| Ref | Part Number | Description |
|---|
| 1 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 1 |
532132734 |
Cap, Fuel Tank Price: $17.99 |
| 2 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 2 |
532138392 |
Dash and Fuel Tank Assembly Price: $75.81 |
| 3 |
532123487 |
Clamp, Hose Price: $3.99 |
| 3 |
86-1480 |
WASHER Price: $4.82 |
| 4 |
104-2354-03 |
DISCONTINUED Price: Call Us |
| 4 |
532000295 |
FUEL LINE This part replaces 532008544. Price: $5.74 |
| 5 |
253-154 |
SEAL-OIL Price: $5.48 |
| 5 |
532008548 |
Line, Fuel Price: $2.99 |
| 6 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 6 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 873510400. Price: $2.69 |
| 7 |
532002751 |
Clip Line Fuel 13/32 Mtg Hole This part replaces 532124996. Price: $2.42 |
| 7 |
69-1530 |
HOUSING-SPINDLE Price: $227.62 |
| 8 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 8 |
734115201 |
WASHER - M6 This part replaces 819091216. Price: $1.99 |
| 9 |
95-4387 |
SPINDLE SHAFT ASM - CTR This part replaces 86-2340. Price: $155.61 |
| 10 |
138-6416 |
SPACER-SPINDLE, SHAFT This part replaces 69-6950. Price: $18.44 |
| 11 |
86-0010-03 |
BLADE-19" Price: $32.86 |
| 12 |
72-9361 |
CUP-SCALP, ANTI Price: $39.78 |
| 13 |
92-5816 |
BOLT-BLADE Price: $4.93 |
| 17 |
872110404 |
Bolt, Carriage 1/4-20 x 1/2 Grade 5 Price: $3.99 |
| 18 |
532131886 |
Support Assembly, Dash Price: $21.03 |
| 19 |
532134744 |
Brace, Cross Price: $9.17 |
| 20 |
817060408 |
Screw, Self-Tapping 1/4-20 x 1/2 Price: $3.99 |
