| Ref | Part Number | Description |
|---|
| 1 |
3296-19 |
NUT-HEX This part replaces 32146-11. Price: $0.65 |
| 1 |
483407 |
Decal, Danger-Spinning Blades Price: Call Us |
| 2 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 2 |
483406 |
Decal, Warning - Rotating Blades Price: Call Us |
| 3 |
3-6804 |
INPUT PULLEY Price: Call Us |
| 3 |
485403 |
Decal, Metalcraft - USA Price: Call Us |
| 4 |
271-102 |
BELT (SET OF 2) Price: $152.86 |
| 4 |
485656 |
Decal, Fuel Valve Position Price: Call Us |
| 5 |
3-7713 |
Shaft Price: Call Us |
| 5 |
482100 |
Decal, Traction Control Price: Call Us |
| 6 |
323-6 |
SCREW-HH Price: $0.66 |
| 6 |
483425 |
Decal, ROPS Price: Call Us |
| 7 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 7 |
483633 |
Decal, Seat Replacement Price: Call Us |
| 8 |
3-6888 |
Cover Price: Call Us |
| 8 |
483402 |
Decal, Warning - Belt Cover Price: Call Us |
| 9 |
484453 |
Decal, Scag Heavy Duty Commercial Price: Call Us |
| 10 |
3-6855 |
Cover Bracket Price: Call Us |
| 10 |
487000 |
Decal, Instrument Panel - Kawasaki FT-EFI Price: Call Us |
| 11 |
3-6801 |
KEY Price: $8.50 |
| 11 |
487001 |
Decal, Instrument Panel - Kawasaki FX & 24FT, Yamaha MX Price: Call Us |
| 12 |
302-14 |
VENT Price: $8.03 |
| 12 |
484134 |
Decal, Deck Height - LH Price: Call Us |
| 13 |
3-6792 |
Gear Box Price: Call Us |
| 13 |
484135 |
Decal, Deck Height - RH Price: Call Us |
| 14 |
485629 |
Decal, Tiger CatII Price: Call Us |
| 15 |
281-7 |
CAP-PIPE Price: $3.69 |
| 15 |
483199 |
DECAL, VELOCITY PLUS - 48 Price: Call Us |
| 16 |
3-1609 |
Shim Kit Price: Call Us |
| 16 |
485654 |
Decal, Seat Support Price: Call Us |
| 17 |
485521 |
Decal, Cutter Deck Belt Routing Price: Call Us |
| 18 |
3-6796 |
Gear Price: Call Us |
| 18 |
486285 |
Decal, STCII Replacement Parts Price: Call Us |
| 19 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 19 |
485551 |
Decal, Start/Drive Price: Call Us |
| 20 |
32120-72 |
RING-SNAP Price: $2.09 |
| 20 |
483405 |
Decal, Warning-Discharge Price: Call Us |
| 21 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 21 |
486203 |
Decal, Scag Price: Call Us |
| 22 |
254-78 |
BEARING-CONE Price: $12.22 |
| 22 |
486202 |
Decal, Scag Tiger Cat II Price: Call Us |
| 23 |
254-79 |
BEARING-ROLLER, CUP Price: $6.39 |
| 24 |
253-44 |
SEAL-OIL Price: $24.63 |
| 25 |
237-57 |
O-RING Price: Call Us |
| 27 |
3-1619 |
SHIM KIT Price: Call Us |
| 30 |
3-6794 |
Base Mount Price: Call Us |
| 31 |
3217-7 |
NUT-HEX Price: $0.28 |
| 32 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 33 |
3-6793 |
Gear Box Base Price: Call Us |
| 34 |
3-6795 |
Output Shaft Price: Call Us |
| 35 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 36 |
323-6 |
SCREW-HH Price: $0.66 |
| 37 |
3-6814 |
Pulley Price: Call Us |
| 38 |
3-6803 |
WASHER-ADJUSTING Price: $0.75 |
| 39 |
3-6802 |
PINION Price: Call Us |
| 40 |
3-6797 |
Bearing Housing Price: Call Us |
| 485522 |
Decal, |
Belt Routing (61V) Price: Call Us 485522 |
| 487420 |
Decal, |
Deck Height - LH Price: Call Us 487420 |
| 487421 |
Decal, |
Deck Height - RH Price: Call Us 487421 |
| 487567 |
Decal, |
Tiger Cat II- Black (use on black paint) Price: Call Us 487567 |
| 487568 |
Decal, |
Heavy Duty Commercial - Black (use on black paint) Price: Call Us 487568 |
