| Ref | Part Number | Description |
|---|
| 1 |
GW-9362 |
PIN - spring, 1/8" dia., retains castle nut to threaded stud This part replaces 9362. Price: $3.82 |
| 2 |
9838 |
NUT-HEX 1/2-20 Price: Call Us |
| 3 |
GW-9934 |
WASHER- shoulder, 1/2" (shoulder faces disc washers) This part replaces 9934. Price: $13.73 |
| 4 |
GW-9932 |
WASHER- disc spring (concave surfaces face each other) This part replaces 9932. Price: $21.54 |
| 5 |
GW-2628 |
LEVER - wheel speed shift This part replaces 2628. Price: $124.90 |
| 6 |
1902240 |
KNOB-WHEEL SPEED HORSE Price: $20.45 |
| 7 |
GW-9317 |
PIN - cotter, 3/32" x 1" This part replaces 9317. Price: $3.22 |
| 8 |
GW-1231 |
ROD - connecting rod, wheel speed shift lever This part replaces 1231. Price: $14.83 |
| 9 |
GW-1033 |
SWIVEL - connecting rod This part replaces 1033. Price: $13.56 |
| 10 |
736-0567 |
NYLON FLAT WASHER Not Available This part replaces GW-9902. Price: |
| 11 |
714-04048 |
PIN - hair cotter This part replaces 9338. Price: $7.04 |
| 12 |
912-0158 |
Hex Lock Nut, 5/16-18 This part replaces GW-9808. Price: $2.83 |
| 13 |
710-0514 |
SCREW 3/8-16 x 1 GR5 This part replaces GW-9710. Price: $3.78 |
| 14 |
736-0169 |
L-Wash. 3/8" I.D." This part replaces GW-9913. Price: $3.33 |
| 15 |
736-3050 |
Washer, Plain (flat) 3/8, S.A.E. This part replaces 9904. Price: $3.90 |
| 16 |
GW-2146 |
BUSHING - spacer, 21/64" (.325") long, yoke to engine mount Not Available This part replaces 2146. Price: |
| 17 |
GW-1113-1099 |
BUSHING - spacer, 19/64" (.300") long, yoke link to retaining plug This part replaces 1113-1. Price: $4.53 |
| 18 |
GW-9120 |
RING- retaining (tolerance ring) This part replaces 9120. Price: $5.94 |
| 19 |
GW-1920 |
BLOCK - belt adjustment, 3-7/8" long This part replaces 1920. Price: $53.19 |
| 20 |
GW-2100 |
ROD - belt adjustment, 7" long, with measuring gauge This part replaces 2100. Price: $11.28 |
| 21 |
1900766 |
DECAL-STARTING STA Not Available Price: |
| 22 |
710-0539 |
Screw, 3/8-24 x 1.75 This part replaces 1100012. Price: $3.95 |
| 23 |
756-04171 |
DISC ONLY-reverse, rubber rimmed This part replaces GW-2111. Price: $58.85 |
| 23 |
GW-1919 |
DISC-reverse, rubber rimmed This part replaces 1919. Price: $92.08 |
| 24 |
GW-9245 |
BELT -forward drive This part replaces 9245. Price: $21.83 |
| 25 |
GW-2357 |
ENGINE PULLEY Not Available Price: |
| 26 |
736-04260 |
Washer, 1.375 x 1.015 x .03 This part replaces 1166-2. Price: $5.94 |
| 26 |
736-04309 |
Washer, 1.375 x 1.015 x .062 This part replaces 1166-1. Price: $3.85 |
| 27 |
GW-9326 |
SQUARE KEY .25 x 1.25 Not Available Price: |
| 28 |
710-0376 |
Hex Screw, 5/16-18 x 1.00 This part replaces GW-90008. Price: $3.66 |
| 29 |
712-3010 |
HEX NUT 5/16-18 This part replaces GW-9801. Price: $3.89 |
| 30 |
GW-1034A |
BAR- engine mounting This part replaces 1900836. Price: $41.06 |
| 31 |
GW-9147 |
PLUG - thread protector, red plastic This part replaces 9147. Price: $7.05 |
| 32 |
710-0672 |
BOLT- hex. hd., 5/16"-24 x 1-1/8", engine mounting This part replaces 9572. Price: $3.85 |
| 33 |
936-0119 |
LOCK WASHER 5/16 This part replaces GW-9912. Price: $4.29 |
| 34 |
719-04222-0637 |
Motor Mount This part replaces 2565. Price: $274.62 |
| 35 |
710-0157 |
HEX SCREW 5/16-24 x .75 This part replaces 1100004. Price: $3.90 |
| 36 |
736-0607 |
External L-Washer 5/16 This part replaces 1177548. Price: $3.66 |
| 37 |
GW-2677 |
PLATE-ADAPTER 11HP PNT Price: Call Us |
| 38 |
GW-2660 |
ENGINE PULLEY SPACER Not Available Price: |
| 39 |
12153 |
BRACKET-DE Not Available Price: |
| 39 |
GW-1904192 |
KIT-ENG 11HP EL B&S Price: Call Us |
| 39 |
GW-1915356 |
ENG-11HP B&S ELC Price: Call Us |
| 40 |
736-3052 |
Flat Washer, .406 x 1.0 x .105 This part replaces GW-9903. Price: $4.02 |
| 43 |
GW-9322099 |
PIN -roll (spirol, 5/16" x 1-1/2" long, wheel hub to shaft This part replaces 9322. Price: $6.86 |
| 45 |
2709-01 |
WHEEL ASSEMBLY Not Available Price: |
| 45A |
2709-02 |
WHEEL ASSEMBLY Not Available Price: |
| 46 |
1902020 |
HUB CAP Not Available Price: |
