| Ref | Part Number | Description |
|---|
| 1 |
33-1480 |
DISCONTINUED Price: Call Us |
| 1 |
463227 |
Cutter Deck w/Decals - 61V Price: Call Us |
| 2 |
04020-09 |
Hex Locknut, Elastic Stop, 3/8-16 Price: Call Us |
| 3 |
04001-172 |
Bolt, Hex Head 1/4-20 x 1" Grade 8 Black Price: Call Us |
| 4 |
48926 |
Hub, Tapered 1-1/8" Bore Price: Call Us |
| 5 |
482745 |
Pulley, 6.35 O.D. (Diesel Engine) Price: Call Us |
| 6 |
481558 |
Belt, Cutter Deck Drive - Kubota Price: Call Us |
| 7 |
33-1410 |
DISCONTINUED Price: Call Us |
| 7 |
48141 |
TAPERED HUB, 1.00" BORE Price: Call Us |
| 8 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 9 |
33-1470 |
DISCONTINUED Price: Call Us |
| 9 |
424367 |
Quick Pin, 5/16" Dia. Price: Call Us |
| 10 |
33-1500 |
DISCONTINUED Price: Call Us |
| 10 |
482746 |
Pulley, 6.75 O.D. - 61" Price: Call Us |
| 11 |
04043-04 |
Flatwasher, 3/8 (.391 x .938 x .105 HD) Grade 8 Price: Call Us |
| 11 |
33-1510 |
DISCONTINUED Price: Call Us |
| 12 |
483215 |
Idler Pulley, Belt Clutch Price: Call Us |
| 13 |
463175 |
Belt Cover, 61V (incl. #14) Price: Call Us |
| 14 |
484368 |
Cap, Spindle 61" Only Price: Call Us |
| 15 |
481625-01 |
Knob, w/stud 3/8-16 x 1-1/4" Price: Call Us |
| 16 |
04001-136 |
Bolt, Hex Head 3/8-16 x 1-1/2" Grade 8 Black Price: Call Us |
| 17 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 18 |
48224 |
BEARINGS, BALL, NEUTRAL RETURN Price: Call Us |
| 19 |
461842 |
Idler Arm, Cutter Deck Price: Call Us |
| 20 |
04001-22 |
Capscrew, Hex Head 3/8-16 x 2.75" Price: Call Us |
| 21 |
43681 |
Pivot, Idler - Short Price: Call Us |
| 22 |
48038 |
Wheel, Anti-ScalpRelief Fitting, Tapered Spindle Price: Call Us |
| 23 |
45944 |
Shaft Weldment, Guide Roller Price: Call Us |
| 24 |
04117-01 |
Nut, Flange Head Elastic Stop 5/16-18 Price: Call Us |
| 25 |
04001-09 |
Bolt, Heax Head 5/16-18 x 1" (48V / 52V) Price: Call Us |
| 26 |
04001-79 |
BOLT, HEX HEAD 5/8-11 X 4-1/2" Price: Call Us |
| 27 |
04021-13 |
HEX LOCKNUT, ELASTIC STOP, 5/8-11 Price: Call Us |
| 28 |
461516 |
Push Arm (Includes 64,60,62) Price: Call Us |
| 29 |
428027 |
Mounting Plate Price: Call Us |
| 30 |
04001-154 |
Bolt, 5/16-18 x 4-3/4" Hex Head Price: Call Us |
| 31 |
04003-12 |
Bolt, 5/16-18 x .75 RHSN Carriage Price: Call Us |
| 32 |
04001-09 |
Bolt, Heax Head 5/16-18 x 1" (48V / 52V) Price: Call Us |
| 33 |
04030-03 |
Lockwasher, 5/16 (.317 x .586 x .078) Helical Spring Price: Call Us |
| 34 |
04040-15 |
Flatwasher, 5/16-.375 x .875 x .083 (35BV & 37BV-EFI) Price: Call Us |
| 35 |
482486 |
Gearbox Assembly, Deck Drive Price: Call Us |
| 36 |
43763 |
Spacer, Gearbox Mount Price: Call Us |
| 37 |
428026 |
Mounting Plate Price: Call Us |
| 38 |
04021-10 |
HEX NUT, ELASTIC STOP LOCK, 5/16-18 Price: Call Us |
| 39 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 40 |
451240 |
Shaft Weldment, Pusharm Price: Call Us |
| 41 |
04021-22 |
Lock Nut, 5/16-18 Elastic Stop Grade 8 Price: Call Us |
| 42 |
04001-54 |
