| Ref | Part Number | Description |
|---|
| 1 |
322-6 |
SCREW-HH Price: $0.45 |
| 1 |
KM-11009-3028 |
GASKET-FLANGED BOL Not Available Price: |
| 2 |
32151-73 |
RING-CLIP Price: $2.59 |
| 2 |
KM-11060-2475 |
GASKET-THERMOSTA T Not Available Price: |
| 3 |
140-6248 |
DAMPER This part replaces 76-8870. Price: $159.54 |
| 3 |
KM-13107-2097 |
IMPELLER SHAFT Not Available Price: |
| 4 |
323-7 |
SCREW-HH Price: $0.65 |
| 4 |
KM-13107-2246 |
SHAFT-FAN PULLEY Not Available Price: |
| 5 |
94-8297 |
DISCONTINUED Price: Call Us |
| 6 |
237-161 |
O-RING Price: $6.06 |
| 6 |
KM-16142-2077 |
COVER-WATER PUMP Not Available Price: |
| 7 |
86-5590 |
DISCONTINUED Price: Call Us |
| 7 |
KM-16160-2139 |
HOUSING-THERMOSTAT UPP Not Available This part replaces KM-16160-2127. Price: |
| 8 |
3213-2 |
SCREW-HH Price: $1.90 |
| 8 |
KM-16160-6001 |
HOUSING-THERMOSTAT LOW Not Available Price: |
| 9 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 9 |
KM-39062-2098 |
HOSE-WATER UPPER Not Available This part replaces KM-39062-2084. Price: |
| 10 |
84-1380-03 |
ANCHOR-SPRING This part replaces 84-1380. Price: $75.43 |
| 10 |
KM-39062-2100 |
HOSE-WATER LOWER Not Available This part replaces KM-39062-2088. Price: |
| 11 |
32144-26 |
SCREW-FLOW, TAPTITE Price: $5.75 |
| 11 |
KM-39062-2101 |
HOSE-WATER PMP TO Not Available This part replaces KM-39062-2089. Price: |
| 12 |
76-9430-03 |
SPRING-EXTENTION This part replaces 76-9430. Price: $28.14 |
| 12 |
KM-41077-2064 |
ADAPTER-FAN Not Available Price: |
| 13 |
84-1480 |
HOSE-DAMPENER Price: $12.04 |
| 13 |
KM-49044-2067 |
WATER PUMP This part replaces KM-49044-2063. Price: $210.95 |
| 14 |
323-29 |
SCREW-HH Price: $0.42 |
| 14 |
KM-49054-2058 |
THERMOSTAT Not Available Price: |
| 15 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 15 |
KM-49063-0002 |
WATER PUMP SEAL This part replaces KM-49063-1054. Price: $19.60 |
| 16 |
3256-71 |
WASHER-FLAT Price: $0.81 |
| 16 |
KM-59011-2058 |
BELT-FAN Not Available Price: |
| 17 |
63-8410 |
WASHER Price: $1.76 |
| 17 |
KM-59041-2092 |
Fan Price: $63.32 |
| 18 |
3296-9 |
NUT-HEX Price: $0.25 |
| 18 |
KM-59051-2355 |
SPUR GEAR 25 T WA Not Available Price: |
| 19 |
322-10 |
SCREW-HH Price: $0.70 |
| 19 |
KM-59091-2054 |
PULLEY HALF Not Available Price: |
| 20 |
82-5180-03 |
CONTROL-PUMP This part replaces 82-5180. Price: $134.08 |
| 20 |
KM-59091-20559H |
PULLEY-COOLING FAN Not Available Price: |
| 21 |
63-9751 |
DISCONTINUED Price: Call Us |
| 21 |
KM-59256-2069 |
IMPELLER-WATER PUM Not Available Price: |
| 22 |
88-1470 |
DISCONTINUED Price: Call Us |
| 22 |
KM-59336-2078 |
HOUSING-WATER PUMP Not Available Price: |
| 23 |
86-3020 |
DISCONTINUED Price: Call Us |
| 23 |
KM-92026-2311 |
SPACER-FAN SHAFT Not Available Price: |
| 24 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 24 |
KM-92043-2237 |
PIN-IMPELLER SHAFT Not Available Price: |
| 25 |
3249-11 |
SCREW-MACHINE Price: $0.54 |
| 25 |
KM-92045-2191 |
BEARING-FAN SHAFT Not Available Price: |
| 26 |
29-6163 |
SWITCH-MICRO Price: $91.23 |
| 26 |
KM-92049-2111 |
OIL SEAL Not Available Price: |
| 27 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 27 |
KM-92170-1284 |
CLAMP-WATER HOSE Not Available Price: |
| 28 |
82-5280 |
SHAFT-PIVOT Price: $51.63 |
| 28 |
KM-92171-2056 |
CLAMP-WATER HOSE Not Available Price: |
| 29 |
251-259 |
BEARING-BALL Price: $13.67 |
| 29 |
KM-92180-2013 |
SHIM-HALF PULLEY 0 Not Available Price: |
| 30 |
322-7 |
SCREW-HH Price: $0.89 |
| 30 |
KM-92180-2014 |
SHIM-HALF PULLEY 1 Not Available Price: |
| 31 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 31 |
KM-92200-2134 |
WASHER IMPELLER Not Available Price: |
| 32 |
84-0750 |
DISCONTINUED Price: Call Us |
| 32 |
KM-92200-2135 |
