| Ref | Part Number | Description |
|---|
| 1 |
132-3777 |
STEERING CYLINDER ASM This part replaces 105-0411. Price: $781.15 |
| 1 |
144927 |
SUB= 125603X Price: Call Us |
| 2 |
115-9472 |
BEARING-CONE AND SEAL This part replaces 254-70. Price: $22.04 |
| 2 |
74760412 |
BOLT LT Price: Call Us |
| 3 |
115-9471 |
BEARING-CUP This part replaces 254-61. Price: $6.46 |
| 4 |
18-6320 |
WASHER-STEERING Price: $2.65 |
| 5 |
32136-9 |
NUT-HEX, SLOTTED Price: $7.44 |
| 6 |
3272-37 |
PIN-COTTER Price: $0.75 |
| 7 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 8 |
84-5300 |
NUT-JAM Price: $9.99 |
| 9 |
107-2553 |
ROD END ASM This part replaces 105-7841. Price: $150.07 |
| 10 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 12 |
74-3730 |
SPACER-SPINDLE, REAR Price: $5.06 |
| 13 |
72-9710 |
HUB-TIRE Price: $288.21 |
| 14 |
5-3934 |
BOLT-CASTER Price: $55.92 |
| 15 |
115-3275 |
KIT-SERVICE, CASTOR FORK This part replaces 93-2529-01. Price: $530.51 |
| 16 |
153664 |
SWITCH INTERLOCK Price: Call Us |
| 17 |
3296-67 |
NUT-LOCK, NI Price: $5.05 |
| 18 |
3217-12 |
NUT-HEX Price: $3.12 |
| 19 |
10090400 |
SUB= 10040400 Price: Call Us |
| 19 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 20 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 20 |
73350400 |
NUT Price: Call Us |
| 21 |
166181 |
HARNESS.ASM.LIGHT W/4152J Price: Call Us |
| 21 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 22 |
4152J |
HEADLAMP BULB Price: Call Us |
| 23 |
325-6 |
SCREW-HH Price: $1.42 |
| 24 |
99-1485-01 |
PLATE-ADAPTER, MOTOR Price: $41.54 |
| 25 |
165987 |
CABLE.BATTERY.CRD Price: Call Us |
| 25 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 26 |
166180 |
FUSE.15 AMP Price: Call Us |
| 26 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 27 |
73510400 |
NUT Price: Call Us |
| 27 |
99-1486-01 |
PLATE-ADAPTER Price: $35.80 |
| 29 |
160784 |
SWITCH.PLUNGER Price: Call Us |
| 30 |
140301 |
SWITCH IGN 4POS Price: Call Us |
| 31 |
124211X |
NUT IGNITION Price: Call Us |
| 32 |
141226 |
COVER KEY SWITCH Price: Call Us |
| 33 |
122147X |
KEY Price: Call Us |
| 40 |
166158 |
HARNESS.IGN.CRD.ELECT Price: Call Us |
| 41 |
71110408 |
BOLT HXHD FIN Price: Call Us |
| 42 |
131563 |
SUB= 154336 Price: Call Us |
| 43 |
145673 |
SUB= 146154 Price: Call Us |
| 44 |
73640400 |
NUT HXKEP 1/4X20 Price: Call Us |
| 48 |
140844 |
ADAPTER AMMETER Price: Call Us |
| 50 |
154959 |
PTO SWITCH.BLK Price: Call Us |
| 51 |
140405 |
RING RETAIN PTO Price: Call Us |
| 52 |
141940 |
PROTECTION LOOP Price: Call Us |
| 58 |
165943 |
BUZZER CRD Price: Call Us |
| 59 |
166299 |
SWITCH.FBI.CRD Price: Call Us |
| 65 |
17211008 |
SCREW Price: Call Us |
| 66 |
17490608 |
SCREW LT Price: Call Us |
| 70 |
166668 |
HARNESS.ENGINE Price: Call Us |
| 80 |
146685 |
HARNESS.CLUT.EVX. Price: Call Us |
