Nut, Crownlock 3/8-16 UNC Price: $1.99 |
| 24 |
119-4262 |
TUBE-SUPPORT Price: $69.90 |
| 24 |
819132012 |
Washer 13/32 x 1-1/4 x 12 Ga. (AYP part number) Price: $2.99 |
| 25 |
112-8980 |
CARRIER FRAME ASM Price: $820.94 |
| 25 |
532004921 |
Spring, Retainer (AYP part number) This part replaces 532124961. Price: $3.99 |
| 26 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 26 |
873680600 |
LOCKNUT This part replaces 873930600. Price: $1.99 |
| 27 |
532127369 |
Link, Threaded (AYP part number) Price: $9.99 |
| 28 |
532127358 |
Assembly, Rear Mower Lift (AYP part number) Price: $40.26 |
| 29 |
872110506 |
Bolt, Carriage 5/16-18 UNC x 3/4 (AYP part number) Price: $3.99 |
