| Ref | Part Number | Description |
|---|
| 1 |
127427 |
SUB= 140119 Price: Call Us |
| 1 |
98-7708 |
NUT Price: $7.76 |
| 2 |
140551 |
BRACKET PVT SEAT Price: Call Us |
| 2 |
98-9453 |
PULLEY-DYNAMO Price: $138.04 |
| 3 |
74760612 |
SUB= 74780612 Price: Call Us |
| 3 |
98-7709 |
COLLAR Price: $8.79 |
| 4 |
19131610 |
WASHER PM Price: Call Us |
| 4 |
98-7714 |
FRAME-END, DRIVE Price: $311.88 |
| 5 |
140407 |
CLIP PUSH - IN Price: Call Us |
| 5 |
98-7717 |
BOLT-THROUGH Price: $9.75 |
| 6 |
73680600 |
SUB= 73690600 Price: Call Us |
| 6 |
98-7716 |
SCREW-HEAD, ROUND Price: $0.91 |
| 7 |
107-0136 |
ROTOR ASM This part replaces 98-7710. Price: $268.62 |
| 7 |
124181X |
SPRING COMPRESSIO Price: Call Us |
| 8 |
17490616 |
SCREW GTV Price: Call Us |
| 8 |
98-7712 |
BEARING-BALL Price: $31.09 |
| 9 |
19131614 |
WASHER Price: Call Us |
| 9 |
98-7711 |
COVER-BEARING Price: $7.32 |
| 10 |
140552 |
SUB= 155925 Price: Call Us |
| 10 |
98-7713 |
WASHER-THRUST Price: $4.49 |
| 11 |
98-7715 |
PLATE-RETAINER Price: $9.38 |
| 12 |
121246X |
BRKT SWITCH Price: Call Us |
| 12 |
98-7718 |
BEARING-BALL Price: $34.82 |
| 13 |
121248X |
BUSHING Price: Call Us |
| 13 |
98-7719 |
FRAME-END Price: $88.65 |
| 14 |
72050411 |
SUB= 872050411 Price: Call Us |
| 14 |
98-7730 |
NUT Price: $1.31 |
| 15 |
134300 |
SPLIT SPACER Price: Call Us |
| 15 |
98-7731 |
BOLT Price: $3.94 |
| 16 |
121250X |
SPRING Price: Call Us |
| 16 |
98-7721 |
RECTIFIER ASM Price: $486.45 |
| 17 |
123976X |
SUB= 73900400 Price: Call Us |
| 17 |
98-7722 |
BUSHING-INSULATION Price: $28.44 |
| 18 |
98-7732 |
NUT Price: $1.45 |
| 19 |
110-3799 |
REGULATOR ASM This part replaces 98-7733. Price: $426.99 |
| 20 |
98-7726 |
SCREW-HEAD, ROUND Price: $0.42 |
| 21 |
139888 |
BOLT.SHLD.5/16-18 Price: Call Us |
| 21 |
98-7728 |
SCREW-HEAD, ROUND Price: $0.70 |
| 22 |
73680500 |
SUB= 73690500 Price: Call Us |
| 22 |
98-7729 |
BOLT Price: $2.35 |
| 23 |
74780814 |
BOLT Price: Call Us |
| 23 |
98-7720 |
COVER-END Price: $39.58 |
| 24 |
19171912 |
WASHER Price: Call Us |
| 24 |
98-7723 |
HOLDER-BRUSH Price: $52.72 |
| 25 |
98-7725 |
SPRING-BRUSH Price: $4.32 |
| 26 |
98-7724 |
BRUSH Price: $12.41 |