WASHER 10.2X19X0.8 Not Available Price: |
| 33 |
86-5940 |
SPACER-BEARING, UPPER Price: $5.16 |
| 33 |
KM-130AB0812 |
FLANGE BOLT 8X12 Not Available This part replaces KM-130C0812. Price: |
| 34 |
323-47 |
SCREW-HH Price: $1.22 |
| 34 |
KM-130BA0625 |
Flanged Bolt, 6 x 25 This part replaces KM-130G0625. Price: $2.45 |
| 35 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 35 |
KM-130BA0635 |
BOLT-FLANGED,6X35 This part replaces KM-130G0635. Price: $0.59 |
| 36 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 36 |
KM-130BA0820 |
FLANGED BOLT 8X20 Not Available This part replaces KM-130G0820. Price: |
| 37 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 37 |
KM-130CA0830 |
FLANGED BOLT Not Available This part replaces KM-130G0830. Price: |
| 38 |
100-2592 |
SCREW-HHF This part replaces 66-9303. Price: $9.09 |
| 38 |
KM-130G0835 |
Bolt, Flanged Price: Call Us |
| 39 |
86-3040 |
COUPLER-LINE, DRIVE Price: $381.88 |
| 39 |
KM-130BA0845 |
FLANGED BOLT 8X45 Not Available This part replaces KM-130G0845. Price: |
| 40 |
253-43 |
SEAL-OIL Price: $31.16 |
| 40 |
KM-130BA0860 |
FLANGED BOLT 8X60 Not Available This part replaces KM-130G0860. Price: |
| 41 |
84-1330 |
DISCONTINUED Price: Call Us |
| 41 |
KM-130G0880 |
FLANGED BOLT Not Available Price: |
| 42 |
KM-315AA1000 |
HEX NUT 10MM Not Available This part replaces KM-315B1000. Price: |
| 43 |
84-1030 |
DISCONTINUED Price: Call Us |
| 43 |
KM-410AA1000 |
PLAIN WASHER 10MM Not Available This part replaces KM-410B1000. Price: |
| 44 |
84-0170-03 |
PULLEY-PTO This part replaces 84-0170. Price: $874.74 |
| 44 |
KM-461DA0800 |
Spring Washer, 8mm This part replaces KM-461F0800. Price: $1.99 |
| 45 |
251-314 |
BEARING-BALL Price: $102.23 |
| 45 |
KM-481J2800 |
CIRCLIP 8 Not Available Price: |
| 46 |
86-2830-03 |
PLATE-ADAPTER, MAIN This part replaces 86-2830. Price: $409.90 |
| 46 |
KM-551A0314 |
DOWEL PIN Not Available Price: |
| 47 |
88-1440 |
WASHER-LOCK Price: $14.32 |
| 48 |
88-1430 |
LOCKNUT-BEARING Price: $30.40 |
| 49 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 50 |
76-8640 |
STUD-TRACTION Price: $23.60 |
| 51 |
92-2581 |
DISCONTINUED Price: Call Us |
| 52 |
256-113 |
BUSHING-FLANGE Price: $5.58 |
| 53 |
75-5470 |
SPACER-BEARING Price: $3.06 |
| 54 |
3220-3 |
NUT-HJ Price: $0.28 |
| 55 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 56 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 57 |
3290-477 |
WASHER-CURVED Price: $0.79 |
| 58 |
324-4 |
SCREW-HH Price: $0.95 |
| 59 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 60 |
95-4352-03 |
BRACKET-NEUTRAL This part replaces 95-4352. Price: $101.92 |
| 61 |
95-4351 |
DISCONTINUED Price: Call Us |
| 62 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 63 |
76-9760 |
DAMPER-PIVOT Price: $96.95 |
| 64 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 65 |
80-7730 |
SPACER Price: $1.97 |
| 66 |
92-1351 |
DISCONTINUED Price: Call Us |
| 503216618 |
503216618 |
SCREW Price: $3.99 |
| 503718201 |
503718201 |
START/STOP SWITCH Price: $11.99 |
| 503852902 |
503852902 |
HANDLE Price: $59.99 |
| 503877901 |
503877903 |
THROTTLE TRIGGER This part replaces 503877901. Price: $7.99 |
| 503878001 |
503878001 |
THROTTLE LOCK Price: $4.99 |
| 503878501 |
503878501 |
WIRE Price: $14.99 |
| 503878601 |
544171701 |
THROTTLE CABLE This part replaces 503878601. Price: $19.99 |
| 503918101 |
503918101 |
LEVER Price: $5.99 |
| 503961302 |
503961302 |
SCREW SPACER Price: $3.99 |
| 503961401 |
503961401 |
VIBRATION DAMPER Price: $4.99 |
| 503995501 |
503995501 |
HSG THROTTLE RH Price: $9.99 |
| 503995601 |
503995601 |
HANDLE HALF HSG LH Price: $9.99 |
| 537011301 |
537011301 |
SPRING Price: $4.99 |
| 537073902 |
537073902 |
VIBRATION ABSORBER Price: $5.99 |
