| Ref | Part Number | Description |
|---|
| 1 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 2 |
136-4368-01 |
PEDAL-TRACTION Price: $45.98 |
| 3 |
93-5347 |
ABRASIVE-PEDAL Price: $12.38 |
| 4 |
93-5368 |
ABRASIVE-PEDAL Price: $9.23 |
| 5 |
323-7 |
SCREW-HH Price: $0.65 |
| 6 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 7 |
3219-3 |
NUT-HEX Price: $0.34 |
| 8 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 9 |
131-2245 |
SHAFT-PEDAL, TRACTION Price: $83.42 |
| 10 |
32121-78 |
PIN-ROLL Price: $3.09 |
| 11 |
321-37 |
SCREW-HH Price: $10.99 |
| 12 |
117-5459 |
BLOCK-CLAMP Price: $14.84 |
| 13 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 14 |
322-14 |
SCREW-HH Price: $1.01 |
| 15 |
104-7201 |
NUT-HF Price: $0.69 |
| 16 |
3234-47 |
SCREW-HHF Price: $1.79 |
| 17 |
256-236 |
BEARING-MOUNT, FLANGE Price: $27.99 |
| 18 |
117-5455 |
PLATE-COVER Price: $5.15 |
| 19 |
117-5454 |
PLATE-BUTTERFLY Price: $10.91 |
| 20 |
131-2250-0P |
BRACKET-PEDAL, OUTER This part replaces 131-2250-01. Price: $21.44 |
| 21 |
3230-22 |
SCREW-CARR Price: $1.99 |
| 22 |
93-7960 |
SPACER Price: $5.67 |
| 23 |
114-7728 |
SCREW-THREADLOCK Price: $1.02 |
| 24 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 25 |
3296-9 |
NUT-HEX Price: $0.25 |
| 26 |
136-4384-0P |
BRACKET-SENDER This part replaces 136-4384-01. Price: $15.32 |
| 27 |
140-6215 |
HUB ASSEMBLY-BUSHING This part replaces 117-5445. Price: $24.64 |
| 28 |
114-5609 |
SENSOR-POSITION Price: $371.51 |
| 29 |
114-5595 |
PLATE-CAPTURE Price: $5.99 |
| 30 |
114-5608 |
SPACER-STANDOFF Price: $15.74 |
| 31 |
32105-25 |
SCREW-SHH Price: $0.81 |
| 32 |
117-5446 |
SHAFT-SPRING Price: $48.04 |
| 33 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 34 |
84-9100 |
SPRING Price: $11.99 |
| 35 |
92-7610 |
RETAINER-SPRING Price: $26.52 |
| 36 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 37 |
3296-6 |
NUT-LOCK Price: $1.49 |
| 38 |
131-2252-0P |
BRACKET-SPRING This part replaces 131-2252-01. Price: $17.94 |
| 39 |
132-6251 |
PLATFORM ASSEMBLY Price: $1,775.15 |
