| Ref | Part Number | Description |
|---|
| 1 |
532439822 |
SEAT.TH150.MS498.GRY.HUSQ.TEX Price: $159.99 |
| 1 |
98-7430 |
O-RING Price: $1.95 |
| 1 |
MA-19561901000 |
DRIVE SHAFT MFD Not Available Price: |
| 2 |
107-9075 |
PLUG-FILLER, OIL This part replaces 98-9449. Price: $7.25 |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $11.99 |
| 2 |
MA-102319150C1 |
JOINT COLLAR Not Available This part replaces MA-10231915000. Price: |
| 3 |
532140675 |
STRAP Price: $5.99 |
| 3 |
98-9455 |
NUT-CAP Price: $4.77 |
| 3 |
MA-10291943000 |
COUPLER-MFD SHAFT Not Available Price: |
| 4 |
98-9454 |
GASKET Price: $1.43 |
| 4 |
MA-07400102000 |
RING, SNAP Not Available Price: |
| 5 |
98-9492 |
JOINT-PIPE, BREATHER Price: $9.68 |
| 5 |
MA-19561904AG0 |
COVER-MFD SHAFT A Not Available Price: |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 6 |
98-9491 |
PIPE-BREATHER Price: $12.92 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 7 |
98-9364 |
SCREW (WITH WASHER) Price: $0.32 |
| 7 |
MA-H1540108020 |
BOLT,W/WASHER Not Available Price: |
| 8 |
98-9490 |
SHIELD-OIL, BREATHER Price: $1.28 |
| 8 |
MA-19561905AG0 |
COVER-MFD SHAFT B Not Available Price: |
| 9 |
98-9488 |
PLATE-ELEMENT, BREATHER Price: $1.33 |
| 9 |
MA-00505000500 |
CLAMP-MFD COVER Not Available Price: |
| 10 |
596768801 |
KIT.PLATE.SEAT This part replaces 532196977. Price: $49.99 |
| 10 |
98-9493 |
ELEMENT-BREATHER Price: $6.10 |
| 10 |
MA-19561906000 |
PIPE-CONNECTOR Not Available Price: |
| 11 |
98-9489 |
PLATE-ELEMENT, BREATHER Price: $7.89 |
| 12 |
98-9615 |
GASKET-COVER, HEAD Price: $20.34 |
| 13 |
98-9614 |
CYLINDER HEAD COVER ASM Price: $256.63 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 37 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 40 |
595088102 |
Handles This part replaces 532439871. Price: $4.99 |
| 41 |
532198200 |
SPRING.LATCH.SEAT.TEX Price: $3.99 |
| 43 |
874760612 |
BOLT Price: $3.99 |
| 44 |
583789501 |
WASHER.13/32x2 3/8x12GA This part replaces 819133812. Price: $4.99 |
