| Ref | Part Number | Description |
|---|
| 1 |
120-9090 |
HOOD ASM Price: $4,242.71 |
| 1 |
532170551 |
CONTROL.THROTTLE/CHOKE.BLACK Price: $24.99 |
| 2 |
120-9099-0P |
HOOD PIVOT ASM This part replaces 120-9099-03. Price: $341.70 |
| 2 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 3 |
114-3823 |
SEAL-BULB Price: $64.68 |
| 4 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 4 |
532137352 |
MUFFLER.LT.BRIGGS.14HP.IC/OHV Price: $39.99 |
| 5 |
121-1470 |
PIVOT-SCREEN Price: $28.37 |
| 6 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 7 |
120-4196-0P |
HOOD SUPPORT ASM This part replaces 120-4196-03. Price: $146.51 |
| 8 |
137-3101 |
SCREW-PLASTIC, HWH This part replaces 46-8092. Price: $0.59 |
| 9 |
65-5100 |
HANDLE-DOOR Price: $9.05 |
| 10 |
104-3590 |
SEAL-BULB Price: $37.82 |
| 11 |
104-3588-03 |
PIVOT-SCREEN Price: $32.46 |
| 12 |
94-5626 |
FLEXIBLE DRAW LATCH ASM Price: $42.59 |
| 13 |
104-3580 |
SEAL-CORNER, SCREEN Price: $32.63 |
| 13 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED This part replaces 532165291. Price: $8.99 |
| 14 |
32144-109 |
SCREW-THD Price: $1.29 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 15 |
120-8949-0P |
SUPPORT-HOOD, LH This part replaces 120-8949-03. Price: $51.81 |
| 16 |
104-8313 |
ROD-HOOD Price: $58.83 |
| 16 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 17 |
283-67 |
PIN-CLEVIS Price: $2.04 |
| 18 |
2412-134 |
CLAMP-R Price: $5.79 |
| 19 |
1-806003 |
PIN-COTTER This part replaces 3290-307. Price: $1.39 |
| 20 |
120-9096-03 |
SCREEN-HOOD, REAR Price: $87.01 |
| 21 |
120-9097-03 |
SCREEN-HOOD, TOP Price: $185.70 |
| 22 |
3229-1 |
BOLT-CARR Price: $3.39 |
| 23 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 24 |
117-2382 |
PLUG-PLASTIC Price: $0.69 |
| 25 |
120-9087 |
SEAL-FOAM Price: $1.77 |
| 25 |
532180945 |
NEEDS DESCRIPTION Price: Call Us |
| 26 |
32128-33 |
NUT-HF Price: $0.25 |
| 26 |
873920600 |
Nut Keps 3/8 - 24 UNF Price: $3.99 |
| 27 |
32104-4 |
SCREW Price: $0.47 |
| 28 |
321-4 |
SCREW-HH Price: $0.99 |
| 31 |
581289901 |
FUEL.TANK.ASM.NON-EPA This part replaces 532185534. Price: $44.99 |
| 32 |
119-0054 |
DECAL-HOOD Price: $50.72 |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532140527. Price: $22.99 |
| 33 |
104-7201 |
NUT-HF Price: $0.69 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 34 |
120-8948-0P |
SUPPORT-HOOD, RH This part replaces 120-8948-03. Price: $53.08 |
| 35 |
3269-4 |
RIVET-POP Price: $1.19 |
| 37 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 37 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 38 |
3274-65 |
SCREW-HSBH Price: $1.15 |
| 38 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 39 |
127-3707-0P |
SUPPORT-HOOD This part replaces 127-3707-03. Price: $22.24 |
| 41 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 44 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 46 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 62 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 72 |
596134201 |
Screws This part replaces 871070512. Price: $2.99 |
| 78 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 81 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 112 |
532003645 |
BUSHING OUTLET T This part replaces 532124952. Price: $3.99 |
