| Ref | Part Number | Description |
|---|
| 1 |
545008010 |
STARTER SPRING This part replaces 530029395. Price: $7.99 |
| 1 |
60-3800 |
COUPLING Price: $131.07 |
| 2 |
530015775 |
SCREW 8-16 X 9/16 (PLAS Price: $2.99 |
| 2 |
60-3810 |
SHAFT Price: $412.07 |
| 3 |
530027523 |
RETAINER Price: $3.99 |
| 3 |
60-3820 |
SPINDLE Price: $1,516.53 |
| 4 |
530015934 |
SCREW Price: $2.99 |
| 4 |
60-3830 |
SEAL Price: $60.55 |
| 5 |
503789101 |
STARTER HANDLE Price: $3.83 |
| 5 |
60-3840 |
CONE Price: $163.95 |
| 6 |
530016386 |
SCREW This part replaces 530015810. Price: $4.99 |
| 6 |
60-3850 |
CUP Price: $109.74 |
| 7 |
60-3860 |
BOLT Price: $8.48 |
| 8 |
503235112 |
BPMR6A NGK SPARK PLUG This part replaces 952030201. Price: $8.99 |
| 8 |
60-3870 |
DISCONTINUED Price: Call Us |
| 9 |
60-3880 |
CONE Price: $179.96 |
| 10 |
530015945 |
CLIP Price: $2.99 |
| 10 |
60-3890 |
BOLT Price: $3.11 |
| 11 |
530047278 |
LEAD WIRE ASSEMBLY Price: $8.99 |
| 11 |
60-3910 |
WASHER Price: $1.35 |
| 12 |
503789001 |
CHOKE KNOB Price: $1.99 |
| 12 |
60-3980 |
WASHER Price: $0.27 |
| 13 |
545221701 |
FLYWHEEL ASSY This part replaces 530069886. Price: $24.99 |
| 13 |
62-6430 |
GEAR Price: $142.98 |
| 14 |
530039163 |
IGNITION MODULE Price: $37.99 |
| 14 |
60-4070 |
BOLT Price: $0.73 |
| 15 |
530036145 |
SPACER - IGNITION MODULE Price: $3.99 |
| 15 |
62-6410 |
DISCONTINUED Price: Call Us |
| 16 |
530015954 |
SCREW Price: $2.99 |
| 16 |
60-4040 |
PLUG Price: $11.10 |
| 17 |
530015149 |
WASHER Price: $2.99 |
| 17 |
60-4030 |
BOLT Price: $1.36 |
| 18 |
530037705 |
DRIVE COUPLING Price: $5.99 |
| 18 |
60-4060 |
COVER Price: $9.99 |
| 19 |
114-5060 |
COVER KIT This part replaces 60-4050. Price: $421.50 |
| 19 |
530014864 |
CRANKSHAFT ASSEMBLY Price: $17.99 |
| 20 |
530069615 |
CONNECTING ROD ASSEMBLY Price: $19.99 |
| 20 |
62-6420 |
DISCONTINUED Price: Call Us |
| 21 |
545154001 |
RING PISTON This part replaces 530049903. Price: $3.99 |
| 21 |
60-4020 |
RING Price: $1.54 |
| 22 |
60-4010 |
PLUNGER Price: $28.33 |
| 23 |
530032125 |
BEARING Price: $8.99 |
| 23 |
60-3990 |
WASHER-THRUST Price: $10.52 |
| 24 |
530032124 |
BEARING Price: $5.99 |
| 24 |
60-3900 |
GEAR Price: $1,114.65 |
| 25 |
530019179 |
SEALING RING Price: $4.99 |
| 25 |
82-8700 |
RING Price: $1.97 |
| 26 |
530015941 |
RETAINING RING Price: $2.99 |
| 26 |
60-3940 |
WASHER Price: $4.07 |
| 27 |
530036578 |
MUFFLER BODY Price: $3.99 |
| 27 |
60-3950 |
SPRING Price: $8.11 |
| 28 |
530036577 |
MUFFLER COVER Price: $2.99 |
| 29 |
530049489 |
MUFFLER BAFFLE Price: $1.99 |
| 29 |
60-3930 |
RING Price: $0.27 |
