| Ref | Part Number | Description |
|---|
| 1 |
104-0085 |
TANK-OIL Price: $1,828.79 |
| 1 |
590025903 |
Tanks This part replaces 584280401. Price: $399.99 |
| 2 |
589997313 |
FUEL TANK ASSEMBLY LH EPA COMP This part replaces 584280301. Price: $399.99 |
| 2 |
68-6150 |
BREATHER Price: $27.22 |
| 3 |
592979103 |
Panel Controls This part replaces 529280202. Price: $27.99 |
| 3 |
61-2790 |
FILTER-SCREEN Price: $49.91 |
| 4 |
574514001 |
TIMER, SEAT Price: $79.99 |
| 4 |
94-9411 |
DIPSTICK Price: $42.51 |
| 5 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. This part replaces 586161801. Price: $19.99 |
| 5 |
98-3917-01 |
BRACKET-FILTER Price: $45.78 |
| 6 |
574455401 |
SWITCH, IGNITION, INDAK Price: $29.99 |
| 6 |
93-7498 |
PLUG-PLASTIC Price: $25.26 |
| 7 |
340-91 |
FITTING-STR Price: $36.83 |
| 7 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 582107602. Price: $24.99 |
| 8 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 8 |
574455501 |
KEY, IGNITION Price: $5.99 |
| 9 |
23-8910 |
STEM-BARB-90 Price: $153.60 |
| 9 |
531077202 |
CHOKE CABLE 48IN This part replaces 574206901. Price: $27.99 |
| 10 |
104-1433 |
STRAINER-SUCTION Price: $156.13 |
| 10 |
574207001 |
CABLE, THROTTLE, 46" Price: $29.99 |
| 11 |
353-508 |
PLUG-HH Price: $7.96 |
| 11 |
539132624 |
KNOB - SHIFT Price: $6.99 |
| 12 |
33104-020 |
SCREW-HHF Price: $2.07 |
| 12 |
575018103 |
CAP 3.5IN SEALED This part replaces 575018101. Price: $27.99 |
| 13 |
576978701 |
CAP, VINYL Price: $2.99 |
| 13 |
92-8020 |
ADAPTER-BREATHER Price: $10.50 |
| 14 |
539103178 |
CAP IGNITION NUT Price: $3.99 |
| 14 |
93-7588 |
COVER-TANK Price: $37.60 |
| 15 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 16 |
576979001 |
ASSEMBLY, VAPOR LINE Price: $29.99 |
| 16 |
93-7499 |
GASKET Price: $5.91 |
| 17 |
577150501 |
ASSEMBLY, FUEL LINE Price: $37.99 |
| 17 |
98-3931 |
HOSE-FORMED Price: $80.81 |
| 18 |
237-101 |
O-RING Price: $2.80 |
| 18 |
539912222 |
HOSE CLAMP Price: $2.99 |
| 19 |
353-550 |
PLUG-HYD, HH Price: $10.71 |
| 19 |
575436501 |
CLAMP, HOSE Price: $2.99 |
| 20 |
2412-93 |
CLAMP-R Price: $1.02 |
| 20 |
579411601 |
BATTERY, 12 V 300 AMP DRY This part replaces 539102436. Price: $129.99 |
| 21 |
510029902 |
BRACKET, BATTERY, BLK Price: $54.99 |
| 21 |
98-3923 |
OIL FILTER ASM Price: $405.79 |
| 22 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 22 |
577104002 |
BRACKET,FUEL VALVE, BLACK Price: $8.99 |
| 23 |
323-4 |
SCREW-HH Price: $1.02 |
| 23 |
510030001 |
BRACKET, BATTERY MOUNT Price: $44.99 |
| 24 |
33105-025 |
SCREW-HHF Price: $1.56 |
| 24 |
584648201 |
GROMMET.CHECK.FUEL This part replaces 576618201. Price: $3.99 |
| 25 |
539105245 |
RUBBER GROMMET Price: $3.99 |
| 25 |
63-8410 |
WASHER Price: $1.76 |
| 26 |
539105974 |
RUBBER GROMMET Price: $2.99 |
| 26 |
75-6870 |
HOSE-INLET, PUMP Price: $50.00 |
| 27 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 27 |
576927001 |
MOUNT, CANISATER, RT Price: $69.99 |
| 28 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 28 |
576926901 |
MOUNT, CANISTER, LT Price: $49.99 |
| 29 |
532414114 |
CANNISTER, CARBON Price: $54.99 |
| 30 |
525865401 |
FITTING, FUEL Price: $29.99 |
| 31 |
574235301 |
LOOM, SPLIT, CONVOLUTED Price: $2.99 |
| 32 |
522718701 |
CABLE, POSITIVE, 55" Price: $22.99 |
| 33 |
522710701 |
CABLE, NEG, 55" Price: $29.99 |
| 34 |
539102759 |
INSULATOR Price: $3.99 |
| 35 |
510064002 |
Hooks This part replaces 510064001. Price: $2.99 |
| 36 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 37 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 38 |
539114341 |
SCR #10-24 X 3/8 SKT HD BLK OX Price: $3.99 |
| 39 |
574822701 |
SCR #10-24 X .75 SKT HD BLK Price: $2.99 |
| 40 |
539990997 |
WING NUT 1/4 Price: $2.99 |
| 41 |
596040801 |
Hardware This part replaces 539976977. Price: $2.99 |
| 42 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539108120. Price: $1.99 |
| 43 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 44 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 510093601 |
HARNESS, |
MAIN WIRING Price: $149.99 510093601 |
