| Ref | Part Number | Description |
|---|
| 1 |
98-3929 |
SPRING-TORSION Price: $23.85 |
| 2 |
104-1805 |
SPRING-TORSION, LH Price: $29.15 |
| 2 |
73680500 |
SUB= 73690500 Price: Call Us |
| 3 |
323-7 |
SCREW-HH Price: $0.65 |
| 3 |
72110506 |
SUB= 72270506 Price: Call Us |
| 4 |
5-1096 |
CHAIN-LIFT Price: $18.82 |
| 4 |
7631J |
RUNNER-LH M Price: Call Us |
| 5 |
138457 |
BRKT.ASM.SW.44/50 Price: Call Us |
| 5 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 6 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 6 |
4939M |
SUB= 85902 Price: Call Us |
| 7 |
130832 |
SUB= 130833 Price: Call Us |
| 7 |
75-5390 |
ROLLER Price: $56.69 |
| 8 |
75-5400 |
PIN-ROLLER Price: $26.06 |
| 8 |
850857 |
BLADE BOLT Price: Call Us |
| 9 |
10030600 |
SUB= 10040600 Price: Call Us |
| 9 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 10 |
140296 |
WASHER.HARD.BLADE Price: Call Us |
| 10 |
32151-61 |
RING-RETAINING Price: $2.39 |
| 11 |
100-3892-03 |
BRACKET-TIPPER, REAR Price: $42.76 |
| 12 |
100-3866-03 |
SUPPORT-TIPPER BRACKET, RH Price: $69.36 |
| 12 |
129895 |
BEARING.BALL Price: Call Us |
| 13 |
100-3867-03 |
SUPPORT-TIPPER BRACKET, LH Price: $69.36 |
| 13 |
137553 |
SHAFT.ASM.W/BRNG Price: Call Us |
| 14 |
137152 |
HOUSING.MAND.44.V Price: Call Us |
| 14 |
323-8 |
SCREW-HH Price: $1.20 |
| 15 |
110485X |
BEARING Price: Call Us |
| 15 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 16 |
140329 |
STRIPPER RND MWR Price: Call Us |
| 16 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 17 |
106735X |
ROD-HINGE T Price: Call Us |
| 17 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 18 |
19111016 |
WASHER Price: Call Us |
| 18 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 19 |
105-0126-03 |
LH PIVOT ROD ASM Price: $130.91 |
| 19 |
105304X |
CAP-SLEEVE LT Price: Call Us |
| 20 |
105-0127-03 |
RH PIVOT ROD ASM Price: $142.57 |
| 20 |
123713X |
SPRING TORSION Price: Call Us |
| 21 |
137607 |
BRKT DEFLECTOR Price: Call Us |
| 22 |
110452X |
NUT PUSH M Price: Call Us |
| 23 |
110509X |
DEFLECTOR Price: Call Us |
| 25 |
19111216 |
WASHER M Price: Call Us |
| 27 |
19131316 |
WASHER Price: Call Us |
| 28 |
132823 |
SUB= 532132823 Price: Call Us |
| 29 |
73800600 |
NUT Price: Call Us |
| 30 |
138776 |
SUB= 157722 Price: Call Us |
| 31 |
137266 |
SUB= 139729 Price: Call Us |
| 32 |
153535 |
PULLEY.MANDREL.42 Price: Call Us |
| 33 |
129963 |
WASHER Price: Call Us |
| 34 |
72140610 |
BOLT.3/8-14X1.25 Price: Call Us |
| 35 |
72110616 |
BOLT Price: Call Us |
| 36 |
72110608 |
BOLT D Price: Call Us |
| 37 |
137166 |
STIFFENER.ARM.IDL Price: Call Us |
| 39 |
131494 |
FLAT IDLER PULLEY Price: Call Us |
| 42 |
72140506 |
BOLT Price: Call Us |
| 44 |
122052X |
SPACER RETAINER Price: Call Us |
| 45 |
73680600 |
SUB= 73690600 Price: Call Us |
| 46 |
74760628 |
BOLT Price: Call Us |
| 48 |
137729 |
SCREW.1/4-20X5/8 Price: Call Us |
| 49 |
136574 |
COVER.MANDREL.LH Price: Call Us |
| 50 |
137272 |
ARM.IDLER.PRIMARY Price: Call Us |
| 52 |
139245 |
PULLEY.IDLER.VGRO Price: Call Us |
| 53 |
137789 |
SHIELD.IDLER.44.V Price: Call Us |
| 54 |
139573 |
BELT V PRIM 50 Price: Call Us |
| 55 |
144959 |
BELT-V.SEC.46.KEL Price: Call Us |
| 56 |
138687 |
SPRING.EXT.DECK. Price: Call Us |
| 57 |
136577 |
BAR.ASM.GUAGE.WHL Price: Call Us |
| 58 |
146850 |
WHEEL.GUAGE.MED. Price: Call Us |
| 59 |
146851 |
BOLT.SHOULDER Price: Call Us |
| 60 |
139031 |
PIN.CLEVIS Price: Call Us |
| 61 |
136573 |
BRACKET.GUAGE.WHL Price: Call Us |
| 62 |
133943 |
HARDENED WASHER Price: Call Us |
| 63 |
72110612 |
BOLT.3/8-16X1.50 Price: Call Us |
| 64 |
19121414 |
WASHER Price: Call Us |
| 65 |
151831 |
PULLEY IDELR FLAT Price: Call Us |
| 67 |
73930600 |
LOCKNUT Price: Call Us |
| 94 |
74760616 |
BOLT Price: Call Us |
| 95 |
132274 |
SUB= 532132274 Price: Call Us |
| 96 |
132273 |
SUB= 532132273 Price: Call Us |
| 97 |
19171416 |
WASHER Price: Call Us |
| 98 |
132264 |
SUB= 532132264 Price: Call Us |
| 99 |
72110614 |
BOLT Price: Call Us |
| 102 |
153390 |
WASHER.FELT. Price: Call Us |
| 143651 |
MANDREL |
SERV ASM Price: Call Us 143651 |