Bolt, Hex Head 3/8-16 x 3" - 52" Price: Call Us |
| 43 |
04001-51 |
Capscrew, Hex Head 3/8-16 x 3-3/4" Price: Call Us |
| 44 |
483176 |
Pad, Deck Wear Price: Call Us |
| 45 |
461663 |
Cutter Spindle Assembly Price: Call Us |
| 46 |
43589 |
Spindle Shaft, Tapered Brng Price: Call Us |
| 47 |
481024 |
SEAL, 2.00 O.D. X 1.50 BORE Price: Call Us |
| 48 |
481022 |
Tapered Bearing Set (Two Bearings W/Race) Price: Call Us |
| 49 |
48114-04 |
GREASE FITTING, STR. 1/4-28 SELF TAP. Price: Call Us |
| 50 |
48677 |
RELIEF FITTING, TAPERED BEARING SPINDLE Price: Call Us |
| 51 |
43644 |
Housing, Spindle Price: Call Us |
| 52 |
43312 |
Spacer, Outside, Cutter Spindle Price: Call Us |
| 53 |
43296 |
SLEEVE, CUTTER SPINDLE Price: Call Us |
| 54 |
481025 |
Seal, 2.00" O.D. x 1.625" Bore Price: Call Us |
| 55 |
43297 |
SPINDLE BUSHING, BOTTOM Price: Call Us |
| 56 |
481035 |
Nut , Spec ial 1 -1/ 1 6 - 1 8 Price: Call Us |
| 57 |
04001-41 |
BOLT, HEX HEAD, 5/8-11 X 9-1/2 GR.5 Price: Call Us |
| 58 |
04043-06 |
Flatwasher, 5/8-.688 x 1-3/4 x .134 HD Price: Call Us |
| 59 |
482879 |
Cutter Blade, 21" (61H) Price: Call Us |
| 60 |
43590 |
Spacer, Spindle Bottom Price: Call Us |
| 61 |
04001-176 |
Bolt, Hex Head 5/16-18 x 1-3/4" Grade 8 Price: Call Us |
| 62 |
04063-08 |
Key, 1/4 x 1/4 x 2.0" Price: Call Us |
| 63 |
04040-04 |
Flatwasher, 5/16-.344 x .688 x .065 (48V / 52V) Price: Call Us |
| 64 |
04021-04 |
Nut, Center Lock, 5/16-18(32) Price: Call Us |
| 65 |
04003-23 |
Carriage Bolt, 3/8-16 x 1.0" Price: Call Us |
| 66 |
424841 |
Baffle Custom-Cut, 61V (7-Position) Price: Call Us |
| 67 |
424209 |
Turbo Baffle, Bolt On Price: Call Us |
| 68 |
482295 |
Wheel, Anti-Scalp Price: Call Us |
| 69 |
48100-15 |
Bushing, .376" I.D. Oilite Price: Call Us |
| 70 |
481632 |
Bolt, Carriage 3/8-16 x 4" Price: Call Us |
| 71 |
04021-05 |
Bolt, Hex Head 3/8-16 x 1" Ser. Flg. Price: Call Us |
| 72 |
422478 |
Bracket, Anti-Scalp Wheel Price: Call Us |
| 73 |
04003-26 |
Bolt, Hex Head 3/8-16 x 3-1/2" Price: Call Us |
| 74 |
04017-27 |
Capscrew, 3/8-16 x 1.0" Serrated Flange Hex Hd Price: Call Us |
| 75 |
461846 |
Discharge Chute Advantage - Large Price: Call Us |
| 76 |
04001-12 |
Bolt, Hex Head 5/16-18 x 1-1/2" - Front Price: Call Us |
| 77 |
483378 |
Spring, Discharge Chute Price: Call Us |
| 78 |
04001-154 |
Bolt, 5/16-18 x 4-3/4" Hex Head Price: Call Us |
| 79 |
04110-04 |
U-Nut, 3/8-16 Price: Call Us |
| 80 |
04003-42 |
Bolt, Carriage 7/16-14 x 2-1/4" Price: Call Us |
| 81 |
04021-11 |
HEX LOCKNUT, ELASTIC STOP, 7/16-14 Price: Call Us |
| 82 |
04110-03 |
U-Nut, 3/8-16 (short) Price: Call Us |
| 83 |
04107-04 |
Bolt, Hex Head 3/8-16 x 2" Special Lock Price: Call Us |
| 84 |
485528 |
Lever, Deck Level Price: Call Us |
| 85 |
483704 |
Spring, Cutter Deck Price: Call Us |
| 462132 |
Discharge |
Chute Assy. 72V Price: Call Us 462132 |
| 482882 |
Cutter |
Blade, 24-1/2" Price: Call Us 482882 |
| 483174 |
Pad, |
Deck Wear Price: Call Us 483174 |
