| Ref | Part Number | Description |
|---|
| 1 |
5-0743-03 |
SPRING-MOWER This part replaces 5-0743. Price: $188.53 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD This part replaces 532416480. Price: $69.99 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 2 |
62-7240 |
DISCONTINUED Price: Call Us |
| 3 |
62-7300 |
CHAIN Price: $9.30 |
| 4 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 5 |
282-4 |
SHACKLE Price: $32.98 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 6 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 7 |
92-1818-01 |
ARM-SPRING, TENSION This part replaces 92-1818. Price: $13.39 |
| 8 |
323-7 |
SCREW-HH Price: $0.65 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
3256-45 |
WASHER-FLAT Price: $0.28 |
| 11 |
83-7900 |
DISCONTINUED Price: Call Us |
| 12 |
76-0370 |
BOLT ASSY Price: $26.50 |
| 13 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
283-40 |
PIN-CLEVIS Price: $2.85 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532408219. Price: $34.99 |
| 17 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 18 |
62-7250 |
VINYL SLEEVE Price: $32.91 |
| 19 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 21 |
2412-112 |
CLAMP-R Price: $1.03 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532194845. Price: $14.99 |
| 23 |
322-4 |
SCREW-HH Price: $0.35 |
| 24 |
55-4300 |
DECAL-WARNING Price: $13.99 |
| 24 |
93-6696 |
DECAL-WARNING Price: $14.78 |
| 25 |
256-115 |
WASHER-THRUST Price: $1.90 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM This part replaces 532415987. Price: $8.99 |
| 26 |
92-1815 |
SHAFT-C.U. PIVOT Price: $59.70 |
| 27 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 28 |
3234-32 |
SCREW-HHF Price: $8.48 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
16-1089 |
DISCONTINUED Price: Call Us |
| 30 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 31 |
92-1812 |
SHAFT-PIVOT, LIFT Price: $51.90 |
| 32 |
283-75 |
PIN-CLEVIS Price: $1.56 |
| 33 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 34 |
93-6912 |
DISCONTINUED This part replaces 92-1822. Price: Call Us |
| 35 |
32104-6 |
SCREW-HH, TAP Price: $3.19 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 36 |
322-26 |
SCREW-HH Price: $2.36 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
| 532186094 |
STEERING |
WHEEL.PREM.2.BLK This part replaces 532193651. Price: $169.99 532186094 |
| 532193652 |
INSERT.CAP.STRG.WH.GRAY |
Price: $11.99 532193652 |
