| Ref | Part Number | Description |
|---|
| 1 |
532146315 |
SCREW Price: $8.99 |
| 1 |
93-2085-01 |
ROD ASM Price: $134.61 |
| 2 |
532751153 |
NUT.LOCK.5/16-18 Price: $2.99 |
| 2 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 3 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 4 |
49-6440-03 |
PEDAL-FORWARD Price: $84.90 |
| 4 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 5 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 5 |
532180017 |
BEARING, FLANGE Price: $22.99 |
| 6 |
33124-020 |
SCREW-CARR Price: $0.88 |
| 6 |
532180134 |
SHAFT, AUXILIARY Price: $6.99 |
| 7 |
532179270 |
SPACER, PLATE Price: $9.99 |
| 8 |
532192616 |
PLATE.AUXILIARY.BLACK This part replaces 532192907. Price: $4.99 |
| 8 |
93-2142 |
DISCONTINUED Price: Call Us |
| 9 |
105-9750-01 |
PLATE-FLOOR This part replaces 94-6399-01. Price: $194.85 |
| 10 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 10 |
532180065 |
GEAR, PINION Price: $12.99 |
| 11 |
532187714 |
ROD.CLUTCH.YELLOW.ZINC Price: $9.99 |
| 11 |
94-1371 |
SPACER Price: $14.81 |
| 12 |
532180066 |
SHAFT.HEX.LONG Price: $84.99 |
| 12 |
94-1383 |
PEDAL-PIVOT Price: $229.74 |
| 13 |
256-311 |
BUSHING-SPLIT Price: $13.37 |
| 13 |
532178807 |
PIN, PIVOT Price: $3.99 |
| 14 |
33115-090 |
SCREW-HH Price: $13.76 |
| 14 |
532184080 |
LEVER, SPEED CONTROL Price: $12.99 |
| 15 |
33023-00 |
NUT-LOCK Price: $0.25 |
| 15 |
597412801 |
BEARING HOUSING ASSY TRUNNION This part replaces 532175344. Price: $29.99 |
| 16 |
107-2550 |
CABLE-CONTROL, TRACTION This part replaces 93-2099. Price: $194.40 |
| 16 |
532435793 |
BRACKET.SHIFT.PIVOT.BLACK This part replaces 532187857. Price: $5.99 |
| 17 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 17 |
585021001 |
RING.RUBBER.4.5".SNOW.DR(2 2MC This part replaces 532179831. Price: $22.99 |
| 18 |
17-9420 |
SCREW-HANDLE Price: $3.49 |
| 18 |
532435789 |
PLATE.RUBBER.WHEEL.BLACK This part replaces 532199509. Price: $7.99 |
| 19 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 19 |
94-1373 |
BRACKET-LOCK Price: $24.82 |
| 20 |
532178613 |
HUB, RUBBER WHEEL Price: $22.99 |
| 20 |
94-1372 |
BRACKET-MOW Price: $18.44 |
| 21 |
596322201 |
BOLT HEXAGON BOLT 5/16-18 X 7/ This part replaces 874760514. Price: $2.99 |
| 21 |
94-1375 |
TRUNNION-BRACKET, LOCK Price: $23.45 |
| 22 |
532085179 |
RETAINER CLIP PM Price: $3.99 |
| 22 |
94-1374 |
TRUNNION-BRACKET, MOW Price: $14.18 |
| 23 |
532180135 |
SPRING, BIAS Price: $3.99 |
| 23 |
94-1386 |
SHAFT-PEDAL Price: $44.42 |
| 24 |
94-1304 |
CABLE-LOCK, NEUTRAL Price: $153.45 |
| 25 |
32128-20 |
NUT-HF Price: $0.99 |
| 25 |
532178695 |
PIN, PIVOT LEVER Price: $4.99 |
| 26 |
532197763 |
DRIVE PLATE WELDMENT Price: $54.99 |
| 26 |
94-3489 |
SCREW-HH Price: $1.70 |
| 27 |
140-6108 |
PIN-FLAG, NEUTRAL LOCK This part replaces 94-1300. Price: $31.21 |
| 27 |
532404307 |
SHAFT.AXLE.POWER.STEERING Price: $59.99 |
| 28 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 28 |
532197764 |
SHAFT.HEX.SHORT Price: $11.99 |
| 29 |
2411-34 |
JOINT-BALL Price: $29.99 |
| 29 |
532184077 |
LEVER.SHIFTER.PLATE.BLACK Price: $9.99 |
| 30 |
3296-13 |
NUT-LOCK, NI Price: $0.34 |
| 30 |
532175349 |
BRACKET, SHIFTER SUPPORT This part replaces 532184076. Price: $4.99 |
| 31 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872270505. Price: $2.99 |
| 31 |
93-2092 |
CLAMP-CABLE Price: $3.46 |
| 32 |
33114-016 |
SCREW-HH Price: $0.27 |
| 32 |
532189282 |
KEY, SQUARE 1/4 X .875 Price: $4.99 |
| 33 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 33 |
532188909 |
BEARING FLANGE Price: $24.99 |
| 34 |
532184075 |
PLATE.DRIVE.MOUNTING.BLACK Price: $14.99 |
| 34 |
93-2279 |
CLAMP-CABLE Price: $7.12 |
| 35 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 35 |
532182504 |
SPACER, BEARING Price: $5.99 |
| 36 |
33115-016 |
SCREW-HH Price: $0.75 |
| 36 |
532191080 |
PULLEY.TRACTION.7.75 Price: $49.99 |
| 37 |
33014-00 |
NUT-HEX Price: $0.25 |
| 37 |
596039201 |
GSPW Hardware This part replaces 532155377. Price: $2.99 |
| 38 |
2411-38 |
JOINT-BALL Price: $21.96 |
| 38 |
819111507 |
WASHER, FLAT Price: $4.99 |
| 39 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 40 |
874950512 |
Screw, Hex Head 5/16-18 x 3/4 Price: $3.99 |
| 41 |
583607301 |
RING.RETAINING. This part replaces 812000012. Price: $2.99 |
| 43 |
532179095 |
SPRING.RETURN Price: $3.99 |
