| Ref | Part Number | Description |
|---|
| 1 |
580806502 |
SUPPORT.FRONT.TRANS.PNTX431 This part replaces 522460702. Price: $5.99 |
| 1 |
66-6370 |
LIFT ARM ASM Price: $430.43 |
| 2 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 2 |
539101721 |
HCS 5/16C X 2-3/4 Price: $3.99 |
| 3 |
32136-2 |
NUT-SHH Price: $3.55 |
| 3 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 4 |
21-3020-01 |
MOUNT-BALLJOINT, RH This part replaces 21-3020. Price: $178.87 |
| 4 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 5 |
21-1830 |
SPRING-EXTENSION Price: $34.62 |
| 5 |
596434201 |
Bolts This part replaces 539990637. Price: $3.99 |
| 6 |
325-25 |
Flat Washer Price: Call Us |
| 6 |
596238701 |
Washers This part replaces 539990118. Price: $3.99 |
| 7 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 7 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 539990122. Price: $2.99 |
| 8 |
3217-8 |
NUT-HEX Price: $1.34 |
| 8 |
539976938 |
CAPSCREW Price: $3.99 |
| 9 |
596584101 |
Nuts This part replaces 539991073. Price: $2.99 |
| 9 |
66-7150 |
ARM-PUSH, RH Price: $536.26 |
| 10 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 10 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 11 |
24-9510 |
PIN Price: $77.49 |
| 11 |
522706002 |
ROD, BYPASS, RT Price: $7.99 |
| 12 |
522706001 |
ROD, BYPASS, LT Price: $7.99 |
| 12 |
61-3610 |
WARNING DECAL Price: $16.67 |
| 13 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 13 |
522447402 |
HG_TRANS, ZT-2800 RT Price: $749.99 |
| 14 |
46-8840-01 |
SPRING-LIFT ARM This part replaces 46-8840. Price: $35.71 |
| 14 |
522447401 |
HG_TRANS, ZT-2800 LEFT Price: $749.99 |
| 15 |
5-1754 |
WASHER-FLAT Price: $2.17 |
| 15 |
510185102 |
EZT MOUNT, REAR, BLACK Price: $32.99 |
| 16 |
256-126 |
BUSHING Price: $9.36 |
| 16 |
510184103 |
SPACER TUBE, EZT, 11.08 Price: $32.99 |
| 17 |
3272-33 |
PIN-COTTER Price: $0.54 |
| 17 |
539112318 |
HG_EXPANSION TANK W/CAP 71354 Price: $49.99 |
| 18 |
23-1950-01 |
SUPPORT-REINFORCEMENT This part replaces 23-1950. Price: $69.64 |
| 18 |
522439801 |
HOSE ASSY Price: $34.99 |
| 19 |
324-4 |
SCREW-HH Price: $0.95 |
| 19 |
596238401 |
BOLT CUP HEAD SQUARE NECK BOLT This part replaces 539990074. Price: $2.99 |
| 20 |
3-7292 |
PIN-CLEVIS Price: $44.11 |
| 20 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 21 |
5-3126 |
PIN-LYNCH Price: $0.73 |
| 21 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 22 |
3241-7 |
SCREW-SQH This part replaces 324-12. Price: $3.39 |
| 22 |
539112308 |
BRAKE SWIVEL Price: $8.99 |
| 23 |
21-3750 |
SUPPORT PLT Price: $14.42 |
| 23 |
539101224 |
SPRING Price: $19.99 |
| 24 |
21-2860-01 |
PUSH ARM BRACKET ASM This part replaces 21-2860. Price: $154.46 |
| 24 |
596580601 |
Pins This part replaces 539976988. Price: $3.99 |
| 25 |
32121-84 |
PIN-SPIRAL Price: $1.29 |
| 25 |
596930401 |
Links This part replaces 510375401. Price: $6.99 |
| 26 |
21-2990 |
SHAFT-PIVOT Price: $227.21 |
| 26 |
596930701 |
Links This part replaces 510375402. Price: $5.99 |
| 27 |
32152-9 |
NUT-HEX Price: $7.99 |
| 27 |
522656101 |
ROD, MOTION CONTROL Price: $27.99 |
| 28 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 28 |
579764601 |
JOINT.HEIM.FEML.5/16.RH.THREAD This part replaces 539115729. Price: $7.99 |
| 29 |
21-2960 |
ARM-PUSH, LH Price: $519.38 |
| 29 |
596718601 |
Coupling This part replaces 539116689. Price: $2.99 |
| 30 |
21-2900-01 |
SPRING-TORSION, LH This part replaces 21-2900. Price: $566.83 |
| 30 |
588692502 |
ROD.END.MALE.LH.THREAD This part replaces 539116690. Price: $8.99 |
| 31 |
21-2890-01 |
SPRING-TORSION, RH This part replaces 21-2890. Price: $566.83 |
| 31 |
596040901 |
Hardware This part replaces 539990223. Price: $2.99 |
| 32 |
21-3050-01 |
LH BALL JOUNT MOUNT ASM This part replaces 21-3050. Price: $153.41 |
| 32 |
539113466 |
HG_FILTER, ZT4800 52114 Price: $32.99 |
| 33 |
596433601 |
Nuts This part replaces 539115617. Price: $2.99 |
| 33 |
86-8100-01 |
BALL JOINT ASM This part replaces 21-0160. Price: $137.53 |
| 34 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 35 |
21-3000-01 |
NUT-JAM, PUSH ARM This part replaces 21-3000. Price: $37.02 |
| 36 |
3-1365 |
CHAIN Price: $72.97 |
| 37 |
68-3270 |
BUMPER-RUBBER This part replaces 67-9800. Price: $37.99 |
| 38 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 39 |
5-2942 |
SHACKLE Price: $16.99 |
