| Ref | Part Number | Description |
|---|
| 1 |
532439822 |
SEAT.TH150.MS498.GRY.HUSQ.TEX Price: $159.99 |
| 1 |
703-0924 |
PLATE-COVER-FR Not Available Price: |
| 1 |
84-0940 |
FORK-BRAKE, RH Price: $74.96 |
| 2 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $11.99 |
| 2 |
721-3016 |
COVER GASKET Not Available Price: |
| 3 |
532140675 |
STRAP Price: $5.99 |
| 3 |
721-0193 |
Seal, Oil, 5/8 ID X 1.574 OD X .312 Wide Price: Call Us |
| 3 |
76-9690-03 |
ROD-BRAKE This part replaces 76-9690. Price: $52.07 |
| 4 |
716-0143 |
RETAINING RING Not Available Price: |
| 4 |
86-5840 |
PLATE-SPRING Price: $7.17 |
| 5 |
86-5830 |
SPRING-COMPRESSION Price: $19.73 |
| 5 |
941-0361 |
Bearing, Ball This part replaces 741-0361. Price: $43.82 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 6 |
66-6480 |
WASHER Price: $1.29 |
| 6 |
717-3073 |
INPUT SHAFT Not Available Price: |
| 7 |
3220-3 |
NUT-HJ Price: $0.28 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 7 |
717-3074 |
GEAR-REDUCTION-84T Not Available Price: |
| 8 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 8 |
717-3104 |
Washer, Flat, 1/2 ID X 1-1/2 OD X 3/16 Thk Price: Call Us |
| 9 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 9 |
736-0171 |
Washer, Lock, 7/16 Price: $3.86 |
| 10 |
323-7 |
SCREW-HH Price: $0.65 |
| 10 |
710-0505 |
Screw, Hex Cap, 7/16-14 X 1.0 Lg GR5 Price: $6.01 |
| 11 |
717-3076 |
SPACER-RED GEAR Not Available Price: |
| 11 |
84-0970 |
FORK-BRAKE, LH Price: $74.96 |
| 12 |
32120-19 |
E-RING Price: $2.27 |
| 12 |
712-3026 |
Nut, Hex Jam, 3/4-16 GR5 Price: $4.29 |
| 13 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 13 |
717-3080 |
RETAINER-BRG Not Available Price: |
| 14 |
741-0366 |
BALL BEARING-W/RIN Not Available Price: |
| 14 |
76-8270 |
PIN-BRAKE Price: $11.07 |
| 15 |
717-3275 |
SHIM-#36 BWG Not Available Price: |
| 15 |
76-4180 |
BOOT-ROD, BRAKE Price: $25.33 |
| 16 |
283-2 |
PIN-CLEVIS Price: $12.99 |
| 17 |
76-6610 |
DISCONTINUED Price: Call Us |
| 17 |
941-3037 |
Bearing, Ball This part replaces 741-0360. Price: $38.73 |
| 18 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 18 |
941-0362 |
Bearing, Needle This part replaces 741-0362. Price: $95.90 |
| 19 |
5-2512 |
BUSHING Price: $15.80 |
| 19 |
710-0847 |
SCREW-SET Not Available Price: |
| 20 |
732-0424 |
Spring, Detent Price: $7.40 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 21 |
741-0359 |
DETENT BALL Not Available Price: |
| 23 |
717-3051 |
TRANSMISSION HOUSING Not Available Price: |
| 24 |
717-3207 |
SHIFT FORK 2ND Not Available Price: |
| 37 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 40 |
595088102 |
Handles This part replaces 532197661. Price: $4.99 |
| 41 |
532198200 |
SPRING.LATCH.SEAT.TEX Price: $3.99 |
| 43 |
874760612 |
BOLT Price: $3.99 |
| 44 |
583789501 |
WASHER.13/32x2 3/8x12GA This part replaces 819133812. Price: $4.99 |
