| Ref | Part Number | Description |
|---|
| 1 |
159530 |
CHASSIS ASM Price: Call Us |
| 2 |
140356 |
SUB= 145009 Price: Call Us |
| 3 |
17490612 |
SCREW Price: Call Us |
| 6 |
155924X012 |
SADDLE Price: Call Us |
| 9 |
145203 |
DASH.PLASTIC.BLK Price: Call Us |
| 10 |
108-1417 |
PISTON (+0.5MM) Price: $271.74 |
| 10 |
72140608 |
SUB= 72110608 Price: Call Us |
| 10 |
98-9550 |
PISTON (STD) Price: $274.67 |
| 11 |
145218 |
PANEL.DASH.LH. Price: Call Us |
| 13 |
145223 |
PANEL.DASH.RH.NOT Price: Call Us |
| 17 |
123801X505 |
HOOD.ASM.YTGT.PNT Price: Call Us |
| 18 |
126938X |
SUB= 532126938 Price: Call Us |
| 20 |
108-1404 |
PISTON RING ASM (+0.5MM) Price: $222.07 |
| 20 |
98-9551 |
PISTON RING ASM (STD) Price: $220.34 |
| 24 |
74780616 |
BOLT Price: Call Us |
| 25 |
19131312 |
WASHER Price: Call Us |
| 26 |
73800600 |
NUT Price: Call Us |
| 28 |
140671 |
GRILLE ASM WELD Price: Call Us |
| 29 |
110898X |
LENS T Price: Call Us |
| 30 |
109872X505 |
FENDER Price: Call Us |
| 30 |
98-9513 |
PIN-PISTON Price: $13.17 |
| 31 |
136619 |
BRKT FENDER Price: Call Us |
| 33 |
105476X505 |
FOOTREST LH Price: Call Us |
| 34 |
105475X505 |
FOOTREST RH Price: Call Us |
| 35 |
72110606 |
BOLT Price: Call Us |
| 36 |
108067X |
PAL NUT LT Price: Call Us |
| 38 |
139886 |
BRACKET ASM LH Price: Call Us |
| 39 |
139887 |
BRACKET ASM RH Price: Call Us |
| 40 |
98-9514 |
CIRCLIP-PIN, PISTON Price: $2.79 |
| 45 |
132257 |
SUB= 918132257 Price: Call Us |
| 50 |
117-7586 |
CONNECTING ROD ASM This part replaces 98-9552. Price: $547.99 |
| 59 |
110436X |
SUB= 9151R Price: Call Us |
| 60 |
115-3014 |
BUSHING-PIN, PISTON This part replaces 98-9515. Price: $19.81 |
| 64 |
150272 |
DASH.LOWER.LT Price: Call Us |
| 66 |
156277X011 |
PLATE SLKSCR.OM Price: Call Us |
| 70 |
98-9517 |
BOLT-ROD, CONNECTING Price: $10.31 |
| 71 |
73640400 |
NUT HXKEP 1/4X20 Price: Call Us |
| 72 |
110350X505 |
STRAP GRILLE 505 Price: Call Us |
| 80 |
117-7588 |
METAL-CRANKPIN (-0.4MM) This part replaces 108-1406. Price: $49.06 |
| 80 |
98-9519 |
BEARING-ROD (-0.2MM) This part replaces 108-1405. Price: $43.73 |
| 80 |
98-9553 |
BEARING-ROD (STD) Price: $52.92 |
| 86 |
123764X505 |
PANEL.SIDE.RH.ASM Price: Call Us |
| 87 |
123765X505 |
PANEL.SIDE.LH.ASN Price: Call Us |
| 90 |
19091216 |
WASHER PM Price: Call Us |
| 90 |
98-9642 |
CRANKSHAFT ASM Price: $4,332.74 |
| 100 |
110-3729 |
BALL This part replaces 98-7473. Price: $0.69 |
| 102 |
2751R |
CLIP T Price: Call Us |
| 110 |
98-9532 |
GEAR-CRANKSHAFT Price: $169.43 |
| 114 |
145349 |
BRACKET.SUPT.DASH Price: Call Us |
| 115 |
121794X |
COVER ACCESS Price: Call Us |
| 117 |
144283 |
WASHER.SERRATED. Price: Call Us |
| 118 |
145595 |
BRACKET.CLUTCH.MC Price: Call Us |
| 120 |
98-9666 |
KEY Price: $3.58 |
| 123 |
149037 |
BRACKET.PICK.LH. Price: Call Us |
| 124 |
149036 |
BRACKET.PICK.RH. Price: Call Us |
| 125 |
74180412 |
SCREW Price: Call Us |
| 127 |
120579X |
PAL NUT Price: Call Us |
| 128 |
124201X |
SCREW SPECIAL Price: Call Us |
| 130 |
98-9542 |
GEAR-DRIVE, OIL PUMP Price: $89.04 |
| 140 |
158418 |
BRKT SUSPENSION Price: Call Us |
| 140 |
98-9522 |
SLEEVE-CRANKSHAFT Price: $116.47 |
| 147 |
74760412 |
BOLT LT Price: Call Us |
| 150 |
98-9521 |
COLLAR-CRANKSHAFT Price: $84.21 |
| 160 |
105-3783 |
O-RING Price: $6.33 |
| 170 |
108-1407 |
METAL-CRANKPIN, -0.2MM Price: $63.01 |
| 170 |
112-7005 |
BEARING-MAIN (STD) This part replaces 98-9554. Price: $66.99 |
| 170 |
112-7010 |
METAL-CRANKPIN (-0.4MM) This part replaces 108-1408. Price: $30.75 |
| 180 |
108-1409 |
METAL-CRANKPIN, -0.2MM Price: $49.61 |
| 180 |
112-7013 |
METAL-CRANKPIN (-0.4MM) This part replaces 108-1410. Price: $30.75 |
| 180 |
98-9524 |
METAL-CRANKSHAFT (STD SET) This part replaces 98-9555. Price: $62.26 |
| 190 |
112-7039 |
METAL-CRANKSHAFT (0.2MM) This part replaces 105-3719. Price: $60.46 |
| 190 |
112-7040 |
METAL-CRANKSHAFT (-0.4MM) This part replaces 105-3720. Price: $66.64 |
| 190 |
115-4121 |
METAL-CRANKSHAFT (STD) This part replaces 98-9556. Price: $86.06 |
| 200 |
127-0416 |
METAL-SIDE (+0.2MM) This part replaces 98-9414. Price: $21.04 |
| 200 |
98-9413 |
BEARING-THRUST (STD) Price: $16.90 |
| 200 |
98-9415 |
BEARING-THRUST (0.4MM) Price: $9.77 |
| 210 |
127-0437 |
METAL-SIDE (+0.2MM) This part replaces 98-9689. Price: $18.42 |
| 210 |
98-9688 |
BEARING-THRUST (STD) Price: $16.90 |
