| Ref | Part Number | Description |
|---|
| 1 |
131-1235 |
RIGHT DECK ASM Price: $2,726.27 |
| 1 |
631376 |
TUBE Price: Call Us |
| 1 |
952030249 |
Spark Plug (RCJ-6Y) Price: $3.99 |
| 2 |
112-1479 |
SKID-BUMPER, DECK Price: $95.09 |
| 2 |
530015953 |
Screw Price: $1.99 |
| 2A |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 3 |
3296-45 |
NUT-HEX Price: $3.79 |
| 3 |
530055191 |
Insulator-Heat Price: $1.99 |
| 3A |
631022 |
CLIP Price: $1.25 |
| 4 |
131-1231-01 |
PLATE-STIFFENER Price: $95.51 |
| 4 |
530055240 |
Screw Price: $1.99 |
| 4 |
631377 |
WELCH PLUG Price: Call Us |
| 5 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 5 |
530055241 |
Deflector-Muffler Price: $3.99 |
| 5 |
630735 |
SPRING Price: $1.25 |
| 6 |
132-9421 |
PULLEY-IDLER, FLAT This part replaces 110-9596. Price: $41.10 |
| 6 |
631378 |
FLOAT BOWL Price: $5.16 |
| 7 |
100-3102 |
WASHER-FLAT Price: $3.70 |
| 7 |
27136A |
DRAIN ASSY Price: $5.96 |
| 7 |
530016341 |
Screw-Muffler-Internal Price: $0.08 |
| 8 |
108-8076 |
V-BELT, DECK Price: $29.86 |
| 8 |
27554 |
GASKET Price: $1.05 |
| 9 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 9 |
530071458 |
Gasket-Baffle (kit) Price: $5.99 |
| 9 |
632527 |
FUEL FITTING This part replaces 631775. Price: $6.03 |
| 10 |
139-1039 |
LOW DRIVEN SPINDLE ASM This part replaces 119-4776. Price: $589.65 |
| 10 |
530071458 |
Gasket-Cylinder (kit) Price: $5.99 |
| 10 |
631379 |
O RING Price: Call Us |
| 11 |
32108-103 |
SCREW-FH Price: $0.68 |
| 11 |
530071457 |
Kit-Cylinder Price: $11.99 |
| 11 |
631620A |
CONTROL VALVE Price: $3.45 |
| 12 |
530019182 |
Grommet-Ign. Module Price: $1.99 |
| 12 |
631381 |
RET PLATE Price: Call Us |
| 12 |
69-9290 |
PAD-BUMPER Price: $9.52 |
| 13 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 13 |
530016357 |
Screw-Ignition Module Price: $1.99 |
| 13 |
650152 |
SCREW Price: $1.60 |
| 14 |
104-2250-01 |
SKID-SIDE Price: $116.02 |
| 14 |
530035505 |
Ignition Module Price: $29.99 |
| 14 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 15 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 15 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 16 |
131-1243 |
PLATE-SPINDLE Price: $62.97 |
| 16 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 16 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 17 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 17 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 17 |
631378 |
FLOAT BOWL This part replaces 631382. Price: $5.16 |
| 18 |
3290-343 |
PIN-HAIR Price: $0.76 |
| 18 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 18 |
631383 |
WASHER Price: $1.25 |
| 19 |
104-7529-01 |
BRACKET-CASTOR Price: $225.46 |
| 19 |
530071615 |
Kit-Crankcase Seal Price: $4.99 |
| 20 |
100-5623 |
DECAL-HOC Price: $20.17 |
| 20 |
530055728 |
Bearing-Outer Price: $6.99 |
| 21 |
100-5569 |
PIN-CLEVIS Price: $22.34 |
| 21 |
530015941 |
Retainer Ring-C'chaft Price: $1.99 |
| 22 |
104-7524 |
SHIM Price: $5.30 |
| 22 |
530016190 |
Spacer-Flywheel Price: $2.99 |
| 23 |
121-1720-01 |
BRACKET-FORK Price: $36.79 |
| 23 |
530015149 |
Washer Price: $1.99 |
| 24 |
3231-33 |
SCREW-CARR Price: $4.29 |
| 24 |
530047534 |
FLYWHEEL ASSY This part replaces 530039209. Price: $22.99 |
| 25 |
3233-4 |
SCREW-CARR Price: $1.90 |
| 26 |
106-2047 |
ROD-TENSION Price: $9.83 |
| 27 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 27 |
530032125 |
Bearing-Inner Price: $11.99 |
| 28 |
104-0858 |
BOLT-SHOULDER Price: $4.69 |
| 28 |
530012452 |
Assy-Crankshaft Price: $24.99 |
| 29 |
530071458 |
O-ring-C/case (kit) Price: $5.99 |
| 29 |
920242 |
WASHER-FLAT This part replaces 9202424. Price: $5.19 |
| 30 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 30 |
530012443 |
Cover-Crankcase Price: $5.99 |
| 31 |
325-7 |
SCREW-HH Price: $1.53 |
| 31 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 32 |
32120-72 |
RING-SNAP Price: $2.09 |
| 32 |
530071459 |
Foam-219mm (kit) Price: $4.99 |
| 33 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 33 |
530029182 |
Eyelet-Flange Price: $1.99 |
| 34 |
110-6128 |
IDLER ARM ASM Price: Call Us |
| 34 |
530071467 |
Kit-Rope Price: $4.99 |
| 35 |
32128-14 |
NUT-HF Price: $0.41 |
| 35 |
530049488 |
Handle-Starter Price: $1.99 |
| 36 |
530016326 |
Screw-Rope Price: $1.99 |
| 36 |
68-0090 |
SCREW-ADJUSTING Price: $7.49 |
| 37 |
139-1728 |
BOLT-HH FT This part replaces 9114524. Price: $1.29 |
| 37 |
530016240 |
Washer-Belleville Price: $1.99 |
| 38 |
107938 |
SPRING-EXTENSION Price: $9.99 |
| 38 |
530626605 |
Nut Price: $1.99 |
| 39 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 39 |
530402043 |
Spring-Return Cover Price: $2.99 |
| 40 |
530049313 |
Inlet Door Price: $4.99 |
| 40 |
9136144 |
SCREW-HWHTF Price: $6.29 |
| 41 |
530016279 |
Washer-Flat Price: $1.99 |
| 41 |
70-1160 |
WASHER Price: $3.59 |
| 42 |
530069817 |
Assy-Impeller Price: $12.99 |
| 43 |
530055106 |
Seal-Ring Price: $1.99 |
| 44 |
530016349 |
Screw Price: $1.99 |
| 45 |
530055101 |
Housing-Pulley Price: $6.99 |
| 46 |
545008011 |
KIT STARTER SPRING This part replaces 530042086. Price: $5.99 |
| 47 |
545150201 |
PULLEY STARTER This part replaces 530071466. Price: $8.99 |
| 48 |
530055102 |
Fan Housing Price: $14.99 |
| 49 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 50 |
530071459 |
Foam-365mm (kit) Price: $4.99 |
| 51 |
530071458 |
Kit-Gasket Price: $5.99 |
