| Ref | Part Number | Description |
|---|
| 1 |
72-9300 |
Cover R.H Price: Call Us |
| 2 |
72-9230-01 |
BASE-CASE, GEAR This part replaces 72-9230. Price: $176.88 |
| 3 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 3 |
532404472 |
HUSQ.GRILLE.CROWN.LOGO This part replaces 532198509. Price: $14.99 |
| 4 |
51-3960 |
DECAL Price: $24.99 |
| 4 |
532404472 |
HUSQ.GRILLE.CROWN.LOGO This part replaces 532199348. Price: $14.99 |
| 5 |
32128-20 |
NUT-HF Price: $0.99 |
| 5 |
532408701 |
DASH.ASM.HUSQ.GT.E.RECT.W/CK Price: $54.99 |
| 6 |
532404883 |
IS ITO Price: $5.99 |
| 6 |
72-9240-01 |
BRACKET-EXTENSION This part replaces 72-9240. Price: $23.69 |
| 7 |
322-4 |
SCREW-HH Price: $0.35 |
| 7 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 8 |
68-9890-01 |
COVER-GEARBOX, FRONT This part replaces 68-9890. Price: $47.21 |
| 9 |
63-9750 |
MOUNT Price: $18.92 |
| 10 |
68-8560-03 |
BRACKET-GEARBOX This part replaces 68-8560. Price: $57.56 |
| 11 |
63-8410 |
WASHER Price: $1.76 |
| 12 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 13 |
93-6697 |
DECAL-LUBE This part replaces 70-2560. Price: $11.38 |
| 14 |
108-1370 |
GEARBOX REPLACEMENT KIT This part replaces 68-6810. Price: $862.61 |
| 14 |
532442396 |
HOOD.ASM.HUSQVARNA.GT.TEX.ORAN This part replaces 532411046. Price: $149.99 |
| 15 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 15 |
532198907 |
LENS.LH.TEX.GT.HUSQ.CL Price: $22.99 |
| 16 |
323-4 |
SCREW-HH Price: $1.02 |
| 17 |
63-9900 |
GEARBOX PULLEY ASM Price: $135.09 |
| 18 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 18 |
532408607 |
GRILL.ASM.HUSQ.TG/CRD.W/TRIM This part replaces 532404821. Price: $129.99 |
| 19 |
27-6140 |
BUSHING-LOCK, TAPER Price: $84.79 |
| 20 |
3231-27 |
SCREW-CARR Price: $0.54 |
| 21 |
3290-321 |
SCREW-HWH Price: $3.99 |
| 22 |
249-21 |
CLAMP-SLOTTED Price: $18.93 |
| 23 |
119-4762-01 |
COVER-BELT, LH This part replaces 72-9340. Price: $114.44 |
| 24 |
3296-28 |
NUT-LOCK, NI This part replaces 32128-7. Price: $0.61 |
| 25 |
3245-9 |
SCREW-SET, HSH Price: $0.81 |
| 25 |
532198906 |
LENS.RH.TEX.GT.HUSQ.CL Price: $32.99 |
| 34 |
580910801 |
PLATE.ENGINE.WELDED.CHASSIS This part replaces 532196125. Price: $59.99 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 37 |
532418673 |
FENDER.TLT.W/CPH.W/FW.ORANGE This part replaces 532404940. Price: $149.99 |
| 52 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 99 |
532415742 |
ROD.SPRING.BYPASS.K46.LT.Z This part replaces 532405903. Price: $7.99 |
| 130 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 138 |
532439747 |
HOLDER.CUP.LT.GREY This part replaces 532402954. Price: $4.99 |
| 150 |
532198512 |
AIR.DUCT.HOOD.TEX.GT.HUSQ Price: $29.99 |
| 152 |
531169901 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532199535. Price: $19.99 |
| 161 |
532439781 |
WINDOW.FUEL.LT.HUSQ.TEX.498 This part replaces 532409627. Price: $5.99 |
| 162 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 165 |
532196826 |
SUPPORT.TANK.REAR.W/TEX Price: $22.99 |
| 175 |
590607702 |
PLATE.PNT.CROSSMEMBER.HUSQ/PRE This part replaces 532196304. Price: $32.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $4.99 |
| 177 |
532195227 |
BUSHING, STEERING Price: $5.99 |
| 178 |
532199782 |
CARGO.ASM.NET.TXGT.W/C Price: $29.99 |
| 180 |
579841501 |
KITS.CHASSIS.WELD.SERVICE This part replaces 532195457. Price: $219.99 |
| 181 |
532403025 |
BUSHING.MNT.FEND.CRGO. Price: $4.99 |
| 182 |
532406859 |
DASH.LOWER.COMMON.12V.ADAPTOR This part replaces 532194787. Price: $84.99 |
| 183 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 194 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 195 |
532404137 |
PLUG.HOLE.DASH.LOWER.12V.BLK Price: $4.99 |
| 196 |
532414579 |
CONSOLE.ASM.DECKLFT.BL/RBT.TLT This part replaces 532402843. Price: $22.99 |
| 202 |
532403048 |
VENT.SIDE.HOOD.HUSQ.RH.GREY Price: $7.99 |
| 203 |
532403076 |
VENT.SIDE.HOOD.HUSQ.LH.GRAY Price: $7.99 |
| 204 |
532416615 |
VENT.ASM.TORPHD.HUSQGT.LOGO.CL This part replaces 532198904. Price: $16.99 |
| 205 |
532401709 |
SKIRT.HOOD.SIDE.HUSQ.RH.GREY Price: $6.99 |
| 206 |
532401711 |
SKIRT.HOOD.SIDE.HUSQ.LH.GREY Price: $5.99 |
| 207 |
532197198 |
BEZEL.RH.TEX.GT.HUSQ Price: $19.99 |
| 208 |
532197199 |
BEZEL.LH.TEX.GT.HUSQ Price: $17.99 |
| 209 |
532199130 |
INSERT.HEX.GRILL.HUSQ.GREY Price: $4.99 |
| 210 |
532199131 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 211 |
532199132 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 212 |
532199133 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 213 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD This part replaces 532156524. Price: $9.99 |
| 218 |
532196395 |
X-PIECE.HOOD.STOP.NON/ Price: $6.99 |
| 222 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 228 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 234 |
532404742 |
BUMPER.HOOD.TEX.HUSQVARNA Price: $5.99 |
| 235 |
596564201 |
Spacers This part replaces 532406129. Price: $4.99 |
