| Ref | Part Number | Description |
|---|
| 1 |
104-0061 |
HYD HOSE ASM Price: $126.22 |
| 1 |
73900500 |
Nut, Flange 5/16-18 Price: Call Us |
| 2 |
104-0060 |
HYD HOSE ASM Price: $108.27 |
| 2 |
161415X550 |
Shield, Side, Outer L. H. Price: Call Us |
| 3 |
104-0059 |
HYD HOSE ASM Price: $139.13 |
| 3 |
8393J |
Pin, Stake, Depth Price: Call Us |
| 4 |
12000035 |
Ring, Klip Price: Call Us |
| 4 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 5 |
104-9335 |
MANIFOLD-BLOCK, LIFT Price: $2,281.99 |
| 5 |
180847 |
Bolt, Carriage 5/16-18 x 3/4 Price: Call Us |
| 6 |
340-86 |
FITTING-TEE Price: $35.23 |
| 6 |
8394J |
Spring Price: Call Us |
| 7 |
23-8910 |
STEM-BARB-90 Price: $153.60 |
| 7 |
8392J |
Bracket, Latch Price: Call Us |
| 8 |
109230X |
Spring, Depth Stake Price: Call Us |
| 8 |
354-79 |
CAP-DUST Price: $7.81 |
| 9 |
102326X550 |
Shield, Tine Price: Call Us |
| 9 |
59-7410 |
FITTING-DIAGNOSTIC Price: $36.39 |
| 10 |
72140508 |
Bolt 5/16-18 x 1 Price: Call Us |
| 10 |
98-3907 |
TUBE ASM Price: $74.32 |
| 11 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 11 |
73220500 |
Nut, Hex 5/16-18 Price: Call Us |
| 12 |
10040500 |
Washer, Lock 5/16 Price: Call Us |
| 12 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 13 |
104-0093 |
TUBE ASM Price: $55.82 |
| 13 |
72110510 |
Bolt, Carriage 5/16-18 x 1-1/4 Price: Call Us |
| 14 |
104-0062 |
HYD HOSE ASM Price: $91.33 |
| 14 |
124343X |
Bracket, Shield Tine Price: Call Us |
| 15 |
104-0055 |
HYD HOSE ASM Price: $236.75 |
| 15 |
161414X550 |
Shield, Side, Outer R.H. Price: Call Us |
| 16 |
73900400 |
Nut, Hex Flange 1/4-20 UNC Price: Call Us |
| 18 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 18 |
72040410 |
Bolt, Carriage 1/4-20 x 1-1/4 Gr. 5 Price: Call Us |
| 19 |
102701X |
Grip Price: Call Us |
| 20 |
73220600 |
Nut, Hex 3/8-16 Price: Call Us |
| 20 |
98-9742 |
VALVE-CONTROL, FLOW Price: $158.79 |
| 21 |
102156X |
Stake, Depth Price: Call Us |
| 21 |
340-143 |
ELBOW-SWIVEL, 90 DEG Price: $58.91 |
| 22 |
104-0054 |
HYD HOSE ASM Price: $203.13 |
| 22 |
74930632 |
Bolt, Hex 3/8-16 x 2 Price: Call Us |
| 23 |
340-1 |
FITTING-STRAIGHT Price: $10.19 |
| 23 |
4440J |
Hinge Price: Call Us |
| 24 |
72140404 |
Bolt, Carriage 1/4-20 x 1/2 Gr. 5 Price: Call Us |
| 25 |
340-110 |
FITTING-SWIVEL, 90 DEG Price: $49.98 |
| 25 |
6712 |
J Cap, Vinyl Price: Call Us 6712 J |
| 26 |
109227X |
Pad, Idler Price: Call Us |
| 26 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 27 |
102695X550 |
Shield, Leveling Price: Call Us |
| 28 |
120588X |
Pin, Hinge Price: Call Us |
| 29 |
104085X550 |
Shield, Side Price: Call Us |
| 32 |
73220400 |
Nut Fin Hex 1/4-20 UNC Price: Call Us |
