| Ref | Part Number | Description |
|---|
| 1 |
532166819 |
CHASSIS This part replaces 532165583. Price: $97.61 |
| 2 |
532145009 |
KIT.DRAWBAR.SERVICE This part replaces 532140356. Price: $44.99 |
| 3 |
42-9830 |
DISCONTINUED Price: Call Us |
| 3 |
534200501 |
BOLT HEX PATCH 3/8-16X3/4 This part replaces 817490612. Price: $1.99 |
| 4 |
42-8100 |
COLLAR MM 304916 Price: $28.56 |
| 4 |
819131216 |
Washer 13/32 x 3/4 x 16 Ga. Price: $2.99 |
| 5 |
532155272 |
BUMPER.RUBBER.HOOD Price: $3.99 |
| 8 |
56-0750 |
CLAMP Price: $15.09 |
| 9 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
| 9 |
532154794 |
DASH/SILKSCREENED This part replaces 532156490. Price: $21.07 |
| 10 |
46-2600 |
RAIL Price: $515.33 |
| 10 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 11 |
42-8140 |
PIPE ASY. Price: $95.38 |
| 11 |
532174996 |
PANEL.DASH.LH.LTX This part replaces 532155927. Price: $9.99 |
| 13 |
532153913 |
PANEL Price: $7.99 |
| 13 |
56-0760 |
CLAMP Price: $7.97 |
| 14 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 15 |
42-8010 |
ADJ SHIM MM 409040 Price: $13.75 |
| 16 |
281-1 |
PLUG-PIPE, SQH Price: $4.56 |
| 17 |
42-7090 |
SEALING CAP Price: $27.82 |
| 17 |
532156051 |
HOOD - LT/YT This part replaces 532165378. Price: $549.99 |
| 18 |
42-7050 |
OIL GA GUIDE Price: $21.44 |
| 18 |
532126938 |
BUMPER HOOD T Price: $3.99 |
| 19 |
43-2710 |
O-RING Price: $6.47 |
| 20 |
532180679 |
PLATE MTG.BATTERY/FUEL TANK This part replaces 532156437. Price: $9.99 |
| 20 |
72-6950 |
OIL LEVEL GUAGE RETAIN. Price: $33.80 |
| 21 |
42-7160 |
PIN Price: $4.51 |
| 22 |
42-7270 |
OIL GAUGE Price: $39.93 |
| 23 |
42-9660 |
WASHER Price: $2.50 |
| 23 |
532124028 |
BUSHING.SNAP.NYL.BLK. Price: $4.99 |
| 25 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 25 |
86-6240 |
PLUG-TAPERED This part replaces 67-2570. Price: $5.11 |
| 26 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 28 |
532156880 |
GRILLE.LT.P/L HUSQVARNA.SERVIC This part replaces 532165379. Price: $256.99 |
| 29 |
532149777 |
LENS LT/PL HUSQVARNA This part replaces 532165380. Price: $24.99 |
| 30 |
583713401 |
KIT.FENDER.PNT.STL.W/CPH. This part replaces 532166505. Price: $249.99 |
| 31 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 31 |
532139976 |
BRACKET.SUPPORT.FENDER Price: $14.99 |
| 32 |
33114-016 |
SCREW-HH This part replaces 42-9230. Price: $0.27 |
| 33 |
42-8180 |
FUEL RETURN ASM Price: $39.29 |
| 34 |
2412-79 |
CLAMP-HOSE Price: $1.63 |
| 35 |
42-8190 |
JOINT MM 100088 Price: $13.50 |
| 36 |
67-2390 |
PLUG Price: $5.06 |
| 37 |
42-7290 |
GASKET-PLUG Price: $7.56 |
| 37 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 38 |
532139886 |
BRACKET LH PIVOT Price: $6.99 |
| 38 |
67-2520 |
PLUG Price: $5.65 |
| 39 |
42-8930 |
SPRING MM 407142 Price: $16.42 |
| 39 |
532139887 |
BRACKET RH PIVOT Price: $6.99 |
| 40 |
67-2500 |
PLUNGER Price: $22.88 |
| 41 |
56-1310 |
