| Ref | Part Number | Description |
|---|
| 1 |
115-6694 |
YOKE-LIFT This part replaces 110-8111-01. Price: $77.72 |
| 1 |
530037793 |
Foam- Air Filter Price: $1.99 |
| 2 |
110-8110 |
SPACER Price: $13.38 |
| 2 |
530016101 |
Nut Price: $1.99 |
| 3 |
110-8114 |
WASHER Price: $4.14 |
| 3 |
530049244 |
Grommet-Carb Adjust Price: $1.99 |
| 4 |
530038479 |
Limiter Cap-High Price: $1.99 |
| 4 |
66-7230 |
SPRING-COMPRESSION Price: $9.25 |
| 5 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 5 |
530038478 |
Limiter Cap-Low Price: $1.99 |
| 6 |
3211-12 |
SCREW-HH Price: $1.70 |
| 6 |
530054144 |
Seal-Carb Adapter Price: $2.99 |
| 7 |
3220-3 |
NUT-HJ Price: $0.28 |
| 7 |
530049700 |
Carb. Adapter Price: $3.99 |
| 8 |
92-7008 |
END-ROD, FEMALE Price: $49.99 |
| 9 |
110-8108 |
ROD-LINK Price: $24.52 |
| 10 |
530047127 |
CYLINDER This part replaces 530069606. Price: $59.99 |
| 11 |
530016136 |
Clip-High Tension Lead Price: $1.99 |
| 12 |
530016153 |
Screw Price: $1.99 |
| 13 |
530037798 |
Shield-Cylinder Price: $2.88 |
| 14 |
530071835 |
Kit-Purge Bulb This part replaces 530047213. Price: $5.99 |
| 15 |
530015780 |
Screw Price: $1.99 |
| 16 |
530095646 |
Assy-Fuel Pick-up Price: $2.99 |
| 17 |
530037652 |
Insulator-Heat Price: $1.99 |
| 18 |
530052296 |
Assy. - Wire Harness Price: $4.99 |
| 20 |
530047442 |
Strap - Ground Price: $1.99 |
| 21 |
530039198 |
Module- Ignition Price: $29.99 |
| 22 |
530015814 |
Screw Price: $1.99 |
| 24 |
530016132 |
Screw Price: $1.99 |
| 25 |
530036103 |
Screen-Spark Price: Call Us |
| 26 |
530037813 |
Diffuser-Muffler Price: $1.99 |
| 28 |
530049870 |
Backplate-Muffler Price: $3.99 |
| 29 |
545113101 |
CRANKSHAFT ASSY This part replaces 530047062. Price: $54.99 |
| 30 |
530037935 |
Cap-Crankcase Price: $8.99 |
| 31 |
530056363 |
Assy.-Seal & Bearing Price: $11.99 |
| 33 |
530015697 |
Retainer-Piston Pin Price: $1.99 |
| 34 |
530029805 |
Ring - Piston Price: $2.99 |
| 36 |
530016187 |
Screw Price: $1.99 |
| 37 |
530016386 |
Screw Price: $5.99 |
| 40 |
530057480 |
Housing- Air Filter This part replaces 530037804. Price: $4.99 |
| 41 |
530031163 |
Wrench - Bar Price: $4.99 |
