| Ref | Part Number | Description |
|---|
| 1 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 1 |
539120899 |
GRIP Price: $11.99 |
| 2 |
539120160 |
LEVER UPPER Price: $89.99 |
| 3 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 3 |
539117949 |
FORWARD STOP RH Price: $29.99 |
| 4 |
539117950 |
FORWARD STOP LH Price: $29.99 |
| 5 |
539120984 |
PIVOT RH (PLATED) Price: $64.99 |
| 5 |
66-8460-01 |
MOUNTING BRACKET This part replaces 66-8460. Price: $68.73 |
| 6 |
539120983 |
PIVOT LH (PLATED) Price: $59.99 |
| 7 |
539114453 |
DAMPENER, DUAL ACTION Price: $49.99 |
| 7 |
70-7920 |
PIN-LOCK Price: $21.78 |
| 8 |
12-3270 |
SCREW Price: $3.09 |
| 8 |
539120159 |
LEVER.PLATED.RH Price: $89.99 |
| 9 |
539120162 |
LEVER PLATED LH Price: $29.99 |
| 9 |
66-8420-03 |
END-SPRING ASM This part replaces 66-8420. Price: $52.26 |
| 10 |
46-3380 |
BOLT-SHOULDER Price: $9.57 |
| 10 |
596582201 |
Bolts This part replaces 539976935. Price: $2.99 |
| 11 |
539101332 |
HCS 1/2C X 2 3/4 Price: $4.99 |
| 11 |
66-8450-01 |
KNEE BRACKET This part replaces 66-8450. Price: $22.51 |
| 12 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 12 |
595086801 |
Washers This part replaces 539990250. Price: $2.99 |
| 13 |
539911121 |
WASH 5/8 BEVELED DISC SPRING Price: $3.99 |
| 13 |
66-8390-03 |
SPRING-EXTENSION This part replaces 66-8390. Price: $35.15 |
| 14 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 14 |
70-7940-03 |
END-SPRING ASM This part replaces 70-7940. Price: $52.21 |
| 15 |
283-69 |
PIN-CLEVIS Price: $3.32 |
| 15 |
595901601 |
GSPW Bolts This part replaces 539990316. Price: $2.99 |
| 16 |
596437101 |
Screws This part replaces 539108396. Price: $2.99 |
| 16 |
99-1298 |
SPRING COVER ASM This part replaces 70-7970. Price: $56.24 |
| 17 |
596582601 |
Nuts This part replaces 539990196. Price: $2.99 |
| 18 |
539115638 |
ZERK, 3/16, DRIVE IN Price: $4.99 |
| 19 |
539120956 |
BUSHING Price: $2.99 |
| 20 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 21 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 22 |
539108010 |
NUT 1/2-13 HEX JM NYL Price: $2.99 |
| 23 |
539115570 |
WASHER-.626IDX.056TK Price: $2.99 |
| 24 |
594977001 |
Nuts This part replaces 539110340. Price: $4.99 |
| 25 |
539991003 |
BOLT 1/4C X 1 3/4 Price: $2.99 |
| 26 |
597357701 |
Nuts This part replaces 539991112. Price: $2.99 |
| 27 |
539119087 |
BUSHING Price: $7.99 |
| 28 |
539976937 |
HCS 5/16-18X2 Price: $2.99 |
| 29 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
