| Ref | Part Number | Description |
|---|
| 1 |
141295 |
Control Th/ch LH Flag 35.5 Price: Call Us |
| 1 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 2 |
139-2650 |
CYLINDER, HYD This part replaces 99-4262. Price: $608.23 |
| 2 |
17720410 |
Screw Hex Thd Cut 1/4-20x5/8 T Price: Call Us |
| 3 |
283-68 |
PIN-CLEVIS Price: $11.26 |
| 4 |
149723 |
Muffler Exhaust Price: Call Us |
| 4 |
99-4126 |
CENTER LIFT ARM ASM Price: $322.79 |
| 5 |
144069 |
Exhaust Asm. Left Price: Call Us |
| 6 |
144068 |
Exhaust Asm Right Price: Call Us |
| 6 |
98-2197 |
BUSHING-FLANGE Price: $1.82 |
| 7 |
138129 |
Clamp Tube Double Engine Price: Call Us |
| 7 |
99-4116 |
REAR LIFT FRAME ASM Price: $376.66 |
| 8 |
150176 |
Bolt 5/16-18 UNC x 3/4 W/Sems Price: Call Us |
| 8 |
69-8940 |
WASHER Price: $1.76 |
| 10 |
145552 |
Heat Shield LT Price: Call Us |
| 14 |
13280336 |
Nipple Pipe 3/8 Npt X 3" Price: Call Us |
| 15 |
13200300 |
Elbow Std 90 Degree 3/8-18 Npt Price: Call Us |
| 15 |
33096-00 |
WASHER-FLAT Price: $1.76 |
| 16 |
11050600 |
Washer Lock Ext Tooth 3/8 Price: Call Us |
| 16 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 17 |
17490624 |
Screw Thdrol 3/8-16 x 1-1/2 Tytt Price: Call Us |
| 17 |
95-1639 |
FITTING-STR,ORIF Price: $63.47 |
| 18 |
32120-72 |
RING-SNAP Price: $2.09 |
| 19 |
63-2290 |
WASHER-THRUST Price: $2.27 |
| 20 |
93-2258 |
HYD HOSE ASM Price: $43.64 |
| 21 |
94-3452 |
PIN Price: $10.04 |
| 22 |
94-8199 |
TUBE-PIVOT Price: $23.74 |
| 23 |
169837 |
Shield Browning/Debris Guard Price: Call Us |
| 23 |
3296-53 |
NUT-LOCK, NI Price: $1.47 |
| 24 |
327-19 |
SCREW-HH Price: $8.70 |
| 25 |
145996 |
Control Choke Price: Call Us |
| 26 |
73920600 |
Nut Keps 3/8-24 UNF Price: Call Us |
| 26 |
94-3477 |
HYD HOSE ASM Price: $65.92 |
| 27 |
152927 |
Screw TT Flange Price: Call Us |
| 28 |
3218-5 |
NUT-JAM Price: $0.27 |
| 29 |
137180 |
Kit Spark Arrestor (Flat Scrn) Price: Call Us |
| 29 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 30 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 31 |
151346 |
Tank Fuel Front Price: Call Us |
| 32 |
140527 |
Cap Asm Fuel Price: Call Us |
| 32 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 33 |
123487X |
Clamp Hose Price: Call Us |
| 33 |
32144-69 |
SCREW-HWHTF Price: $1.58 |
| 34 |
106082X |
Strip Foam Price: Call Us |
| 34 |
325-5 |
SCREW-HH Price: $1.20 |
| 35 |
93-7489 |
ORIFICE VALVE ASM Price: $191.40 |
| 36 |
99-4248 |
SPACER Price: $6.58 |
| 37 |
8543R |
Line Fuel Price: Call Us |
| 37 |
95-2927 |
FITTING-ELBOW 90 Price: $97.89 |
| 38 |
125-5222 |
BUSHING-ECCENTRIC, MACHINED This part replaces 98-4618. Price: $44.55 |
| 39 |
109227X |
Pad Spacer Price: Call Us |
| 39 |
3256-74 |
WASHER-FLAT Price: $0.27 |
| 40 |
33114-016 |
SCREW-HH Price: $0.27 |
| 40 |
3645J |
Bushing Price: Call Us |
| 41 |
139277 |
Stem Tank Fuel Price: Call Us |
| 41 |
99-4072 |
SPACER Price: $23.67 |
| 42 |
99-4111-01 |
PLATE-TRANSPORT, 1 AND 3 Price: $49.03 |
| 43 |
99-4225 |
PAD-WEAR Price: $10.18 |
| 44 |
325-7 |
SCREW-HH Price: $1.53 |
| 45 |
17000612 |
Screw Hex Wsh Thdrol 3/8-16 x 3/4 Price: Call Us |
| 45 |
99-4201 |
TUBE-SPACER Price: $10.91 |
| 46 |
99-4246 |
LINK BRACKET ASM Price: $62.27 |
| 48 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 49 |
3250-17 |
SCREW-PPH Price: $1.76 |
| 50 |
325-14 |
SCREW-HH Price: $2.64 |
| 51 |
3296-54 |
NUT-LOCK Price: $3.59 |
