| Ref | Part Number | Description |
|---|
| 1 |
539131517 |
BLOCK, UPPER Price: $24.99 |
| 1 |
82-9250 |
STUD-THREADED Price: $10.57 |
| 2 |
539131519 |
BLOCK, LOWER Price: $12.99 |
| 2 |
60-2000 |
PIN Price: $1.13 |
| 3 |
539131518 |
BEARING, FLANGE Price: $9.99 |
| 3 |
60-1750-03 |
LEVER-LATCHING, RH This part replaces 60-1750. Price: $94.34 |
| 4 |
522452901 |
PIVOT.SECTION.DRIVE.CONTROL Price: $17.99 |
| 4 |
60-1990 |
BUSHING Price: $14.57 |
| 5 |
47-7010 |
BUSHING-RUBBER Price: $122.81 |
| 5 |
576452801 |
MOUNT.HANDLE.CONTROL This part replaces 539131521. Price: $29.99 |
| 6 |
60-1820 |
SHAFT-PIVOT, LATCH Price: $134.64 |
| 6 |
874780528 |
SCREW This part replaces 539990669. Price: $4.99 |
| 7 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 7 |
74-2920-03 |
CARRIER-FRONT This part replaces 74-2920. Price: $2,618.36 |
| 8 |
539133007 |
WASHER, .825 X 1.087, WAVE Price: $2.99 |
| 8 |
60-1780-03 |
LEVER-LATCHING, LH This part replaces 60-1780. Price: $94.34 |
| 9 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 9 |
82-9370 |
PAD-STEP, FRONT Price: $19.69 |
| 10 |
3285-11 |
PIN-GROOVE Price: $1.70 |
| 10 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 11 |
539131658 |
DAMPENER W/SPRING Price: $84.99 |
| 11 |
60-0670 |
SPRING Price: $19.50 |
| 12 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 13 |
510422601 |
RHSNB 5/16-18 X 4 GR 5 ZD Price: $2.99 |
| 13 |
82-9360 |
ROD-LATCH Price: $31.36 |
| 14 |
539127046 |
NUT M8 X 1.25 STD HEX Price: $2.99 |
| 14 |
58-2720 |
PIN Price: $49.81 |
| 15 |
594056301 |
Studs This part replaces 539110607. Price: $2.99 |
| 15 |
86-6120 |
DISCONTINUED Price: Call Us |
| 16 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 16 |
596582201 |
Bolts This part replaces 539976935. Price: $2.99 |
| 17 |
539132011 |
LEVER.DRIVE.W/GRIP Price: $59.99 |
| 17 |
60-0090 |
PIN-PIVOT Price: $93.25 |
| 18 |
322-2 |
SCREW-HH Price: $0.69 |
| 18 |
521982601 |
KNOB, 3" Price: $5.99 |
| 19 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 19 |
539104530 |
DECK LIFT SPACER Price: $5.99 |
| 20 |
539102845 |
SPRING Price: $2.99 |
| 20 |
60-0190 |
STRIP Price: $36.98 |
| 21 |
58-6520 |
DECAL-GREASE Price: $2.57 |
| 21 |
596565201 |
Screws This part replaces 539108395. Price: $1.99 |
| 22 |
325-2 |
SCREW-HH Price: $1.02 |
| 22 |
539130894 |
GRIP - DRIVE LEVER 12" This part replaces 539122635. Price: $6.99 |
| 23 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 23 |
539122636 |
END PLUG 15/16 (BLACK) Price: $3.99 |
| 24 |
596433601 |
Nuts This part replaces 539115617. Price: $2.99 |
