| Ref | Part Number | Description |
|---|
| 0010 |
7010740YP |
RETAINING RING, 2 External Price: $4.92 |
| 0020 |
7010935SM |
FW, .77X1.13X.06 Price: $3.17 |
| 0030 |
7012055YP |
ROD, Idler Control Price: $14.16 |
| 0040 |
7012670YP |
RING, 2 ID x 3/4 High, Tolerance Price: $7.34 |
| 0050 |
7014168YP |
SPRING, Blade Handle Price: $5.78 |
| 0060 |
7014304YP |
PIN, 1/4 x 1-5/8 Clevis Price: $3.61 |
| 0070 |
7014314YP |
SPACER, .31 I.D. x .39 O.D. x 1 Nylon Price: $4.41 |
| 0080 |
7015290YP |
HUB, Pulley, PM Price: $5.66 |
| 0090 |
7018781BMYP |
PULLEY, DECK ECOAT Price: $40.25 |
| 0100 |
7032027SM |
WASHER, 49/64x1-1/2x.06, Flat Price: $3.94 |
| 0110 |
7600133YP |
KIT, Brake Band, 10.1” L, 1.25” H (Formed) Price: $38.55 |
| 0120 |
7035378YP |
DRUM, Brake Spindle (3" OD, 1.6" Tall) Price: $11.11 |
| 0130 |
7036521YP |
SPRING, Extension, 4 x 1/2 Diameter Price: $6.91 |
| 0140 |
7038021YP |
MOUNT, Handle/Switch Price: $12.38 |
| 0150 |
7046677YP |
EYE-BOLT, 1/4-20 x 4” Price: $6.02 |
| 0160 |
7046782YP |
SPRING, Rectangular Wire Die, Blue Price: $11.79 |
| 0180 |
7059254YP |
WELDMENT, Blade Engagement Handle Price: $35.09 |
| 0190 |
7074467SM |
NUT, 3/4-16 Hex Jam, GR 8 Price: $3.61 |
| 0200 |
71072MA |
WASHER, FLAT .406X.81 This part replaces 703590. Price: $3.63 |
| 0210 |
703054 |
SCREW, 1/4-20X0.625 Price: $3.82 |
| 0220 |
5025018X10SM |
BOLT, 1/2-20 X 1-1/4" GD8 CZ This part replaces 7090491YP. Price: $3.82 |
| 0230 |
7090509YP |
WASHER, 1/2 Internal Tooth Lock, BZ Price: $3.82 |
| 0240 |
703409 |
NUT, 5/16-18, GR5 Price: $4.92 |
| 0250 |
703823 |
BOLT, 5/16-18X0.625 Price: $3.39 |
| 0260 |
703955 |
BOLT, 3/8-16X0.75 Price: $3.72 |
| 0270 |
703333 |
NUT, 3/8-16 Price: $4.26 |
| 0280 |
703419 |
NUT, 1/4-20 Hex Top Lock, Zinc/Clear Price: $116.65 |
| 0290 |
703332 |
WASHER Price: $3.72 |
| 0300 |
7091939YP |
NUT, 1/2-20 Hex, GR 5 ZP Price: $3.06 |
| 0310 |
704039 |
PIN, COTTER,1/16X1.31 This part replaces 1960221SM. Price: $3.82 |
| 0320 |
706001 |
WELDMENT, Idler Arm, RER Price: $24.06 |
| 0340 |
7014343YP |
BUSHING, Flange .27 ID x .35 x .4, Nylon, Black Price: $3.50 |
| 0350 |
7035728BMYP |
BRACKET FIXED IDLER E Price: $16.77 |
| 0360 |
7036526BMYP |
BRACE, FIXED IDLER EC Price: $11.29 |
| 0370 |
703985 |
SCREW, 5/16-18X.5 Price: $3.61 |
