| Ref | Part Number | Description |
|---|
| 1 |
174619 |
Chassis Price: Call Us |
| 1 |
98-9462 |
ELEMENT-PUMP Price: $282.73 |
| 2 |
176554 |
Drawbar Price: Call Us |
| 2 |
98-9423 |
O-RING Price: $6.07 |
| 3 |
17060612 |
Screw 3/8-16x3/4 Price: Call Us |
| 3 |
98-9443 |
PIN-JOINT Price: $13.13 |
| 4 |
98-9434 |
FLANGE-SLEEVE Price: $17.25 |
| 5 |
98-9421 |
VALVE-DELIVERY Price: $116.98 |
| 6 |
98-9424 |
SPRING-VALVE, DELIVERY Price: $21.66 |
| 7 |
98-9425 |
GASKET-VALVE, DELIVERY Price: $10.58 |
| 8 |
98-9447 |
O-RING Price: $18.23 |
| 9 |
163976X428 |
Dash Price: Call Us |
| 9 |
98-9652 |
HOLDER-VALVE, DELIVERY Price: $111.74 |
| 10 |
72140608 |
Bolt 3/8-16 x 1 Price: Call Us |
| 10 |
98-9452 |
SCREW Price: $7.23 |
| 11 |
167203 |
Panel Dash Lh Price: Call Us |
| 11 |
98-9422 |
TAPPET ASM Price: $275.51 |
| 12 |
98-9433 |
SHIM Price: $2.13 |
| 13 |
178298 |
Panel Dash Rh Price: Call Us |
| 13 |
98-9429 |
SEAT-SPRING, LOWER Price: $50.60 |
| 14 |
17490608 |
Screw Thdrol 3/8-16 x 1/2 Price: Call Us |
| 14 |
98-9428 |
SPRING-PLUNGER Price: $32.36 |
| 15 |
98-9427 |
SEAT-SPRING, UPPER Price: $16.02 |
| 16 |
98-9432 |
SLEEVE-CONTROL Price: $107.77 |
| 17 |
175260X428 |
Hood Price: Call Us |
| 17 |
98-9466 |
PLUG Price: $12.54 |
| 18 |
98-9451 |
GASKET Price: $1.92 |
| 19 |
98-9445 |
GASKET Price: $1.84 |
| 20 |
162026 |
Plate Battery Price: Call Us |
| 20 |
98-9464 |
BOLT-JOINT Price: $20.48 |
| 21 |
98-9446 |
GASKET Price: $2.50 |
| 22 |
98-9430 |
SCREW Price: $19.45 |
| 23 |
98-9643 |
INJECTION PUMP ASM This part replaces 98-9463. Price: $2,551.99 |
| 24 |
98-9465 |
PLATE Price: $9.73 |
| 25 |
98-9442 |
SCREW Price: $26.58 |
| 26 |
73800600 |
Nut Lock Hex W/Ins 3/8-16 Unc Price: Call Us |
| 26 |
98-9426 |
PIN-GUIDE, TAPPET Price: $7.65 |
| 28 |
175289X428 |
Grille Price: Call Us |
| 29 |
179761 |
Light Asm. Bar Price: Call Us |
| 30 |
179131X428 |
Fender Price: Call Us |
| 31 |
139976 |
Bracket Fender Price: Call Us |
| 37 |
17490508 |
Screw Thdrol 6/16-18 x 1/2 TYT Price: Call Us |
| 38 |
175710 |
Bracket, Asm. Pivot Mower Rear Price: Call Us |
| 54 |
161464 |
Screw Hex Wshd 8-18 x 7/8 Price: Call Us |
| 58 |
175351 |
Duct Hood Price: Call Us |
| 59 |
177579 |
Bushing Snap Price: Call Us |
| 60 |
72140606 |
Bolt Rd Hd Sqnk 3/8-16 Unc x 3/4 Price: Call Us |
| 64 |
174997 |
Dash Lower Price: Call Us |
| 74 |
73680600 |
Nut Crownlock 3/8-16 Unc Price: Call Us |
| 90 |
124346X |
Nut Self-Thd Wsh-Hd 1/4 Zinc Price: Call Us |
| 142 |
175702 |
Plate Reinforcement STLT Price: Call Us |
| 143 |
154966 |
Bracket Swaybar Chassis Price: Call Us |
| 144 |
175582 |
Bracket Footrest Price: Call Us |
| 145 |
156524 |
Rod Pivot Chassis/Hood Price: Call Us |
| 154 |
161897 |
Bracket Dash Rh Price: Call Us |
| 155 |
161900 |
Bracket Dash Lh Price: Call Us |
| 156 |
163805 |
Striker Plate Price: Call Us |
| 157 |
163806 |
Magnet Stealth Price: Call Us |
| 158 |
162037 |
Bracket Parking Brake Price: Call Us |
| 159 |
179950X428 |
Cupholder Price: Call Us |
| 161 |
164655 |
Extrusion Bumper Price: Call Us |
| 166 |
171875 |
Screw Hw Hd Hi-Lo #13-16 x 3/4 Price: Call Us |
| 209 |
17000612 |
Screw Hexwsh Thdrol 3/8-16 x 3/4 Price: Call Us |
| 213 |
169848X428 |
Skirt Grille LH Price: Call Us |
| 214 |
169847X428 |
Skirt Grille RH Price: Call Us |
