| Ref | Part Number | Description |
|---|
| 1 |
108-4496 |
HOUSING-BEARING, NON DRIVEN Price: $315.85 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $139.99 |
| 2 |
108-4495 |
HOUSING-BEARING, DRIVEN Price: $315.85 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
237-22 |
O-RING This part replaces 107-8844. Price: $2.43 |
| 4 |
112-6966 |
ROLLER BRUSH ASM Price: $431.52 |
| 5 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 6 |
108-4480 |
BRACKET-MOUNTING Price: $34.10 |
| 7 |
108-4172 |
SEAL-EXCLUDER Price: $6.52 |
| 8 |
532193228 |
BOX.BATTERY.MNT.REAR.L Price: $11.99 |
| 8 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 9 |
322-16 |
SCREW-HH Price: $3.39 |
| 10 |
108-4491 |
SPACER Price: $11.71 |
| 11 |
112-6957 |
WASHER-HARDENED Price: $1.37 |
| 12 |
115-0821 |
PULLEY-DRIVEN, RRB (5-RIB) Price: $60.66 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $11.99 |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 22 |
532004152 |
LIGHTBULB Price: $2.99 |
| 25 |
581498001 |
CABLE.BATT.RED.8GA.17 Price: $4.99 |
| 26 |
532175158 |
FUSE 20AMP Price: $3.99 |
| 27 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 28 |
532421686 |
CABLE.GROUND.REAR.BATTERY.8G Price: $11.99 |
| 29 |
532192749 |
SWITCH.SEAT.DP W/RAMPS Price: $12.99 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $9.99 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT Price: $6.99 |
| 34 |
532110712 |
SWITCH LT Price: $4.99 |
| 40 |
581023101 |
HARNESS.TEX.DASH.MAN.REAR BATT Price: $24.99 |
| 43 |
582042801 |
SOLENOID.STARTER.BRASS.PLUNGER This part replaces 532192507. Price: $7.99 |
| 55 |
532171877 |
BOLT, 5/16-18 X 1 3/4 This part replaces 817060512. Price: $3.99 |
| 71 |
581023001 |
HARNESS.TEX.CHSSIS.REAR.BATT Price: $39.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $11.99 |
| 87 |
532197802 |
SWITCH.INTRLCK.CLUTCH. Price: $11.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $2.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $2.99 |
| 102 |
581023401 |
HARNESS.PIGTAIL.VARIATOR.SD Price: $12.99 |
| 105 |
532407568 |
REVERSE SWITCH Price: $11.99 |
