| Ref | Part Number | Description |
|---|
| 1 |
161-8350 |
COIL ASM This part replaces 88-9190. Price: $111.53 |
| 1 |
MA-MD008784 |
CAP Not Available Price: |
| 2 |
161-8352 |
VALVE AND COIL KIT This part replaces 93-7494. Price: $347.93 |
| 2 |
MA-MM438850 |
BREATHER PIPE Not Available Price: |
| 3 |
None |
UNKNOWN |
| 3 |
94-2627 |
CARTRIDGE Price: $453.45 |
| 4 |
None |
UNKNOWN |
| 4 |
353-991 |
PLUG-HEX, HOLLOW Price: $10.21 |
| 5 |
237-156 |
O-RING Price: $1.07 |
| 5 |
MA-30H01-00010 |
CYLINDER HEAD ASSEMBLY Not Available Price: |
| 6 |
353-989 |
PLUG-HEX, HOLLOW Price: $21.59 |
| 6 |
MA-MM435275 |
GUIDE-VALV Not Available Price: |
| 7 |
237-42 |
O-RING Price: $2.78 |
| 7 |
MA-F5014-25000 |
SEALING CAP Not Available This part replaces MA-MF665538. Price: |
| 8 |
75-2010 |
CARTRIDGE-RELIEF Price: $413.23 |
| 8 |
MA-04826-24000 |
SEALING CAP Not Available This part replaces MA-MD000427. Price: |
| 9 |
139-6007 |
CARTRIDGE-POPPET, NC This part replaces 92-6315. Price: $531.50 |
| 9 |
MA-30H01-00300 |
CYLINDER HEAD GASKET Not Available Price: |
| 10 |
353-988 |
PLUG-HEX Price: $10.61 |
| 10 |
MA-30A01-03300 |
BOLT-CYLIN Not Available Price: |
| 11 |
237-79 |
O-RING Price: $5.46 |
| 11 |
MA-30A01-03200 |
BOLT-CYLIN Not Available Price: |
| 12 |
MA-MF106091 |
BOLT Not Available Price: |
| 13 |
94-6351 |
CARTRIDGE-RELIEF Price: $285.09 |
| 13 |
MA-MF101316 |
BOLT Not Available Price: |
| 14 |
106-9084 |
PLUG-ORIFICE (.020 DIA) This part replaces 95-5999. Price: $67.12 |
| 14 |
MA-MS661140 |
PLUG 35200 Not Available Price: |
| 15 |
94-6353 |
PLUG-CAVITY Price: $145.49 |
| 15 |
MA-30H04-00010 |
ROCKER COVER Not Available Price: |
| 16 |
237-80 |
O-RING Price: $6.10 |
| 16 |
MA-32A04-09100 |
PIPE-MANIFOLD INLE Not Available This part replaces MA-K9644171. Price: |
| 17 |
354-70 |
PLUG-HEX, HOLLOW Price: $10.29 |
| 17 |
MA-30H04-00101 |
VALVE COVER GASKET Not Available This part replaces MA-30H04-00100. Price: |
| 18 |
94-6352 |
PLUG-CAVITY Price: $207.43 |
| 18 |
MA-MF100065 |
BOLT Not Available Price: |
| 19 |
94-5438 |
SEAL-WASHER Price: $3.56 |
| 19 |
MA-MF100069 |
BOLT Not Available Price: |
| 21 |
MA-MS470058 |
CLIP Not Available Price: |
| 22 |
None |
Cover, Rocker |
| 23 |
MA-30H04-02100 |
LABEL Not Available Price: |
| 503212810 |
503212810 |
SCREW Price: $2.99 |
| 503214416 |
503214416 |
SCREW Price: $2.99 |
| 503216220 |
503216220 |
SCREW W/ LOCKING FLUID Price: $3.99 |
| 503227201 |
503227201 |
NUT Price: $2.99 |
| 537034401 |
503987401 |
DECAL This part replaces 537034401. Price: $4.99 |
| 537080502 |
537080503 |
HEAT PROTECTOR This part replaces 537080502. Price: $27.99 |
| 537096601 |
537096601 |
MUFFLER SHIELD Price: $7.99 |
| 537145402 |
537145404 |
CYLINDER COVER This part replaces 537145402. Price: $44.99 |
