| Ref | Part Number | Description |
|---|
| 1 |
532190192 |
CONTROL.THROTTLE.BLACK This part replaces 532190259. Price: $27.99 |
| 1 |
98-9590 |
NUT-CAP Price: $3.86 |
| 2 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 2 |
98-9547 |
CAM-FUEL Price: $87.63 |
| 3 |
98-9548 |
WASHER Price: $3.49 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 4 |
98-9669 |
GEAR-PUMP, INJECTION Price: $86.00 |
| 5 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 This part replaces 532146699. Price: $19.99 |
| 5 |
98-9350 |
BOLT Price: $0.98 |
| 6 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 This part replaces 532146700. Price: $17.99 |
| 6 |
98-9511 |
STOPPER-FUEL, CAMSHAFT Price: $5.18 |
| 7 |
98-9383 |
DISCONTINUED Price: Call Us |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 8 |
98-9595 |
KEY-WOODRUFF Price: $2.04 |
| 9 |
98-9459 |
CAMSHAFT-FUEL Price: $159.71 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 10 |
98-9382 |
BEARING-BALL Price: $23.27 |
| 11 |
98-9657 |
CIRCLIP-SHAFT, GOVERNOR Price: $4.48 |
| 12 |
98-9381 |
BEARING-BALL Price: $21.66 |
| 13 |
98-9565 |
SCREW-SET Price: $2.66 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 14 |
98-9644 |
GOVERNOR SHAFT ASM Price: $527.54 |
| 15 |
98-9564 |
WASHER-THRUST Price: $5.01 |
| 16 |
98-9563 |
SLEEVE-GOVERNOR Price: $29.68 |
| 17 |
817060624 |
SCREW 3/8-16 X 1-1/2 Price: $4.99 |
| 17 |
98-9560 |
SHAFT-WEIGHT, GOVERNOR Price: $6.17 |
| 18 |
98-9692 |
ROLLER Price: $11.45 |
| 19 |
98-9559 |
GOVERNOR WEIGHT ASM Price: $105.15 |
| 20 |
98-9673 |
GEAR-GOVERNOR Price: $137.25 |
| 21 |
98-9562 |
HOLDER-GEAR, GOVERNOR Price: $61.49 |
| 22 |
98-9561 |
HOLDER-WEIGHT, GOVERNOR Price: $23.68 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 25 |
532190194 |
CHOKE.CONTROL.PUSH/PULL.BLACK This part replaces 532190260. Price: $37.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 32 |
532179124 |
FUEL CAP This part replaces 532181803. Price: $29.99 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 41 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 101 |
596433401 |
Nuts This part replaces 532163305. Price: $2.99 |
