Engine Assembly (22 & 24 HP Briggs & Stratton)

Engine Assembly (22 & 24 HP Briggs & Stratton)

Parts (21)

RefPart NumberDescription
1 98-9358 DISCONTINUED Price: Call Us
2 98-9538 BASE-FILTER Price: $48.81
3 98-7527 O-RING Price: $1.48
4 98-9646 GASKET-PAN, OIL Price: $43.44
5 98-9685 PAN-OIL Price: $337.48
6 98-9350 BOLT Price: $0.98
7 98-9399 GASKET Price: $2.14
8 98-9686 PLUG-DRAIN This part replaces 98-7523. Price: $14.50
9 98-7524 GASKET Price: $5.09
532180505 583389701 KIT.SVC.CLUTCH.ELE.180505 This part replaces 532180505. Price: $299.99
539107476 539107476 BOLT 3/8-16 X 1.0 Price: $5.99
539108120 582478602 NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539108120. Price: $1.99
539110064 532126197 WASHER This part replaces 539110064. Price: $6.99
539110093 532428287 VALUE.OIL.DRAIN This part replaces 539110093. Price: $14.99
539110423 539110423 PULLEY Price: $24.99
539110425 587044805 HOSE.1/4".LOW.PERM.FUEL.LN.5" This part replaces 539110425. Price: $2.99
539912222 539912222 HOSE CLAMP Price: $2.99
539923388 539923388 HEX SCREW 7/16-20 X 3 Price: $2.99
539976938 539976938 CAPSCREW Price: $3.99
539990247 596238901 Washers This part replaces 539990247. Price: $2.99
539990546 595305901 Nuts This part replaces 539990546. Price: $2.99
