| Ref | Part Number | Description |
|---|
| 1 |
144393 |
DECK.WELD.42. Price: Call Us |
| 1 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 2 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 2 |
72140506 |
BOLT Price: Call Us |
| 3 |
11-0160 |
ROLLER SHAFT SCREW ASM Price: $28.16 |
| 3 |
138017 |
BRKT ASM SWAY BAR Price: Call Us |
| 4 |
138440 |
BRKT DECK SW BAR Price: Call Us |
| 4 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 5 |
3220-3 |
NUT-HJ Price: $0.28 |
| 5 |
4939M |
SUB= 85902 Price: Call Us |
| 6 |
130832 |
SUB= 130833 Price: Call Us |
| 6 |
147-3120 |
BALL JOINT RECEIVER ASM This part replaces 99-1460. Price: $16.35 |
| 7 |
145-4593 |
HYD CYLINDER SERVICE KIT This part replaces 106-9066. Price: $633.52 |
| 8 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 8 |
850857 |
BLADE BOLT Price: Call Us |
| 9 |
10030600 |
SUB= 10040600 Price: Call Us |
| 9 |
5-1226 |
WASHER Price: $3.90 |
| 10 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 10 |
140296 |
WASHER.HARD.BLADE Price: Call Us |
| 11 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 12 |
129895 |
BEARING.BALL Price: Call Us |
| 12 |
HY4486 |
NUT UNF 1/2"NYLOC EXT THIN5/16 This part replaces 283-8. Price: $1.36 |
| 13 |
137645 |
SUB= 137646 Price: Call Us |
| 13 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 14 |
110-3952 |
SPRING-TORSION, LH This part replaces 106-9079. Price: $9.40 |
| 14 |
128774 |
HSG ASM MANDREL Price: Call Us |
| 15 |
110485X |
BEARING Price: Call Us |
| 15 |
322-1 |
SCREW-HH Price: $0.22 |
| 16 |
105-3828 |
SPACER Price: $5.10 |
| 16 |
140329 |
STRIPPER RND MWR Price: Call Us |
| 17 |
140-5248 |
PIN-PIVOT RAM, WELDED This part replaces 10-6060. Price: $25.64 |
| 17 |
72110618 |
BOLT CARRIAGE Price: Call Us |
| 18 |
115-3259 |
KIT-SERVICE, PIN This part replaces 10-6110. Price: $39.21 |
| 18 |
72140505 |
BOLT Price: Call Us |
| 19 |
10-7820 |
PIVOT HINGE ASM Price: $504.57 |
| 19 |
132827 |
BOLT SHD 5/16-18 Price: Call Us |
| 20 |
136888 |
SUB= 918136888 Price: Call Us |
| 20 |
137-9706 |
DECAL-WARNING This part replaces 93-8064. Price: $4.48 |
| 21 |
136-8484 |
FRAME-PULL, LH This part replaces 104-2054. Price: $382.66 |
| 21 |
73680500 |
SUB= 73690500 Price: Call Us |
| 22 |
134753 |
STIFFENER BRKT Price: Call Us |
| 22 |
138-6311 |
ARM-PULL-ASSEMBLY-LH This part replaces 92-0586. Price: $29.91 |
| 23 |
131267 |
DEFLECTOR BRKT Price: Call Us |
| 23 |
133-2337 |
ROLLER ASM This part replaces 99-4277. Price: $176.14 |
| 24 |
105304X |
CAP-SLEEVE LT Price: Call Us |
| 24 |
3290-317 |
WASHER-SPRING Price: $1.40 |
| 25 |
123713X |
SPRING TORSION Price: Call Us |
| 25 |
131-4295 |
PIN-PIVOT This part replaces 10-6090. Price: $51.39 |
| 26 |
110452X |
NUT PUSH M Price: Call Us |
| 26 |
138-6303 |
ARM-PULL-ASSEMBLY-RH This part replaces 92-0585. Price: $29.91 |
| 27 |
130968 |
DEFLECTOR.SHIELD Price: Call Us |
| 27 |
21-8470 |
SHAFT-ROLLER Price: $62.10 |
| 28 |
19111016 |
WASHER Price: Call Us |
| 28 |
74-3730 |
SPACER-SPINDLE, REAR Price: $5.06 |
| 29 |
131491 |
HINGE ROD Price: Call Us |
| 29 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 30 |
138776 |
SUB= 157722 Price: Call Us |
| 30 |
83-1690 |
HOSE-HYD Price: $68.48 |
| 31 |
129963 |
WASHER Price: Call Us |
| 31 |
63-3850 |
HOSE ASM Price: $83.26 |
| 32 |
153535 |
PULLEY.MANDREL.42 Price: Call Us |
| 32 |
94-4548 |
BUMPER-RECESSED Price: $4.68 |
| 33 |
137266 |
SUB= 139729 Price: Call Us |
| 33 |
32144-44 |
SCREW-HWH, THREAD ROLL Price: $1.39 |
| 34 |
107-2598 |
LH LIFT ARM ASM Price: $139.43 |
| 34 |
72110622 |
BOLT Price: Call Us |
| 35 |
105-5740 |
HOOK-LIFT Price: $13.14 |
| 35 |
133835 |
XMAS TREE FASTNER Price: Call Us |
| 36 |
131494 |
FLAT IDLER PULLEY Price: Call Us |
| 37 |
19131316 |
WASHER Price: Call Us |
| 38 |
132823 |
SUB= 532132823 Price: Call Us |
| 40 |
73680600 |
SUB= 73690600 Price: Call Us |
| 44 |
140088 |
GUARD MAND LH BLK Price: Call Us |
| 46 |
137729 |
SCREW.1/4-20X5/8 Price: Call Us |
| 54 |
133943 |
HARDENED WASHER Price: Call Us |
| 55 |
140084 |
SUB= 151785 Price: Call Us |
| 56 |
122052X |
SPACER RETAINER Price: Call Us |
| 59 |
141043 |
GUARD IDLER TUV Price: Call Us |
| 61 |
131950 |
SPRING.EXTENSION Price: Call Us |
| 68 |
144959 |
BELT-V.SEC.46.KEL Price: Call Us |
| 84 |
158824 |
BRACKET ASM IDLER Price: Call Us |
| 111 |
155197 |
BRACKET.GWHL.LH. Price: Call Us |
| 112 |
155198 |
BRACKET.GWHL.RH. Price: Call Us |
| 113 |
17490512 |
SCREW Price: Call Us |
| 114 |
73510500 |
NUT Price: Call Us |
| 115 |
72110504 |
SUB= 872110504 Price: Call Us |
| 116 |
4898H |
BOLT M Price: Call Us |
| 117 |
105455X |
WHEEL.GAGE.BLK.PL Price: Call Us |
| 118 |
73930600 |
LOCKNUT Price: Call Us |
| 119 |
19121414 |
WASHER Price: Call Us |
| 120 |
19171512 |
WASHER Price: Call Us |
| 121 |
143723 |
BRACKET.EXTRD.GWL Price: Call Us |
| 125 |
76020816 |
COTTER PIN Price: Call Us |
| 128 |
153390 |
WASHER.FELT. Price: Call Us |
| 132 |
19132203 |
WASHER GT Price: Call Us |
| 133 |
72110622 |
BOLT Price: Call Us |
| 130794 |
MANDREL |
ASM Price: Call Us 130794 |
