| Ref | Part Number | Description |
|---|
| 1 |
59-7580 |
NUT Price: $0.95 |
| 2 |
3253-6 |
WASHER-LOCK This part replaces 59-7590. Price: $0.39 |
| 3 |
59-7970 |
STUD Price: $17.00 |
| 3 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 4 |
532432420 |
SHIELD.INNER.BELT.GUARD.RT Price: $69.99 |
| 4 |
69-2060 |
SHAFT END COVER ASM This part replaces 86-6010. Price: $1,123.41 |
| 5 |
532164329 |
PIN.SPIROL.FLARED Price: $3.99 |
| 5 |
59-7990 |
SEAL Price: $14.58 |
| 6 |
532110111 |
LEVER ASM CRT Price: $11.99 |
| 6 |
59-8470 |
RETAINER Price: $18.19 |
| 7 |
69-2070 |
PLATE-FLEX This part replaces 86-6070. Price: $311.23 |
| 7 |
872110404 |
BOLT Price: $7.99 |
| 8 |
532008700 |
PANEL.INDICATOR.SHIFT.BLACK Price: $3.99 |
| 8 |
69-2080 |
SECTION-CENTER This part replaces 86-6020. Price: $700.92 |
| 9 |
59-8590 |
SEAL Price: $31.34 |
| 9 |
817021008 |
SCREW This part replaces 532086777. Price: $3.99 |
| 10 |
532009484 |
CONDUIT.CLIP.PLATED Price: $4.99 |
| 10 |
59-8500 |
GEAR Price: $1,303.76 |
| 11 |
59-8600 |
GEAR Price: $470.56 |
| 12 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 12 |
86-6080 |
O-RING Price: $4.40 |
| 13 |
823230506 |
SET SCREW Price: $2.99 |
| 13 |
86-6000-01 |
PUMP This part replaces 86-6030. Price: $2,799.05 |
| 14 |
532156117 |
SPACER-SPLIT.327 X .42 Price: $4.99 |
| 14 |
59-8540 |
COUPLING Price: $240.01 |
| 15 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 15 |
69-2200 |
O-RING This part replaces 86-6040. Price: $17.77 |
| 16 |
532145102 |
SHEAVE, TRANSMISSION Price: $59.99 |
| 16 |
86-6050 |
PLUG Price: $12.09 |
| 17 |
59-8570 |
SEAL Price: $45.56 |
| 18 |
59-8580 |
RING-RETAINING Price: $10.21 |
| 19 |
812000028 |
RETAINING RING LT Price: $1.99 |
| 21 |
532110652 |
SPACER CRT Price: $4.99 |
| 22 |
874770508 |
BOLT Price: $2.99 |
| 23 |
532005015 |
TIRE.16X4-8.CHEVRON.TILLER Price: $99.99 |
| 24 |
532126875 |
RIVET,DRILLED Price: $2.99 |
| 25 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 26 |
532440438 |
GUARD.BELT.TILLER.ORANGE Price: $44.99 |
| 27 |
591372401 |
BELT.V.DR.RT TILLER This part replaces 532132801. Price: $14.99 |
| 28 |
532104679 |
PULLEY-IDLER TI Price: $14.99 |
| 29 |
812000032 |
KLIP RING Price: $3.99 |
| 30 |
584289401 |
BRACKET.IDLER.ASM.SHORT This part replaces 532159229. Price: $12.99 |
| 31 |
532102384 |
BOLT.FIN.HEX.3/8-16UNC Price: $7.99 |
| 32 |
532102141 |
SHIFT ARM CRT Price: $6.99 |
| 33 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 34 |
532102383 |
COUNTERWEIGHT.LH.CRT Price: $84.99 |
| 37 |
532130812 |
RP.ENGINE PULLEY Price: $19.99 |
| 38 |
596218601 |
Bolts This part replaces 874760544. Price: $3.99 |
| 39 |
532140062 |
CAP.PLUNGER.BLACK Price: $4.99 |
| 40 |
532170488 |
SCREW.HEX.WSH.SLT.#10-24X.50 Price: $2.99 |
| 44 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 65 |
596040501 |
Hardware This part replaces 873970500. Price: $2.99 |
| 66 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 67 |
596582201 |
Bolts This part replaces 874760524. Price: $2.99 |
| 68 |
873510600 |
NUT Price: $4.99 |
| 532065139 |
VALVE |
STEM LT This part replaces 532124718. Price: $5.99 532065139 |
| 532128952 |
RIM |
ASM.2.75 X 8.00.WHITE This part replaces 532124366. Price: $89.99 532128952 |
