| Ref | Part Number | Description |
|---|
| 1 |
106-0385 |
SEAL KIT Price: $230.04 |
| 1 |
159530 |
CHASSIS ASM Price: Call Us |
| 2 |
140356 |
SUB= 145009 Price: Call Us |
| 2 |
69-3770 |
SHIM Price: $51.82 |
| 3 |
107-4351 |
SPRING-RELIEF, CHARGE Price: $10.09 |
| 3 |
17490612 |
SCREW Price: Call Us |
| 4 |
19131216 |
WASHER Price: Call Us |
| 4 |
69-3800 |
VALVE Price: $39.31 |
| 5 |
107-4380 |
CPRV PLUG ASM Price: $52.04 |
| 5 |
155272 |
BUMPER-HOOD/DASH Price: Call Us |
| 6 |
155923 |
SADDLE Price: Call Us |
| 6 |
69-3130 |
PLUG This part replaces 107-4352. Price: $62.97 |
| 7 |
136-1026 |
PLUG ASM This part replaces 94-9415. Price: $9.75 |
| 8 |
155138 |
CLIP.RETAINER Price: Call Us |
| 8 |
69-3370 |
BEARING-NEEDLE Price: $49.67 |
| 9 |
147633X011 |
DASH SILKSCREEN Price: Call Us |
| 9 |
69-3230 |
PIN-SPRING Price: $24.22 |
| 10 |
69-3960 |
SCREW This part replaces 107-4353. Price: $5.90 |
| 10 |
72140608 |
SUB= 72110608 Price: Call Us |
| 11 |
75-0460 |
BEARING-BALL Price: $175.71 |
| 12 |
145660 |
CLIP.TINNERMAN Price: Call Us |
| 12 |
69-3200 |
RING-RETAINING Price: $20.29 |
| 13 |
69-3170 |
RING-RETAINING Price: $11.40 |
| 14 |
17490608 |
SCREW LT Price: Call Us |
| 14 |
94-2878 |
PIN Price: $9.76 |
| 15 |
69-3500 |
BEARING-SLEEVE Price: $472.61 |
| 15 |
74180512 |
SCREW Price: Call Us |
| 16 |
69-3450 |
PIN Price: $3.33 |
| 16 |
73510500 |
NUT Price: Call Us |
| 18 |
126938X |
SUB= 532126938 Price: Call Us |
| 18 |
69-3540 |
COVER-GEROTOR Price: $538.45 |
| 19 |
92-1352 |
PLUG Price: $30.00 |
| 20 |
107-4354 |
COVER-FRONT Price: $1,302.74 |
| 21 |
76-4590 |
SCREW Price: $5.43 |
| 22 |
69-3650 |
PISTON-SERVO Price: $852.55 |
| 23 |
107-4355 |
SWASHPLATE ASM Price: $1,223.29 |
| 24 |
74780616 |
BOLT Price: Call Us |
| 24 |
AU193488A1 |
JOURNAL This part replaces 107-4356. Price: $57.15 |
| 25 |
107-4357 |
SHAFT-PUMP Price: $1,045.25 |
| 25 |
19131312 |
WASHER Price: Call Us |
| 26 |
73800600 |
NUT Price: Call Us |
| 26 |
93-9320 |
PLATE-VALVE, LH This part replaces 107-4358. Price: $466.03 |
| 27 |
69-3390 |
GEROTOR ASM Price: $542.68 |
| 28 |
157428 |
GRILL Price: Call Us |
| 28 |
69-3550 |
PIN Price: $3.66 |
| 29 |
146654 |
LENS.EURO.W/DECAL Price: Call Us |
| 29 |
69-3430 |
KEY-WOODRUFF Price: $4.89 |
| 30 |
140001X428 |
FENDER ASM LT W/S Price: Call Us |
| 30 |
94-9414 |
ADAPTER-SUCTION Price: $211.04 |
| 31 |
136619 |
BRKT FENDER Price: Call Us |
| 31 |
94-9413 |
SCREW Price: $18.13 |
| 32 |
136-1026 |
PLUG ASM This part replaces 94-9415. Price: $9.75 |
| 33 |
145244X428 |
FOOTREST PNT LH Price: Call Us |
| 33 |
69-4040 |
STOP Price: $162.69 |
| 34 |
145243X428 |
