| Ref | Part Number | Description |
|---|
| 1 |
1-404257 |
DECK-SERVICE, 48 Price: $2,303.99 |
| 2 |
116-1729-01 |
BAFFLE-DOGLEG Price: $24.99 |
| 3 |
322-2 |
SCREW-HH Price: $2.29 |
| 4 |
32128-20 |
NUT-HF Price: $0.99 |
| 5 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 6 |
323-7 |
SCREW-HH Price: $2.69 |
| 7 |
3290-357 |
NUT-HHF, WHIZ Price: $0.79 |
| 8 |
98-5975 |
WASHER-BELLEVILLE Price: $3.09 |
| 9 |
1-808280 |
PIN-CLEVIS Price: $2.29 |
| 10 |
1-303105 |
YOKE-ADJUSTABLE Price: $11.99 |
| 11 |
109-0977 |
PULLEY,IDLER 5 Price: $74.99 |
| 12 |
32151-103 |
RING-RETAINING, EXT Price: $2.89 |
| 13 |
103-6583-S |
SPK, BLADE NOTCHED 16.25 This part replaces 103-6583. Price: $29.99 |
| 14 |
1-323174 |
ARM-LINKAGE, ASSIST Price: $28.99 |
| 15 |
323-13 |
SCREW-HH Price: $3.49 |
| 16 |
3296-42 |
NUT-LOCK, NI Price: $0.39 |
| 17 |
103-8387 |
ASM, CUTTER HOUSING OUTER Price: $522.99 |
| 18 |
702809 |
SCREW-HH Price: $4.79 |
| 19 |
32120-35 |
RING-RETAINING, EXT Price: $3.79 |
| 20 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 21 |
1-322235 |
ARM-ASSIST, 32/36 Price: $50.99 |
| 22 |
1-303434 |
BUSHING-ENGAGEMENT Price: $13.99 |
| 23 |
1-303348 |
EYEBOLT-THREAD, LH Price: $5.89 |
| 24 |
1-303236 |
BODY-TURNBUCKLE Price: $19.99 |
| 25 |
1-303238 |
EYEBOLT-THREAD, RH Price: $5.89 |
| 26 |
1-323747 |
SPRING-COMPRESSION Price: $2.99 |
| 27 |
1-806003 |
PIN-COTTER Price: $1.39 |
| 28 |
1-303352 |
WASHER-SPINDLE Price: $2.29 |
| 29 |
322-10 |
SCREW-HH Price: $0.79 |
| 30 |
1-303334 |
WASHER-SPRING Price: $2.29 |
| 31 |
103-3600 |
IDLER ARM ASM Price: $123.99 |
| 32 |
145-7145 |
SCREW-HSH,LOCK This part replaces 116-3515. Price: $3.09 |
| 33 |
302-19 |
FITTING-GREASE Price: $2.19 |
| 34 |
323-20 |
SCREW-HH Price: $3.29 |
| 35 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 36 |
109-5151 |
CHUTE DEFLECTOR XRK M056 Price: $50.99 |
| 37 |
1-403179 |
TUBE-PIVOT Price: $16.99 |
| 38 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 39 |
1-323714 |
ROD-BRAKE Price: $26.99 |
| 40 |
1-324372 |
PAD AND SPRING ASM Price: $65.99 |
| 41 |
3256-23 |
WASHER-PLAIN Price: $1.99 |
| 42 |
132-4718 |
PULLEY-IDLER, FLAT This part replaces 116-3626. Price: $30.99 |
| 43 |
1-403174-SL |
BELT,BLADE 48 WITH SLEEVE This part replaces 1-403174. Price: $87.99 |
| 44 |
1-323746 |
SPACER-FLANGED Price: $1.29 |
| 45 |
1-413113 |
BUSHING-IDLER Price: $5.29 |
| 46 |
109-8854 |
PIN-CHUTE Price: $14.99 |
| 47 |
1-323071 |
SPRING-EXTENSION Price: $14.99 |
| 48 |
116-8245 |
ASM-CASTER MNT W/WEIGHT Price: $677.99 |
| 49 |
321-4 |
SCREW-HH Price: $0.99 |
| 50 |
1-323748 |
RING-PUSH ON Price: $1.49 |
| 51 |
1-323417 |
WASHER Price: $2.89 |
| 52 |
323-4 |
SCREW-HH Price: $3.59 |
| 53 |
1-303537 |
STUD-SHIELD, BELT (SHORT) Price: $5.89 |
| 54 |
1-303536 |
STUD-SHIELD, BELT (LONG) Price: $7.09 |
| 55 |
1-323385 |
KNOB-3 PRONG Price: $4.89 |
| 56 |
1-402100-01 |
Shield Weldmt, 48" Price: Call Us |
| 56 |
116-2703 |
ASM,SHIELD W/DECALS 48 VIKING Price: $474.99 |
| 57 |
1-403188 |
SPACER Price: $13.99 |
| 58 |
323-6 |
SCREW-HH Price: $2.29 |
| 59 |
116-0962 |
SPRING, TORSION Price: $7.99 |
| 60 |
104-8301 |
NUT-HF, NI Price: $1.19 |
| 61 |
3219-2 |
NUT-HEX Price: $0.79 |
| 62 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 63 |
126-6891 |
DECAL, VIKING HYDRO MODEL Price: $9.99 |
| 64 |
106-5517 |
DECAL-WARNING Price: $4.79 |
| 66 |
103-2535 |
SPACER-GUARD, BOTTOM Price: $11.99 |
| 68 |
1-800861 |
SCREW-CAP, HH Price: $17.99 |
| 69 |
1-323539 |
SPACER Price: $2.09 |
| 70 |
1-513208 |
WASHER-SPRING Price: $8.29 |
| 71 |
1-323339 |
WASHER-RETAINER, SHEAVE Price: $4.79 |
| 72 |
1-807267 |
KEY Price: $2.29 |
| 74 |
3219-6 |
NUT-HEX Price: $3.69 |
| 76 |
103-8280 |
KIT, CUTTER HOUSING Price: $254.99 |
