Engine Assembly Type 5
Parts (71)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 111-9510-03 | BRACKET-LIGHT, REAR Price: $27.13 |
| 2 | 111-3710-03 | LIGHT GUARD Price: $40.41 |
| 2 | 530042088 | Muffler Spring Price: $1.99 |
| 3 | 111-6180 | LIGHT-INDICATOR, REAR Price: $144.50 |
| 3 | 530071391 | Kit-Spark Arrestor Price: $7.99 |
| 4 | 111-6179 | LIGHT-STOP/TAIL Price: $144.50 |
| 4 | 530015953 | Screw-Cylinder Price: $1.99 |
| 5 | 111-3760 | RED REFLECTOR Price: $4.20 |
| 5 | 952030249 | Spark Plug (RCJ 6Y) Price: $3.99 |
| 6 | 09470 | WASHER M5 X 10 X 1 ZN & PASS Price: $1.25 |
| 6 | 530071689 | Cylinder Price: Call Us |
| 7 | 530069616 | Gasket-Cyl./Carb.(kit) Price: $6.99 |
| 7 | ZDH1E020U | HEX HD SET SCREW M5*20 Price: $1.31 |
| 8 | 09430 | NUT M5 NYL INS T TYPE Price: $1.25 |
| 8 | 530047659 | Carb. Adaptor Price: $2.99 |
| 9 | 530016014 | Screw Price: $1.99 |
| 9 | ZCS1F025U | SOC.HD.CAP SCW.M6*25 Price: $1.38 |
| 10 | 09472 | WASHER-PLAIN Price: $1.25 |
| 10 | 530069616 | Gasket-Carb.(kit) Price: $6.99 |
| 11 | 530069754 | Kit - Carb. (WA-226) Price: $19.24 |
| 11 | 530069971 | Kit - Carb. (C1U-W7) Price: $17.28 |
| 11 | 530071630 | Kit - Carb. (C1U-W7D) Price: $27.99 |
| 12 | 530038747 | Choke Plate Mounting Price: $1.99 |
| 13 | 530038686 | Choke Shutter Price: $1.99 |
| 14 | 530052431 | Air Box Price: $1.99 |
| 15 | 530015887 | Screw Price: $1.99 |
| 16 | 530036569 | Plate - Filter Support Price: $1.99 |
| 17 | 530036575 | Air Filter Foam Price: $1.99 |
| 18 | 530036568 | Air Filter Cover Price: $1.99 |
| 19 | 530016349 | Screw Price: $1.99 |
| 20 | 530015852 | Spacer-Choke Price: $1.99 |
| 21 | 530015254 | Washer Price: $1.99 |
| 23 | 530029924 | Piston Ring Price: $4.99 |
| 24 | 530015162 | Piston Pin Retainer Price: $1.99 |
| 25 | 530069615 | Connecting Rod Ass'y. Price: $14.99 |
| 26 | 530069616 | Gasket-Cylinder(kit) Price: $6.99 |
| 27 | 530039163 | Ignition Module Price: $34.99 |
| 28 | 530016357 | Screw Price: $1.99 |
| 29 | 581425901 | SWITCH, GROUND WIRE This part replaces 530014662. Price: $1.99 |
| 30 | 530014663 | Assy-Leadwire Price: $5.99 |
| 32 | 530016381 | Screw-Nose Cone Price: $2.99 |
| 33 | 530016382 | Nut-Nose Cone Price: $2.99 |
| 34 | 530016386 | SCREW This part replaces 530015810. Price: $5.99 |
| 35 | 530069572 | Kit-Switch Price: $4.99 |
| 36 | 530027569 | Starter Handle Price: $1.99 |
| 37 | 530069232 | Kit - Rope Price: $3.99 |
| 38 | 530016080 | Screw Price: $1.99 |
| 39 | 530038604 | Drive Coupling Price: $1.99 |
| 40 | 530023817 | Starter Dog Spring Price: $1.99 |
| 41 | 530015941 | Retain. Ring-C'shaft Price: $1.99 |
| 42 | 530055728 | Outer Bearing Price: $6.99 |
| 43 | 530071615 | Kit-C'case Seal Price: $4.99 |
| 44 | 530032125 | Inner Bearing Price: $11.99 |
| 45 | 530056547 | Shroud Price: $8.99 |
| 46 | 530015886 | Screw Price: $1.99 |
| 47 | 530016386 | SCREW This part replaces 530015810. Price: $5.99 |
| 48 | 530054536 | Guard-Muffler Price: $1.99 |
| 49 | 530069616 | O-Ring-C'case(kit) Price: $6.99 |
| 50 | 530054753 | Assy-Crankshaft Price: $27.99 |
| 53 | 545221701 | FLYWHEEL ASSY This part replaces 530069886. Price: $8.99 |
| 54 | 530015828 | Washer-Flat Price: $1.99 |
| 55 | 530015775 | Screw Price: $1.99 |
| 56 | 530027523 | Retainer-Can Price: $2.99 |
| 58 | 545008010 | STARTER SPRING This part replaces 530042085. Price: $3.99 |
| 59 | 530071667 | Kit-Fan Hsg/Shroud Price: $5.44 |
| 60 | 530071731 | Kit-Module Spacer & Screws Price: $4.99 |
| 62 | 530016379 | Retainer Price: $2.99 |
| 63 | 530014347 | Assy-Fuel Cap Price: $4.99 |
| 64 | 530095646 | Assy-Fuel Pickup Price: $2.99 |
| 65 | 530069247 | Kit-Fuel Line (Small) Price: $3.99 |
| 66 | 530069216 | Kit-Fuel Line (Large) Price: $3.99 |
