| Ref | Part Number | Description |
|---|
| 1 |
108-1641 |
DRIVESHAFT ASM Price: $717.02 |
| 1 |
532439822 |
SEAT.TH150.MS498.GRY.HUSQ.TEX Price: $159.99 |
| 2 |
322-9 |
SCREW-HH Price: $3.09 |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $11.99 |
| 3 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 4 |
119-6972 |
VARIABLE HYDRAULIC PUMP ASM Price: $3,033.39 |
| 5 |
43-0090 |
SCREW-HH Price: $8.05 |
| 6 |
340-156 |
FITTING-ELBOW 45 Price: $67.70 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
108-1679 |
HOSE-HYD Price: $120.18 |
| 7 |
589483501 |
SPRING.COMPRESS.SEAT.TAPERED Price: $7.99 |
| 8 |
140-6248 |
DAMPER This part replaces 76-8870. Price: $159.54 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 10 |
125-8822-0P |
PLATE-PUMP This part replaces 119-6971-03. Price: $12.30 |
| 10 |
596768801 |
KIT.PLATE.SEAT This part replaces 587232002. Price: $49.99 |
| 11 |
3234-38 |
SCREW-HHF Price: $3.33 |
| 12 |
32128-49 |
NUT-HHF Price: $1.04 |
| 13 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 14 |
108-1799-0P |
HOOP - GUARD This part replaces 108-1799-03. Price: $17.13 |
| 15 |
340-105 |
FITTING-ELBOW, 90 DEG Price: $39.67 |
| 16 |
32128-20 |
NUT-HF Price: $0.99 |
| 17 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 18 |
322-10 |
SCREW-HH Price: $0.70 |
| 19 |
321-9 |
SCREW-HH Price: $0.27 |
| 20 |
110-5323-03 |
BRACKET Price: $69.50 |
| 21 |
2411-41 |
ROD END-BALL JOINT Price: $40.28 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER Price: $2.99 |
| 22 |
115-5300 |
PROXIMITY SWITCH ASM Price: $137.95 |
| 23 |
117-0265 |
LEVER-PUMP Price: $74.01 |
| 24 |
33093-00 |
WASHER-FLAT Price: $0.70 |
| 25 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 26 |
32151-72 |
RING-RETAINING Price: $1.59 |
| 27 |
3230-6 |
BOLT-CARR Price: $0.59 |
| 28 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 40 |
595088102 |
Handles This part replaces 532197661. Price: $4.99 |
| 41 |
532198200 |
SPRING.LATCH.SEAT.TEX Price: $3.99 |
| 43 |
874760612 |
BOLT Price: $3.99 |
| 44 |
501051801 |
WASHER.WINGED.3/8ID.1.5OD Price: $3.99 |
| 46 |
588090401 |
BOLT.3/8-16X1;1.25OD.WSHR.SEMS Price: $5.99 |
