| Ref | Part Number | Description |
|---|
| 1 |
547746001 |
KIT.SVC.DECK.WELD.46.TEX_668 This part replaces 532418227. Price: $449.99 |
| 1 |
99-1644 |
DASH SHROUD ASM Price: $365.54 |
| 2 |
532405507 |
COVER.MANDREL.LH.46" Price: $19.99 |
| 2 |
92-8997 |
COOLER-OIL Price: $512.86 |
| 3 |
532405506 |
COVER.MANDREL.RH.46" Price: $19.99 |
| 3 |
85-9550 |
RUBBER CLAMP ASM Price: $5.56 |
| 4 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 4 |
85-9670 |
NUT-T Price: $1.63 |
| 5 |
AU218-5106 |
FITTING-ELB 90 This part replaces 353-371. Price: $10.29 |
| 6 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 6 |
95-0643 |
TUBE-VALVE TO COOLER Price: $45.04 |
| 7 |
119-2482 |
DECAL-OPERATING This part replaces 92-8985. Price: $27.42 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 584309301. Price: $6.99 |
| 8 |
767148 |
FILTER CONVERSION KIT This part replaces 95-0610. Price: $112.49 |
| 9 |
46-8560 |
SCREW-HHFTF Price: $1.79 |
| 10 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 11 |
322-14 |
SCREW-HH Price: $1.01 |
| 11 |
581043901 |
BLADE.REVOLTION.46"BAGER.PT43 Price: $24.99 |
| 12 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 13 |
587820201 |
KIT,MANDREL,NONGREASE,REVOL This part replaces 580854701. Price: $32.99 |
| 13 |
92-7159 |
TREAD-FLOOR, LH Price: $26.24 |
| 14 |
3234-33 |
SCREW-HHF Price: $0.79 |
| 14 |
587820201 |
KIT,MANDREL,NONGREASE,REVOL This part replaces 580796101. Price: $32.99 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 15 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 16 |
95-5807 |
SPACER Price: $10.10 |
| 17 |
3256-82 |
WASHER-FLAT Price: $0.47 |
| 18 |
322-2 |
SCREW-HH Price: $0.69 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 19 |
95-0620-01 |
STRIP-RETAINER This part replaces 95-0620. Price: $12.71 |
| 20 |
95-5826 |
SHIELD-RUBBER Price: $40.16 |
| 21 |
2412-92 |
CLAMP-HOSE Price: $2.44 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
95-0582 |
HOSE-INTAKE, AIR Price: $61.51 |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 23 |
95-5805 |
AIR CLEANER ASM Price: $140.44 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 24 |
95-5806 |
BRACKET-MOUNTING Price: $28.01 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 25 |
92-7158 |
TREAD-FLOOR, RH Price: $26.24 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 26 |
95-5817 |
FRONT SHIELD ASM Price: $354.47 |
| 27 |
532405357 |
SHIELD.DEFLECTOR.MOWER.46"BLAC Price: $49.99 |
| 27 |
95-0607 |
DISCONTINUED Price: Call Us |
| 28 |
133-8095 |
DECAL-CE This part replaces 93-7252. Price: $3.73 |
| 29 |
237-79 |
O-RING Price: $5.46 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
3269-8 |
RIVET-BLIND Price: $0.51 |
| 31 |
3295-26 |
RIVET 3/16 X 7/16 Price: $6.09 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
532195945 |
PULLEY.MANDREL.5.438.P This part replaces 532197473. Price: $12.99 |
| 32 |
94-1392 |
PAD-RUBBER Price: $7.41 |
| 33 |
117344 |
HANDLE ASM Price: $34.99 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 34 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 34 |
95-0611 |
BRACKET-RH Price: $28.14 |
| 35 |
110-9681-03 |
FORK-PTO This part replaces 95-0612. Price: $195.34 |
| 36 |
249-40 |
KEEPER Price: $9.77 |
| 36 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $34.99 |
| 37 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 38 |
95-5828 |
STRIP-WEAR Price: $2.51 |
| 39 |
94-4519 |
TUBE-CONVOLUTE Price: $2.24 |
| 40 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 40 |
95-0574 |
DISCONTINUED Price: Call Us |
| 41 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $3.99 |
| 41 |
95-5825 |
WIRE ASM Price: $29.70 |
| 42 |
95-0599 |
WIRE ASM Price: $45.86 |
| 43 |
95-0591 |
HOSE-HYD Price: $106.46 |
| 44 |
38-3400 |
GUARD-RUBBER Price: $8.02 |
| 45 |
95-0563 |
TUBE-LH Price: $68.75 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 55 |
531169401 |
SERVICE KIT IDLER.ARM This part replaces 532197249. Price: $5.99 |
| 56 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 59 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 62 |
596564404 |
Bolts This part replaces 874520636. Price: $2.99 |
| 68 |
584453101 |
V-BELT.DRIVE.MWR.MECHANICL.46" This part replaces 532405143. Price: $49.99 |
| 69 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 117 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 119 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $27.99 |
| 147 |
532197251 |
SPRING.MOWER.DRIVE.ELECTRIC Price: $9.99 |
| 188 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 189 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 197 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 198 |
531170601 |
SERVICE KIT BAFFLE CENT This part replaces 532403149. Price: $9.99 |
| 199 |
531170701 |
SERVICE KIT BAFFLE FRONT This part replaces 532403150. Price: $11.99 |
| 200 |
596135501 |
Washers This part replaces 532413524. Price: $4.99 |
| 241 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 246 |
580954003 |
HOLDER.BLADE.REVOLUTION Price: $179.99 |
| 256 |
578296405 |
Screws This part replaces 578296404. Price: $2.99 |
| 257 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873900400. Price: $3.99 |
| 261 |
589481805 |
PLATE.REINF.DECK.46".FRONT.BLK This part replaces 585317705. Price: $17.99 |
| 262 |
585317805 |
PLATE.REINFOR.46.SIDEBOLT.X431 Price: $22.99 |
| 263 |
586638501 |
CAP.REVOLUTION ASM Price: $29.99 |
