| Ref | Part Number | Description |
|---|
| 1 |
783-0250 |
HOOD-STY O W/LOUVERS Not Available Price: |
| 2 |
938-0952A |
Shoulder Bolt, .375 x .125 This part replaces 738-0952. Price: $6.17 |
| 8 |
753-06310 |
KIT-SERVICE FOR 731-1503A Not Available This part replaces 731-1503A. Price: |
| 9 |
912-3027 |
LOCK NUT 1/4 This part replaces 712-3027. Price: $3.85 |
| 10 |
783-04979 |
GRILL:2 STYLE Not Available This part replaces 783-0156A. Price: |
| 13 |
925-0963 |
Miniature Lamp 12V Socket Type This part replaces 725-0963. Price: $6.73 |
| 14 |
925-1651 |
SQ HEADLIGHT SOCKET Not Available This part replaces 725-1651. Price: |
| 15 |
710-0932A |
SCREW 1/4-20 x 1 GR5 This part replaces 710-0932. Price: $3.66 |
| 16 |
710-0599 |
Hx Wash. Hd. TT-Tap Scr. 1/4-20 x .5" L Price: $3.86 |
| 17 |
736-0173 |
Fl-Wash. .281" I.D. x .73" O.D. Price: $3.76 |
| 18 |
726-0233 |
Bolt Retainer 1/4" I.D. Price: $3.93 |
| 19 |
712-0185 |
SPEED NUT 1/4-20 Not Available Price: |
| 20 |
710-0118 |
Hex Bolt 5/16-18 x .75" Lg. Price: $3.76 |
| 22 |
731-1678 |
DASH - W/AMMETER & LIGHT SWITCH HOLES Not Available Price: |
| 24 |
925-0201 |
Key This part replaces 725-0201. Price: $8.70 |
| 25 |
746-0614A |
Choke Control Price: $22.93 |
| 26 |
N/A |
UNKNOWN |
| 28 |
720-0218 |
Shift Knob Price: $17.27 |
| 29 |
720-0166 |
THROTTLE KNOB Not Available Price: |
| 32 |
710-05177 |
CARRIAGE BOLT 1/4-20X.50" This part replaces 710-0167. Price: $4.26 |
| 34 |
17426A |
FENDER-RR Not Available Price: |
| 37 |
710-0924 |
Truss Mach. Scr. #1/4-20 x .75" Lg. Price: $4.02 |
| 38 |
710-0726 |
Hx Wash Hd. AB-Tap Scr. 5/16 x .75" L Price: $3.82 |
| 41 |
831-0823A |
Throttle Box Ass'y. Price: $30.59 |
| 42 |
710-0779A |
Truss Mach. AB-Tap Scr. #10 x .5" Lg. Price: $3.85 |
| 43 |
946-0634 |
Throttle Wire This part replaces 746-0634. Price: $10.24 |
| 49 |
732-0626 |
Ext. Spring 5.06" Lg. Price: $11.77 |
| 50 |
747-0750A |
DECK CONTROL ROD Not Available Price: |
| 51 |
726-0106 |
PUSH NUT This part replaces 7260106. Price: $3.37 |
| 52 |
710-1017 |
Torx Mach. Scr. 1/4 x .62" Lg. Price: $7.26 |
| 55 |
17500 |
LEVER-PTO Not Available Price: |
| 57 |
938-0155 |
Shoulder Bolt This part replaces 738-0155. Price: $6.01 |
| 58 |
712-3009 |
Hex L-Nut 5/16-18 Thd. Price: $5.99 |
| 59 |
925-1657A |
Safety Switch This part replaces 7251657A. Price: $22.57 |
| 62 |
17782 |
CLIP-CHOKE RETAINER Not Available Price: |
| 69 |
910-0224 |
HEX SCREW AB-TAP #10-16 x 0.500 This part replaces 710-1066. Price: $3.19 |
| 73 |
731-0511-81 |
Trim Strip 81" Lg. Price: $92.23 |
| 74 |
783-0151 |
SIDE PANEL (LH) Not Available Price: |
| 75 |
783-0150A |
SIDE PANEL (RH) Not Available Price: |
| 78 |
710-0286 |
Pan Hd. Mach. Scr. 1/4-20 x .5" Lg. Price: $3.86 |
| 79 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 80 |
920-0232 |
Knob This part replaces 720-0232. Price: $9.11 |
| 81 |
710-0642 |
Hex TT-Tap Scr. 1/4-20 x .75" Lg. Price: $4.05 |
| 82 |
710-0896 |
Hex Screw, 1/4-14 x 0.625" This part replaces 710-0776A. Price: $3.86 |
| 84 |
726-0211 |
U-Nut 5/16-18 Thd. Price: $3.90 |
