| Ref | Part Number | Description |
|---|
| 1 |
105-9861 |
STEERING CYLINDER ASM Price: $1,317.06 |
| 1 |
532170690 |
TUBE HANDLE BAGGER This part replaces 532165249. Price: $7.14 |
| 3 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 3 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 4 |
532169916 |
HANDLE.BAGGER.W/LVRS.BLK.CRD Price: $9.99 |
| 4 |
74-5700 |
BEARING-NEEDLE, ROLLER Price: $27.84 |
| 5 |
32120-15 |
RING-SNAP, EXT Price: $1.20 |
| 5 |
874981024 |
SCREW.PAN.HEAD Price: $4.99 |
| 6 |
32120-76 |
RING-SNAP, EXT Price: $0.34 |
| 6 |
532750029 |
SCREW This part replaces 874981032. Price: $4.99 |
| 7 |
340-9 |
FITTING-HYD, STRAIGHT Price: $67.47 |
| 7 |
873401000 |
NUT Price: $6.99 |
| 8 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 8 |
532441543 |
COVER.PNT.BGR.CRD.WSLOTS.MS668 This part replaces 532181095. Price: $199.99 |
| 9 |
325-7 |
SCREW-HH Price: $1.53 |
| 9 |
872140418 |
Bolt Carriage 1/4-20 x 2.25d x Gr.5 Price: $7.99 |
| 10 |
106-9888 |
WASHER-FLAT Price: $0.49 |
| 10 |
583110201 |
TUBE.SUPPORT.BAGGER.CRD This part replaces 532181282. Price: $59.99 |
| 11 |
121-3101 |
MOTOR-PISTON Price: $2,639.96 |
| 11 |
532165719 |
BRACKET.SUPPORT.UPPER.BAG.CRD Price: $9.99 |
| 12 |
237-166 |
O-RING Price: $10.46 |
| 12 |
583173701 |
BRKT.PIVOT.LH.CRD This part replaces 532188848. Price: $7.99 |
| 13 |
104-5663 |
PINION-28T Price: $203.65 |
| 13 |
874760612 |
BOLT Price: $3.99 |
| 14 |
104-5664 |
GEAR-44T Price: $267.37 |
| 14 |
596564404 |
Bolts This part replaces 874520636. Price: $2.99 |
| 15 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 16 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 17 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 17 |
93-5268 |
NUT-LUG Price: $2.20 |
| 19 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 20 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 20 |
532188847 |
BRKT.PIVOT.RH.CRD Price: $7.99 |
| 21 |
32136-14 |
NUT-HST Price: $3.38 |
| 21 |
532406180 |
BAGGER.ASM.CRD.2007 Price: $129.99 |
| 22 |
532165781 |
BRKT.SIDE.BAG.CRD Price: $2.99 |
| 22 |
92-5836 |
WASHER Price: $5.34 |
| 23 |
110-4750 |
DRIVE AXLE ASM Price: $8,909.28 |
| 24 |
100-3796 |
SPACER-JOINT, BALL Price: $13.33 |
| 24 |
532165783 |
TUBE.PIVOT.BAG.CRD.BLACK Price: $22.99 |
| 25 |
353-989 |
PLUG-HEX, HOLLOW Price: $21.59 |
| 25 |
583211601 |
TUBE.FRONT.BAGGER.CRD This part replaces 532193705. Price: $84.99 |
| 26 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 27 |
115-9142 |
PIN-REAR AXLE Price: $103.95 |
| 28 |
532165787 |
GRIP.HANDLE.BLACK Price: $5.99 |
| 28 |
92-1765 |
WASHER-THRUST Price: $2.57 |
| 29 |
98-3867 |
WASHER-THRUST Price: $3.21 |
| 30 |
3296-68 |
NUT-LOCK, NI Price: $14.67 |
| 31 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 31 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 32 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 32 |
532126875 |
RIVET,DRILLED Price: $2.99 |
| 33 |
33114-025 |
SCREW-HH Price: $0.70 |
| 33 |
583448501 |
MULCHING.PLUG.92.CRD.NON-TEX This part replaces 532165571. Price: $19.99 |
| 34 |
532165570 |
HANDLE.MULCHER.92.CRD (2 2) Price: $44.99 |
| 35 |
532165572 |
PIN Price: $12.99 |
| 36 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 36 |
95-7541 |
PLATE-COVER Price: $89.04 |
| 37 |
104-2353 |
PIN-DOWEL Price: $2.17 |
| 37 |
532175401 |
Plug Support Bagger CRD Price: Call Us |
| 38 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 38 |
872010520 |
BOLT.5/16-18X2.5 Price: $4.99 |
| 39 |
340-98 |
FITTING-ELBOW, 90 DEG Price: $31.91 |
| 39 |
532416257 |
SEAL.BAGGER.CRD Price: $29.99 |
| 40 |
110-8829 |
SENDER-TEMPERATURE Price: $80.84 |
| 41 |
532169683 |
BRKT.VERT.ADJ.BAGGER.CRD Price: $4.99 |
| 43 |
532174083 |
PLUG, TUBING END Price: $5.99 |
| 46 |
872110510 |
BOLT.CARRIAGE.5/16-18 Price: $4.99 |
| 47 |
583211501 |
TUBE.UPPER.BAGGER.CRD This part replaces 532193704. Price: $279.99 |
| 50 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 51 |
529846601 |
SERVICE KIT LATCH.SPRING.BAGGE This part replaces 532199903. Price: $1.99 |
| 53 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 54 |
872110407 |
BOLT.CARRIAGE.1/4-20 X 7/8 This part replaces 872140406. Price: $3.99 |