SWITCH ASM Price: $40.76 |
| 42 |
108-3841 |
FILTER-OIL This part replaces 67-4330. Price: $10.81 |
| 43 |
42-9480 |
DISCONTINUED Price: Call Us |
| 44 |
42-8920 |
DISCONTINUED Price: Call Us |
| 45 |
42-8910 |
PUMP ROTOR Price: $416.87 |
| 46 |
42-8940 |
O-RING Price: $28.65 |
| 47 |
93-3657 |
PIN DOWEL Price: $2.64 |
| 48 |
42-8900 |
PUMP BODY MM 409201 Price: $249.04 |
| 49 |
42-8950 |
BODY GASKET MM 407124 Price: $13.24 |
| 50 |
42-7180 |
DISCONTINUED Price: Call Us |
| 51 |
42-7170 |
PLUG-40 MM MF665511 Price: $11.46 |
| 51 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 52 |
42-7200 |
KNOCK BSHG MS 471110 Price: $10.16 |
| 52 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 53 |
532150067 |
BRACKET PNT PICK OFF LT/PL Price: $1.64 |
| 53 |
93-3409 |
BEARING Price: $33.38 |
| 54 |
42-7840 |
SUNK KEY Price: $9.67 |
| 55 |
42-7810 |
DISCONTINUED Price: Call Us |
| 56 |
42-7790 |
IDLER GEAR Price: $383.30 |
| 57 |
42-7780 |
DISCONTINUED Price: Call Us |
| 57 |
596230901 |
Screws This part replaces 874780412. Price: $2.99 |
| 58 |
42-7730 |
DISCONTINUED Price: Call Us |
| 58 |
532150127 |
AIR DUCT P/L/LT Price: $13.99 |
| 59 |
72-4280 |
CAM SHAFT Price: $839.96 |
| 60 |
872140606 |
Bolt Rdhd Sqnk 3/8-16unc x 3/4 Price: $4.99 |
| 62 |
48-7880 |
NUT-HEX This part replaces 43-5970. Price: $0.25 |
| 63 |
43-5920 |
WASHER-LOCK, SPRING Price: $0.25 |
| 64 |
33014-00 |
NUT-HEX Price: $0.25 |
| 64 |
532154798 |
DASH LOWER Price: $17.99 |
| 65 |
43-0370 |
DISCONTINUED Price: Call Us |
| 66 |
43-0380 |
DISCONTINUED Price: Call Us |
| 67 |
112-1359 |
ALTERNATOR This part replaces 43-0390. Price: $469.33 |
| 68 |
43-1900 |
BOLT MD 017625 Price: $17.40 |
| 68 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 69 |
54-8660 |
WASHER Price: $2.23 |
| 70 |
67-4660 |
BOLT-FLANGE Price: $2.64 |
| 71 |
43-0400 |
GEN BRACE MM 409463 Price: $68.06 |
| 72 |
42-7190 |
DISCONTINUED Price: Call Us |
| 73 |
42-9820 |
DISCONTINUED Price: Call Us |
| 74 |
56-2120 |
DISCONTINUED Price: Call Us |
| 74 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 109 |
532170310 |
BUMPER BRACKET This part replaces 532141461. Price: $4.99 |
| 110 |
532143679 |
PLUG PLASTIC Price: $2.99 |
| 113 |
532170311 |
BUMPER ASM. This part replaces 532150300. Price: $127.99 |
| 115 |
874760620 |
BOLT This part replaces 817490620. Price: $4.99 |
| 129 |
596582301 |
Washers This part replaces 819091016. Price: $2.99 |
| 134 |
532160219 |
ROD SUPPORT HOOD LT/PL HUS. Price: $7.99 |
| 140 |
532158418 |
BRACKET SUSPENSION FRONT Price: $7.99 |
| 142 |
532175702 |
PLATE REINFORCEMENT This part replaces 532165867. Price: $7.99 |
| 143 |
532186689 |
BRACKET, SWAYBAR CHASSIS This part replaces 532154966. Price: $5.99 |
| 144 |
532175582 |
BRKT, FOOT REST This part replaces 532154207. Price: $4.99 |
| 145 |
532409167 |
ROD.PIVOT.HOOD This part replaces 532156524. Price: $9.99 |
