| Ref | Part Number | Description |
|---|
| 1 |
76-8160-03 |
SUPPORT-GEAR, STEERING This part replaces 76-8160. Price: $25.24 |
| 2 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 2 |
532123583 |
SQUARE KEY Price: $3.99 |
| 3 |
323-6 |
SCREW-HH Price: $0.66 |
| 4 |
74-3670 |
DISCONTINUED Price: Call Us |
| 5 |
82-4950 |
PLUNGER-SPRING Price: $145.10 |
| 5 |
874760636 |
BOLT Price: $4.99 |
| 6 |
532124028 |
BUSHING.SNAP.NYL.BLK. Price: $4.99 |
| 6 |
74-5770 |
DISCONTINUED Price: Call Us |
| 7 |
32121-10 |
PIN-ROLL Price: $6.99 |
| 8 |
74-5790 |
SHAFT-PIVOT Price: $75.26 |
| 9 |
32121-123 |
PIN-ROLL Price: $0.81 |
| 10 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 11 |
3220-3 |
NUT-HJ Price: $0.28 |
| 12 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 13 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 14 |
76-8720 |
PANEL - TOWER Price: $86.81 |
| 15 |
233-17 |
KNOB Price: $10.58 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 16 |
72-0130 |
DISCONTINUED Price: Call Us |
| 17 |
107-2561 |
NUT-HEX This part replaces 47-6990. Price: $14.65 |
| 17 |
501487101 |
SPRING.BRAKE.VARIATOR Price: $4.99 |
| 18 |
68-8080 |
WHEEL-STEERING Price: $273.84 |
| 19 |
32144-4 |
SCREW-HWH Price: $1.29 |
| 20 |
76-9450 |
DISCONTINUED Price: Call Us |
| 21 |
77-4260 |
LINK-SHIFT Price: $48.90 |
| 22 |
323-8 |
SCREW-HH Price: $1.20 |
| 23 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 24 |
69-1560 |
DISCONTINUED Price: Call Us |
| 25 |
2410-64 |
PLUG-BUTTON Price: $0.74 |
| 26 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 27 |
76-8850 |
DISCONTINUED Price: Call Us |
| 28 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 29 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 29 |
584823102 |
ROD.BRAKE.VARIATOR.SD3.X431 This part replaces 584823101. Price: $9.99 |
| 30 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 31 |
95-1821 |
SPRING-COMPRESSION This part replaces 3-3251. Price: $6.71 |
| 32 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 33 |
76-9050 |
ROD-BRAKE, PARK Price: $33.40 |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 34 |
63-7900-03 |
RACK This part replaces 63-7900. Price: $144.55 |
| 35 |
596874801 |
Rods This part replaces 532401031. Price: $6.99 |
| 35 |
76-8140-03 |
BRACKET-GEAR, STEERING This part replaces 76-8140. Price: $70.53 |
| 36 |
31-0390 |
DISC-FRICTION Price: $11.25 |
| 37 |
20-9500 |
WASHER Price: $3.53 |
| 37 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 38 |
76-8340 |
SHAFT-PIVOT, STEERING Price: $89.60 |
| 39 |
76-8150-03 |
SUPPORT-SHAFT, STEERING This part replaces 76-8150. Price: $25.87 |
| 40 |
74-3660 |
DISCONTINUED Price: Call Us |
| 41 |
237-79 |
O-RING Price: $5.46 |
| 42 |
340-138 |
FITTING-HYD, 45 DEG Price: $31.15 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 43 |
237-22 |
O-RING Price: $2.43 |
| 44 |
76-9570 |
HYD HOSE ASM Price: $49.70 |
| 45 |
76-9560 |
HOSE ASSY Price: $58.41 |
| 46 |
59-6430 |
DISCONTINUED Price: Call Us |
| 47 |
86-5570 |
HOSE ASM Price: $151.86 |
| 48 |
76-9530 |
HOSE ASSY Price: $106.02 |
| 49 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 50 |
2412-74 |
R-CLAMP Price: $2.37 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 51 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 52 |
32128-20 |
NUT-HF Price: $0.99 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 53 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 54 |
76-8960 |
DISCONTINUED Price: Call Us |
| 55 |
3334-945 |
TIE-CABLE This part replaces 3333-975. Price: $0.43 |
| 56 |
581603801 |
BELT.V.EURO.VARIATOR Price: $59.99 |
| 64 |
589671401 |
SHAFT VARIATOR PEDAL CROSS This part replaces 532448353. Price: $49.99 |
| 67 |
582580101 |
WASHER.NYLON;13/32X13/16X.109 Price: $4.99 |
| 99 |
532435935 |
ROD.BYPASS.VARIATOR.GEN2 Price: $4.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 143 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 163 |
583971301 |
ROD.CONTROL.PEDAL.VARIATOR Price: $27.99 |
| 166 |
532429164 |
NUT.PUSH.625 Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 172 |
583974201 |
STRAP.TORQUE.VARIATOR Price: $5.99 |
| 184 |
532411484 |
HANDLE.PARKNG BRK.PRED.LT.428 Price: $24.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 195 |
581504601 |
BRACKET.BRAKE.BRAKE.VAR.SD Price: $6.99 |
| 203 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 210 |
588921002 |
WELDMENT.PEDAL.VARIATOR.X431 This part replaces 588921001. Price: $39.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 214 |
532421263 |
PEDAL.FORWARD.PAD.TEX Price: $6.99 |
| 215 |
532448254 |
CAP.PEDAL.REVERSE.VARIATOR Price: $5.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 222 |
879212010 |
WASHER 21/32 X 1-1/4 X 10 GA. Price: $3.99 |
| 263 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 268 |
583122001 |
GUARD.MUFFLER This part replaces 532182402. Price: $5.99 |
| 277 |
532448500 |
SUBASM.LINK.ROCKER.PEDAL Price: $9.99 |
| 282 |
874490548 |
BOLT HEX FLGHD 5/16-18X3 GR. 5 Price: $4.99 |
| 299 |
532415683 |
BRACKET.MOUNT.IDLERS Price: $7.99 |
| 300 |
531153901 |
SERVICE KIT IDLER KEEPER This part replaces 532415681. Price: $3.99 |
| 301 |
532415680 |
PULLEY.IDLER.V-GROOVE Price: $24.99 |
| 302 |
581420501 |
PULLEY.IDLER.FLAT.2" Price: $22.99 |
| 303 |
872110618 |
BOLT CARRIAGE Price: $4.99 |
| 306 |
596029601 |
Pins This part replaces 876020416. Price: $1.99 |
| 345 |
596136001 |
Bolts This part replaces 872110606. Price: $3.99 |
| 373 |
581461801 |
SPACER.IDLER Price: $3.99 |
| 374 |
581475201 |
ARM.CONTROL.BRAKE Price: $4.99 |
| 375 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 378 |
584287701 |
NUT.PUSH.8MM Price: $3.99 |
