WHEELS & TIRES
Parts (28)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 104-0545 | BED ASM Price: $1,416.99 |
| 1 | 523012202 | WHEEL Price: $139.99 |
| 2 | 32128-21 | NUT-HF Price: $0.39 |
| 2 | 523034501 | RIM Price: $109.99 |
| 3 | 535460001 | TIRE This part replaces 523034602. Price: $69.99 |
| 3 | 98-8761-01 | GUIDE-WHEEL Price: $48.62 |
| 4 | 3231-21 | SCREW-CARR Price: $0.76 |
| 4 | 506574301 | VALVE This part replaces 523034701. Price: $4.99 |
| 5 | 523012602 | WHEEL Price: $159.99 |
| 6 | 108-3156 | BRACKET-ROD Price: $33.17 |
| 6 | 523034801 | RIM Price: $89.99 |
| 7 | 106-5354 | SPRING-LATCH Price: $30.57 |
| 7 | 506504805 | WASHER Price: $3.99 |
| 8 | 506596203 | SPACE SLEEVE Price: $5.94 |
| 9 | 506504803 | WASHER Price: $3.99 |
| 10 | 506899001 | RETAINING RING Price: $2.99 |
| 10 | 98-8756 | SPACER-STOP Price: $12.55 |
| 11 | 323-38 | SCREW-HH Price: $2.62 |
| 12 | 544353502 | HUB CAP Price: $7.99 |
| 13 | 105-5392 | RIVET-DRIVE Price: $1.76 |
| 13 | 725245961 | BOLT FLANGE - M8X40\ Price: $5.99 |
| 14 | 535470801 | AXLE Price: $32.99 |
| 14 | 98-8776 | MAT-BED Price: $179.44 |
| 15 | 98-8777 | SPACER Price: $5.64 |
| 16 | 136-8502 | ROD-TRAILER, REAR Price: $24.52 |
| 17 | 136-8501 | ROD-TRAILER, FRONT (RH) Price: $24.52 |
| 18 | 323-20 | SCREW-HH Price: $1.28 |
| 19 | 98-8694 | DECAL Price: $33.10 |
