| Ref | Part Number | Description |
|---|
| 1 |
115-8047-01 |
NO. 3 LIFT ARM ASM This part replaces 92-9291-01. Price: $1,059.77 |
| 1 |
122147X |
KEY Price: Call Us |
| 2 |
110859X |
HARNESS T Price: Call Us |
| 2 |
68-6480 |
BUSHING-FLANGE Price: $3.19 |
| 3 |
325-17 |
SCREW-HH Price: $2.90 |
| 3 |
7662J |
SUB= 4152J Price: Call Us |
| 4 |
323-7 |
SCREW-HH Price: $0.65 |
| 4 |
4406R |
SUB= STD365402 Price: Call Us |
| 6 |
109788X |
SUB= 124211X Price: Call Us |
| 6 |
52-6180 |
SPACER Price: $1.65 |
| 7 |
110712X |
SWITCH LT Price: Call Us |
| 7 |
60-3250 |
WASHER Price: $5.21 |
| 8 |
109081X |
SUB= 146154 Price: Call Us |
| 8 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 9 |
10090400 |
SUB= 10040400 Price: Call Us |
| 9 |
3256-56 |
WASHER-FLAT Price: $1.15 |
| 10 |
73350400 |
NUT Price: Call Us |
| 10 |
92-9246-03 |
A-FRAME Price: $525.35 |
| 11 |
325-7 |
SCREW-HH Price: $1.53 |
| 11 |
74780408 |
BOLT Price: Call Us |
| 12 |
11050400 |
LOCKWASHER Price: Call Us |
| 12 |
115-8046-01 |
NO. 2 LIFT ARM ASM This part replaces 92-9290-01. Price: $933.22 |
| 13 |
73510400 |
NUT Price: Call Us |
| 14 |
60-1280 |
PIN Price: $3.53 |
| 14 |
719J |
SUB= 154336 Price: Call Us |
| 15 |
122918X |
HARNESS Price: Call Us |
| 15 |
58-4380 |
PIN Price: $25.11 |
| 17 |
109670X |
CABLE LT Price: Call Us |
| 17 |
115-8017 |
REEL MOTOR KIT This part replaces 93-1412. Price: $1,999.51 |
| 18 |
3246-17 |
SETSCREW-HSH Price: $0.47 |
| 18 |
4207J |
CABLE T Price: Call Us |
| 19 |
109596X |
HOSE CLAMP T Price: Call Us |
| 19 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 20 |
121265X |
SUB= 123899X Price: Call Us |
| 20 |
323-14 |
SCREW-HH Price: $1.34 |
| 21 |
100541K |
SUB= 7697J Price: Call Us |
| 21 |
324-6 |
SCREW-HH Price: $0.81 |
| 22 |
104445X |
SWITCH-INTER. GT Price: Call Us |
| 23 |
17021008 |
SCREW Price: Call Us |
| 24 |
108824X |
FUSE HYT Price: Call Us |
| 25 |
74760412 |
BOLT LT Price: Call Us |
| 26 |
19091016 |
WASHER Price: Call Us |
| 26 |
340-87 |
FITTING-ELBOW, 45 DEG Price: $18.39 |
| 27 |
10040400 |
LOCKWASHER Price: Call Us |
| 28 |
73220400 |
SUB= 50675 Price: Call Us |
| 29 |
123198X |
SUB= 146525 Price: Call Us |
| 31 |
102476X |
SUB= 150109 Price: Call Us |
| 31 |
115-8011 |
CYLINDER-HYD This part replaces 104-5225. Price: $784.12 |
| 32 |
72240460 |
BOLT Price: Call Us |
| 32 |
93-7331 |
DECAL-WARNING Price: $10.35 |
| 33 |
121433X |
SUB= 122822X Price: Call Us |
| 34 |
325-34 |
SCREW-HH Price: $2.37 |
| 36 |
235R |
CLIPT Price: Call Us |
| 37 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 38 |
73680400 |
SUB= 73690400 Price: Call Us |
| 39 |
109553X |
SWITCH INTERLOCKT Price: Call Us |
| 39 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 42 |
71031008 |
SCREW Price: Call Us |
| 44 |
102501X |
SUB= 141940 Price: Call Us |
| 45 |
121305X |
SWITCH SEAT Price: Call Us |
| 46 |
11050600 |
LOCKWASHER Price: Call Us |
| 47 |
109787X |
SUB= 147626 Price: Call Us |
| 101539X |
SHEET |
INSTR LT Price: Call Us 101539X |
| 129618 |
NLA |
Price: Call Us 129618 |
