| Ref | Part Number | Description |
|---|
| 1 |
117-8093 |
RADIATOR ASM This part replaces 104-3780. Price: $2,185.13 |
| 1 |
157626 |
CONTROL-THROT/CHO Price: Call Us |
| 2 |
114-3995 |
OIL COOLER ASM This part replaces 82-3740. Price: $1,388.56 |
| 2 |
17720410 |
SCREW LT Price: Call Us |
| 3 |
94-2638 |
NUT-FLAT Price: $0.54 |
| 4 |
156700 |
MUFFLER TEC. 13HP Price: Call Us |
| 4 |
93-6028 |
PLATE-LOGO Price: $13.70 |
| 5 |
92-7505-03 |
SCREEN ASM Price: $1,733.53 |
| 6 |
92-7631 |
SEAL-SCREEN Price: $33.08 |
| 7 |
77-3620 |
KNOB-RETAINER Price: $15.13 |
| 8 |
93-4208 |
SEAL-SCREEN, STRIP Price: $68.49 |
| 9 |
32151-72 |
RING-RETAINING Price: $1.59 |
| 10 |
92-7535 |
HOSE ASM Price: $197.33 |
| 11 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 12 |
37-8771 |
BOLT-SHOULDER,HFH Price: $3.59 |
| 13 |
272293 |
GASKET ENG 1 313 LD TIN PLATED Price: Call Us |
| 13 |
32128-20 |
NUT-HF Price: $0.99 |
| 14 |
13280336 |
PIPE NIPPLE LT Price: Call Us |
| 14 |
92-7516-03 |
BRACKET-SUPPORT, COOLER BASE Price: $46.80 |
| 15 |
13200300 |
ELBOW Price: Call Us |
| 16 |
11050600 |
LOCKWASHER Price: Call Us |
| 16 |
3269-4 |
RIVET-POP Price: $1.19 |
| 17 |
69-3020 |
LATCH-CAMLOC Price: $43.54 |
| 18 |
100-3758-03 |
BUMPER ASM Price: $1,074.80 |
| 19 |
2410-42 |
CAP-END Price: $11.62 |
| 20 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 21 |
325-6 |
SCREW-HH Price: $1.42 |
| 22 |
92-7416-03 |
STRAP-RADIATOR Price: $32.23 |
| 23 |
156123 |
SHIELD-HEAT Price: Call Us |
| 23 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 25 |
237-65 |
O-RING Price: $2.50 |
| 26 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 27 |
2410-64 |
PLUG-BUTTON Price: $0.74 |
| 28 |
104-3781 |
HOSE-RADIATOR, LOWER Price: $98.96 |
| 29 |
104-3782 |
HOSE-RADIATOR, UPPER Price: $116.97 |
| 29 |
137180 |
SUB= 532137180 Price: Call Us |
| 30 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 31 |
109202X |
TANK.FUEL.LT. Price: Call Us |
| 32 |
140527 |
CAP ASM FUEL Price: Call Us |
| 33 |
123487X |
HOSE CLAMP Price: Call Us |
| 33 |
98-4576-03 |
BRACKET-RESERVOIR, WATER This part replaces 98-4576. Price: $43.21 |
| 34 |
108-0638 |
BOTTLE-OVERFLOW This part replaces 104-9318. Price: $33.20 |
| 35 |
17490512 |
SCREW Price: Call Us |
| 35 |
321-4 |
SCREW-HH Price: $0.99 |
| 36 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 37 |
137040 |
LINE FUEL Price: Call Us |
| 37 |
281-13 |
PLUG-PIPE Price: $2.86 |
| 38 |
98-7895 |
TUBE Price: $6.88 |
| 39 |
110-4110 |
HOSE-LP This part replaces 54-8040. Price: $8.31 |
| 40 |
124028X |
SUB= 532124028 Price: Call Us |
| 40 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 44 |
17490412 |
SCREW HEX CRT Price: Call Us |
| 46 |
19091416 |
WASHER Price: Call Us |
| 62 |
10040500 |
LOCKWASHER Price: Call Us |
| 78 |
17490620 |
SCREW Price: Call Us |
| 81 |
128861 |
NUT Price: Call Us |