FOOTREST.RH.LT/GT Price: Call Us |
| 34 |
69-3640 |
COVER-SERVO Price: $389.32 |
| 35 |
107-4359 |
GUIDE-SPRING Price: $44.64 |
| 35 |
72110606 |
BOLT Price: Call Us |
| 36 |
69-3680 |
STOP Price: $65.27 |
| 37 |
17490508 |
SCREW LT Price: Call Us |
| 37 |
69-3670 |
SPRING-SERVO Price: $194.02 |
| 38 |
107-4360 |
SCREW Price: $53.10 |
| 38 |
139886 |
BRACKET ASM LH Price: Call Us |
| 39 |
139887 |
BRACKET ASM RH Price: Call Us |
| 39 |
69-3580 |
GUIDE-SPRING Price: $142.64 |
| 40 |
69-3590 |
RING-RETAINING Price: $4.15 |
| 41 |
69-3600 |
NUT-HEX Price: $1.89 |
| 42 |
107-4361 |
NUT Price: $4.00 |
| 43 |
107-4362 |
SCREW Price: $10.69 |
| 44 |
69-3140 |
BRACKET Price: $30.30 |
| 45 |
107-4363 |
GASKET-COVER Price: $33.08 |
| 46 |
136-1026 |
PLUG ASM This part replaces 94-9415. Price: $9.75 |
| 47 |
136-1026 |
PLUG ASM This part replaces 94-9415. Price: $9.75 |
| 48 |
107-4364 |
BYPASS VALVE ASM Price: $166.69 |
| 49 |
69-3730 |
RELIEF VALVE KIT Price: $226.03 |
| 50 |
104-0168 |
BALL SWITCH KIT This part replaces 95-7034. Price: $87.16 |
| 51 |
107-4365 |
COVER-MOUNTING Price: $326.25 |
| 51 |
73800400 |
NUT Price: Call Us |
| 52 |
107-4366 |
GASKET-PLATE, MOUNTING Price: $25.49 |
| 52 |
19091416 |
WASHER Price: Call Us |
| 53 |
107-4367 |
PLATE-MOUNTING Price: $366.98 |
| 53 |
144697 |
BRACKET.GRILLE.LH Price: Call Us |
| 54 |
107-4368 |
SCREW Price: $5.82 |
| 54 |
17030814 |
SUB= 91817030814 Price: Call Us |
| 55 |
107-4369 |
GASKET-COVER, MOUNTING Price: $30.03 |
| 55 |
144696 |
BRACKET.GRILLE.RH Price: Call Us |
| 56 |
69-3860 |
SCREW Price: $3.87 |
| 57 |
107-4370 |
PLUG-EXPANSION Price: $6.00 |
| 57 |
74780412 |
SUB= 74780414 Price: Call Us |
| 58 |
107-4371 |
SPACER-SPRING Price: $18.92 |
| 58 |
150127 |
AIR DUCT Price: Call Us |
| 59 |
69-3860 |
SCREW Price: $3.87 |
| 60 |
107-4372 |
NUT-LOCK Price: $1.51 |
| 61 |
69-3880 |
SPRING-RETURN, NEUTRAL Price: $64.49 |
| 62 |
107-4373 |
HANDLE-CONTROL Price: $78.34 |
| 63 |
69-3890 |
BRACKET-RETURN, NEUTRAL Price: $60.82 |
| 64 |
107-4374 |
WASHER-LOCK Price: $0.81 |
| 65 |
107-4375 |
SPOOL BRACKET ASM Price: $857.43 |
| 66 |
69-3530 |
ORIFICE PLUG ASM Price: $137.05 |
| 67 |
107-4376 |
SLEEVE ASM Price: $874.40 |
| 68 |
75-0160 |
PLUG-PIPE Price: $4.39 |
| 69 |
69-3060 |
SCREW Price: $8.34 |
| 70 |
69-3410 |
ADAPTER-A, FLANGE Price: $516.81 |
| 71 |
107-4377 |
SEAL-A, PAD Price: $51.66 |
| 72 |
107-4378 |
COVER Price: $94.82 |
| 73 |
69-3400 |
SCREW Price: $1.29 |
| 74 |
107-4379 |
CYLINDER BLOCK KIT Price: $2,151.85 |
| 75 |
69-3920 |
PISTON RING AND O-RING KIT Price: $181.90 |
| 140 |
158418 |
BRKT SUSPENSION Price: Call Us |
