| Ref | Part Number | Description |
|---|
| 1 |
06500810 |
NUT,NYL-FLG .50-13 GF ZCC This part replaces 06500010. Price: $1.45 |
| 2 |
06401015 |
WSHR,FLT .531X1.062X.095 ZCC This part replaces 06430200. Price: $0.95 |
| 3 |
07000031 |
BEARING, PEDESTAL Price: $74.45 |
| 4 |
09286251 |
WMT, MECHANICAL LIFT Price: $193.95 |
| 5 |
05901703 |
BLT,HEX .50-13X3.75 G5 ZCC This part replaces 05960100. Price: $5.45 |
| 6 |
09299651 |
LOCK-UP, MECH LIFT Price: $22.45 |
| 7 |
08319000 |
SG-TENS .162X1.25X8.25 WLD 25 Price: $29.95 |
| 8 |
09291500 |
WMT, MECH. LIFT SHAFT (.62) Price: $134.95 |
| 9 |
09299451 |
WMT, MECH LIFT COVER Price: $40.45 |
| 10 |
06500726 |
NUT,NYL-FLG .38-16 GF ZCC This part replaces 06545500. Price: $1.45 |
| 11 |
07400126 |
SCR,TAP .375-16X.50 HWH TR ZCC This part replaces 07412900. Price: $1.45 |
| 12 |
05901817 |
BLT, HEX .38-16X3.25 G5 ZCC This part replaces 05961100. Price: $3.95 |
| 13 |
05709200 |
RG-RTNG-EXT .625X.050 Price: $2.45 |
| 14 |
01593500 |
PIN, SPRING BALL .375OD X 1.50 Price: $5.45 |
| 15 |
06401117 |
WSHR, FLT .630X1.005X.062 ZCC This part replaces 06436100. Price: $0.45 |
| 16 |
02988500 |
WMT, FOOT OPERATED DECK LIFT Price: $137.95 |
| 17 |
05707300 |
RG-RTNG-EXT 1.00X.078 Price: $2.95 |
| 18 |
05500034 |
BSHG,1.00ID X 1.125OD X 1.50LG Price: $6.45 |
| 19 |
06608900 |
KEY-WDRF .25X1.00 HRD #15 Price: $3.45 |
| 20 |
06443000 |
WSHR-FL-STL- 1.062X2.0X.134 YZ Price: $1.95 |
| 21 |
00441000 |
WMT, LH FRONT MOWER LIFT Price: $78.45 |
| 22 |
00481600 |
WMT, LH REAR LIFT ARM (100) Price: $59.45 |
| 23 |
05518400 |
BSHG-FLG .762X1.0X.580X1.48 NY Price: $4.45 |
| 24 |
06413400 |
WSHR-HDND-THRST .758X1.23X.031 Price: $2.95 |
| 25 |
05714600 |
RG-RTNG-EXT .689X.078 Price: $2.45 |
| 26 |
00481500 |
WMT, RH REAR LIFT ARM (100) Price: $66.45 |
| 27 |
04063000 |
ROD-LIFT ASSIST 16.35" This part replaces 00164700. Price: $37.45 |
| 28 |
06401008 |
WSHR-FLT .438X1.00X.083 ZCC This part replaces 06435900. Price: $1.45 |
| 29 |
05800001 |
PIN-ROLL .250X1.25 STNLESS STL Price: $2.95 |
| 30 |
05901711 |
BLT-HEX .38-16X1.00 G5 ZCC This part replaces 05948700. Price: $1.45 |
| 31 |
00270100 |
GRIP, PEDAL 1.50 X 3.00 Price: $3.45 |
| 32 |
05508900 |
BSHG-SLV .377X.624X.235 Price: $8.45 |
| 33 |
06500910 |
NUT-JAM .375-16 G2 ZCC This part replaces 06535900. Price: $0.95 |
| 34 |
06500914 |
NUT-LK-CTR-JAM .375-16 GB ZCC This part replaces 06537200. Price: $0.95 |
