| Ref | Part Number | Description |
|---|
| 1 |
532424543 |
WHEEL.STEERING.HARD.RIM.BLAC Price: $27.99 |
| 2 |
115-3299 |
SEAL-FLOCKED Price: $13.85 |
| 2 |
583512701 |
SUBASM.AXLE.CAST.NZTR. This part replaces 532436870. Price: $149.99 |
| 3 |
140-5510 |
BEARING-SEALED, STAINLESS This part replaces 115-3296. Price: $28.48 |
| 4 |
115-5258 |
SPRING-WIRE, FLAT Price: $3.40 |
| 4 |
583512801 |
WELDMENT.SPINDLE.LH.15.NZTR This part replaces 532436873. Price: $32.99 |
| 5 |
583512901 |
WELDMENT.SPINDLE.RH.15.NZTR This part replaces 532436874. Price: $32.99 |
| 6 |
106-2648-01 |
BEDBAR Price: $367.64 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $5.99 |
| 7 |
119-4150 |
WASHER-FLAT Price: $0.64 |
| 7 |
532121748 |
WASHER Price: $1.99 |
| 8 |
52-2900 |
WASHER-PLASTIC Price: $0.75 |
| 8 |
812000029 |
RING CLIP Price: $1.99 |
| 9 |
117-9493 |
BOLT-BEDBAR Price: $5.50 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $1.99 |
| 10 |
140-9234 |
NUT-HEX LOCK This part replaces 119-4154. Price: $0.92 |
| 11 |
137-8513 |
ES REEL+, LD (21), 14 BLD This part replaces 119-4105. Price: $658.50 |
| 12 |
119-4153 |
RUBBER BUSHING ASM Price: $6.66 |
| 13 |
52-2890 |
BUSHING-NYLON Price: $2.49 |
| 13 |
532121749 |
WASHER Price: $1.99 |
| 14 |
119-4151 |
SCREW-BEDKNIFE Price: $0.41 |
| 14 |
539990118 |
SLW 3/8 STD This part replaces 810040600. Price: $1.99 |
| 15 |
115-1880 |
BEDKNIFE-EDGEMAX, MICROCUT Price: $129.33 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $1.99 |
| 16 |
587016002 |
SHAFT.STEER.2HIGH.SPLND.PLATED Price: $11.99 |
| 19 |
532194729 |
PLATE.STEER.DDL.NLT/NG Price: $12.99 |
| 20 |
532424740 |
BOOT.STRNG.PREDATOR.YT/GT.428 Price: $2.99 |
| 21 |
586840201 |
ADAPTER.WHEEL.STEER.SPLND.ALUM Price: $2.99 |
| 22 |
585029901 |
BEARING.SUBASM.SHAFT.STEER.LOW Price: $4.99 |
| 26 |
532424691 |
INSERT, WHEEL STEERING Price: $4.99 |
| 27 |
819211616 |
WASHER LT Price: $3.99 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 35 |
583551401 |
GEAR.SECTOR.TEX.NZTR (3 2) This part replaces 532440770. Price: $22.99 |
| 45 |
587016401 |
WASHER.3/8ID.2-3/8OD.12GA.PLTD Price: $1.99 |
| 50 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $2.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $2.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $4.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $3.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
583513301 |
SUBASM.LINK.DRAG.LH.NZTR This part replaces 532436884. Price: $24.99 |
| 62 |
583513401 |
SUBASM.LINK.DRAG.RH.NZTR This part replaces 532436885. Price: $24.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $2.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $2.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $2.99 |
| 67 |
532194737 |
BUSHING.PM.FRONT AXLE Price: $3.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $2.99 |
| 70 |
585338801 |
BRACKET.FRT.DECK.SUSP.RR.MT431 Price: $5.99 |
| 75 |
580683702 |
PINION.ZINC PLATED This part replaces 580683701. Price: $2.99 |
| 76 |
580683601 |
SCREW HEAD SOCKET LRVB Price: $1.99 |
| 80 |
532001370 |
THRUST WASHER Price: $2.99 |
| 81 |
583513501 |
SUBASM.LINK.CROSS.RH.NZTR This part replaces 532436887. Price: $11.99 |
| 82 |
532442147 |
SUBASM;PIVOT;BOLT;NZTR Price: $3.99 |
| 85 |
583561101 |
SUBASM.PIVOT.RH.NZTR This part replaces 532441873. Price: $24.99 |
| 86 |
583561001 |
SUBASM.PIVOT.LH.NZTR This part replaces 532441872. Price: $24.99 |
