| Ref | Part Number | Description |
|---|
| 1 |
111-4831 |
DECK ASM Price: $3,868.92 |
| 1 |
30816 |
SHAFT & LEV Price: Call Us |
| 1 |
539976935 |
CAPSCREW 5/16 X 1/1/2 HEX HEAD This part replaces 874760524. Price: $1.99 |
| 2 |
30357 |
SCREW Price: $2.62 |
| 2 |
874780652 |
Bolt, Hex 3/8-16 x 3-1/4 (AYP part number) Price: $9.99 |
| 3 |
30726 |
SHUTTER Price: Call Us |
| 3 |
819131311 |
Washer 13/32 x 13/16 x 11 Ga. (AYP part number) Price: $3.99 |
| 4 |
30933 |
SHAFT & LEV Price: Call Us |
| 5 |
30358 |
RET SPRING Price: Call Us |
| 5 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.99 |
| 6 |
532138330 |
Price: Call Us |
| 6 |
650399 |
SCREW This part replaces 630605. Price: $1.20 |
| 7 |
27112 |
IDLE SCREW Price: $1.26 |
| 8 |
27114 |
SPRING Price: $2.62 |
| 9 |
30950 |
CARB BODY Price: Call Us |
| 10 |
30927 |
SHUTTER Price: Call Us |
| 11 |
30356 |
GASKET Price: $2.22 |
| 11 |
532187912 |
BOLT, HEX HEAD 5/16-18 X 2.5 Price: $2.99 |
| 12 |
27108 |
GASKET Price: Call Us |
| 12 |
532151222 |
TRANSMISSION.ASM.W/1".D-SHAFT Price: $169.99 |
| 13 |
29154 |
INLET NEEDLE Price: Call Us |
| 14 |
30354 |
FLOAT Price: Call Us |
| 14 |
532009173 |
SPACER Price: $3.99 |
| 15 |
27106 |
FLOAT SHAFT Price: $2.04 |
| 15 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873970500. Price: $2.99 |
| 16 |
27136A |
DRAIN ASSY This part replaces 27136. Price: $5.96 |
| 16 |
819091416 |
WASHER This part replaces 819091412. Price: $3.99 |
| 17 |
32131 |
FLOAT BOWL This part replaces 30350. Price: $11.15 |
| 17 |
819092016 |
WASHER Price: $2.99 |
| 18 |
27136A |
DRAIN ASSY This part replaces 27137. Price: $5.96 |
| 18 |
810040400 |
LOCKWASHER Price: $3.99 |
| 19 |
27136A |
DRAIN ASSY This part replaces 27138. Price: $5.96 |
| 19 |
874610412 |
Bolt, Hex 1/4-28 x 3/4 Gr. 5 (AYP part number) Price: $1.99 |
| 20 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 21 |
28945 |
POWER SCREW Price: $18.86 |
| 22 |
630786 |
SPRING Price: $1.25 |
| 23 |
30355 |
NOZZLE Price: Call Us |
| 25 |
27554 |
GASKET Price: $1.05 |
| 27 |
650506 |
SCREW This part replaces 630606. Price: $0.87 |
| 28 |
30815 |
BAFFLE Price: Call Us |
| 29 |
30817 |
SCREW Price: Call Us |
