| Ref | Part Number | Description |
|---|
| 1 |
137-6105 |
SHORT REAR ROLLER ASM (2.5IN DIA)(22IN) This part replaces 114-5406. Price: $478.13 |
| 1 |
872170410 |
Bolt, Carriage 1/4-20 x 1-1/4 (AYP part number) Price: $2.99 |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 2 |
532127427 |
Seat (AYP part number) This part replaces 532127423. Price: $119.99 |
| 3 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 3 |
874641008 |
Screw, Slotted Pan Head #10-32 x 1/2 (AYP part number) Price: $2.99 |
| 4 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 5 |
106-3924 |
BRACKET-ROLLER, REAR Price: $23.58 |
| 5 |
532139888 |
BOLT.SHOULDER.5/16-18 This part replaces 532105529. Price: $2.99 |
| 6 |
3230-26 |
SCREW-CARR Price: $3.99 |
| 6 |
532124967 |
Clip, Insulated (AYP part number) This part replaces 532004171. Price: $5.46 |
| 7 |
114-5400 |
PLASTIC WIEHLE ROLLER ASM Price: $477.85 |
| 7 |
873951000 |
Nut, Keps #10-32 UNF (AYP part number) Price: $5.99 |
| 8 |
874760612 |
Bolt, Fin. Hex 3/8-16 UNC x 3/4 (AYP part number) Price: $1.99 |
| 9 |
32128-20 |
NUT-HF Price: $0.99 |
| 9 |
532126471 |
Clip, Insulated (AYP part number) Price: $2.99 |
| 10 |
322-16 |
SCREW-HH Price: $3.39 |
| 10 |
532126656 |
Bracket, Pivot, Seat (AYP part number) Price: $5.46 |
| 11 |
3231-4 |
SCREW-CARR Price: $3.59 |
| 11 |
819131210 |
Washer 13/32 x 3/4 x 10 Ga. (AYP part number) Price: $2.99 |
| 12 |
140-5690 |
BRACKET-RM FRONT HOC This part replaces 125-2796. Price: $20.85 |
| 12 |
873680600 |
Nut, Crownlock 3/8-16 UNC Price: $1.99 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 13 |
532127018 |
Bolt, Shoulder (AYP part number) Price: $3.99 |
| 14 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 14 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT This part replaces 532120068. Price: $6.99 |
| 15 |
107-4026 |
SCREW-HH Price: $5.28 |
| 15 |
819171912 |
Washer 17/32 x 1-3/16 x 12 Ga. (AYP part number) Price: $3.99 |
| 16 |
532121251 |
Strip, Foam (AYP part number) Price: $5.46 |
| 16 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 17 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 532123976. Price: $2.99 |
| 18 |
532121248 |
Bushing, Snap (AYP part number) Price: $3.99 |
| 19 |
532121250 |
Spring, Compression (AYP part number) Price: $3.99 |
| 20 |
532121249 |
Spacer, Split 28 ld. x .88 Large (AYP part number) Price: $3.99 |
| 21 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $4.99 |