| 30 |
530036579 |
MUFFLER BAFFLE - FIRST Price: $2.99 |
| 31 |
530016197 |
SPRING Price: $3.99 |
| 32 |
530038466 |
REAR SHROUD Price: $7.99 |
| 34 |
582144301 |
SERVICE KIT CYLINDER 25CC This part replaces 530069757. Price: $54.99 |
| 35 |
530069758 |
CARB ADAPTOR KIT Price: $9.99 |
| 36 |
530016014 |
SCREW - CARB. ADAPTOR Price: $2.99 |
| 38 |
530071639 |
CARBURETOR This part replaces 530069902. Price: $59.99 |
| 39 |
530038465 |
AIR BOX Price: $4.99 |
| 40 |
530037326 |
CHOKE PLATE Price: $2.99 |
| 41 |
503788901 |
CHOKE SHUTTER Price: $1.99 |
| 42 |
530015254 |
WASHER Price: $2.99 |
| 43 |
530015852 |
CHOKE SPACER Price: $2.99 |
| 44 |
530015849 |
SCREW Price: $3.99 |
| 45 |
530037413 |
FILTER PLATE Price: $2.99 |
| 46 |
530037331 |
AIR FILTER FOAM Price: $2.99 |
| 47 |
530038692 |
AIR FILTER COVER Price: $1.99 |
| 48 |
530015957 |
SCREW This part replaces 530015966. Price: $2.99 |
| 49 |
530049826 |
THROTTLE CABLE. Price: $7.99 |
| 50 |
530049413 |
FUEL TANK This part replaces 530047257. Price: $13.99 |
| 51 |
530038874 |
AIR PURGE BUBBLE Price: $6.99 |
| 52 |
530015780 |
SCREW 6-19X5/8 PLAS.PAN This part replaces 530016090. Price: $2.99 |
| 53 |
530038463 |
CAP - FAN HOUSING Price: $2.61 |
| 54 |
530015880 |
SCREW Price: $2.99 |
| 55 |
530014347 |
CAP ASSY W/ RETAINER Price: $7.99 |
| 56 |
530095646 |
FUEL PICK-UP ASSY This part replaces 530014362. Price: $5.99 |
| 57 |
530036792 |
CRANKCASE ISOLATOR Price: $5.99 |
| 58 |
530023817 |
SPRING STR DOG Price: $3.99 |
| 59 |
530015953 |
SCREW Price: $3.99 |
| 60 |
530015767 |
SCREW-10-24 X 1-3/8 (UN Price: $2.99 |
| 61 |
530015768 |
LOCKNUT-HEX 10-24 Price: $3.99 |
| 62 |
530071393 |
KIT FAN HSG CLUTCH This part replaces 530047292. Price: $14.99 |
| 63 |
530069232 |
KIT-ROPE Price: $4.99 |
| 64 |
530016080 |
SCREW Price: $2.99 |
| 65 |
530071786 |
STARTER PULLEY KIT This part replaces 530069400. Price: $9.99 |
| 66 |
530069380 |
KIT-SPARK ARRESTOR (OLD STYLE) Price: $4.99 |
| 67 |
530015162 |
WRIST PIN RET. Price: $2.99 |
| 71 |
530049678 |
Starter Dog Price: $1.67 |
| 72 |
530047293 |
Clutch Hsg. Price: $19.23 |
| 73 |
530069491 |
CLUTCH ASSEMBLY KIT Price: $8.99 |
| 74 |
530015611 |
FRICTION DISC,CLUTCH 36/41 Price: $4.99 |
| 75 |
530015828 |
WASHER FLAT Price: $2.99 |
| 76 |
530626605 |
NUT Price: $4.99 |
| 77 |
530015886 |
SCREW-10-14 X 13/16 (PL Price: $2.99 |
| 78 |
530069571 |
FUEL LINE - PRIM/TNK Price: $4.99 |
| 80 |
530036793 |
SHROUD ISOLATOR Price: $6.99 |
| 81 |
530069380 |
KIT-SPARK ARRESTOR (OLD STYLE) This part replaces 530037045. Price: $4.99 |
